ST7500 Basic Service
Manual
NOVEMBER 2019
*MN004528A01*
MN004528A01-AF
©
2019 Motorola Solutions, Inc. All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST7500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Motorola solutions ST7500

Summary of Contents for Motorola solutions ST7500

  • Page 1 ST7500 Basic Service Manual NOVEMBER 2019 *MN004528A01* MN004528A01-AF © 2019 Motorola Solutions, Inc. All rights reserved...

  • Page 2: Table Of Contents

    Use of Communication Devices While Driving................20 Operational Warnings....................... 21 Operational Cautions......................21 Warranty and Service Support.................22 Warranty Period and Return Instructions..................22 After Warranty Period........................22 Related Publications....................23 Chapter 1: Model Information.................. 25 1.1 ST7500 Model Specifications....................25 1.2 Sales Model Nomenclature....................27 Chapter 2: Overview....................29...
  • Page 3 MN004528A01-AF Contents 2.1 Digital Modulation Technology....................29 2.2 Voice Compression Technology.................... 29 2.3 Transceiver..........................29 2.3.1 Digital Section......................30 2.3.2 Transmitter Path...................... 30 2.3.3 Receiver Path......................30 2.3.4 Frequency Generating Section................31 2.4 Bluetooth Section........................31 2.5 Global Navigation Satellite System Section................31 Chapter 3: Programming the Radio................32 Chapter 4: Test Setup and Testing................33 4.1 Typical Test Setup.........................
  • Page 4 MN004528A01-AF Contents 4.12.2 Testing Charger Recognition................. 61 4.13 Service Flowchart........................ 62 4.14 Man Down Calibration Data....................63 4.14.1 Testing for Man Down Calibration Data..............63 Chapter 5: Maintenance....................65 5.1 Preventive Maintenance......................65 5.2 Safe Handling of CMOS and LDMOS Devices..............67 5.3 General Repair Procedures and Techniques................ 67 5.4 Pre-baking of Integrated Circuits...................
  • Page 5 MN004528A01-AF Contents 5.8.2.1 Performing Front Housing Kit Troubleshooting.......... 93 5.8.2.2 Performing Battery Cover Kit Troubleshooting...........94 5.8.2.3 Performing Miscellaneous Troubleshooting..........94 Appendix A: Service Information................95 A.1 Service Information....................... 95 A.2 Service Information – APAC....................96 A.3 Recommended Programming Equipment................98 A.4 Service Replacement Kit Matrix.................... 99 Appendix B: Service Aids..................

  • Page 6: List Of Figures

    Figure 26: Removing the Vibrator......................80 Figure 27: Removing the Front Keypad Screw..................81 Figure 28: Inserting the Front Housing Kit Into the ST7500 Front Keypad Service Removal Fixture..81 Figure 29: Detaching the Front Keypad....................81 Figure 30: Removing the Front Keypad....................81 Figure 31: Inserting the Front Keypad ....................
  • Page 7 MN004528A01-AF List of Figures Figure 37: Inserting the OLED Display Jacket..................84 Figure 38: Attaching the Front Keypad Board Connector...............84 Figure 39: Installing the Internal Antenna Module Assembly..............85 Figure 40: Checking the Vibrator Spring, Internal Antenna Spring, Speaker/Bottom Mic Spring, Earpiece Flex Spring, PTT and Side Buttons Spring.................85 Figure 41: Inserting the OLED Flex Connector..................

  • Page 8: List Of Tables

    Table 2: Quick Start Guides........................23 Table 3: User Manuals........................... 23 Table 4: Other Related Manuals......................24 Table 5: ST7500 Sales Models......................25 Table 6: General Specifications for 380–430 MHz Sales Models............25 Table 7: Receiver Specifications for 380–430 MHz Sales Models............26 Table 8: Transmitter Specifications for 380–430 MHz Sales Models.............
  • Page 9 MN004528A01-AF List of Tables Table 36: Service Aids List........................101...

  • Page 10: List Of Procedures

    MN004528A01-AF List of Procedures List of Procedures Assembly Procedures ..........................35 Disassembly Procedures ........................37 Connecting the Radio in Blank Flash Mode ..................39 Connecting the Radio in Normal Mode ....................41 Connecting the Radio in UART Mode ....................42 Configuring IFR 3901/IFR 3902/IFR 3920 Setup .................. 45 Configuring IFR 2968 Setup ........................
  • Page 11 MN004528A01-AF List of Procedures Installing the Internal Antenna Module Assembly ..................84 Installing the Main Board ........................85 Installing the Back Cover ........................86 Inserting the Battery ..........................88 Attaching the Battery Cover ........................88 Installing the Antenna ..........................89 Performing Vacuum Leak Test ......................91 Performing Leak Area Troubleshooting ....................92 Performing Front Housing Kit Troubleshooting ..................

  • Page 12: Copyrights

    Motorola Solutions, Inc. Furthermore, the purchase of Motorola Solutions products shall not be deemed to grant either directly or by implication, estoppel or otherwise, any license under the copyrights, patents or patent applications of Motorola Solutions, except for the normal non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.

  • Page 13: Document History

    Service Aids on page 101. • Added SIM card test in Testing in DALT Mode on page MN004528A01-AD Removed Motorola Solutions Propriety footer. June 2019 MN004528A01-AE Added information for Man Down calibration November 2019 hotfix setup in Man Down Calibration Data chapter.

  • Page 14: Scope Of This Manual

    MN004528A01-AF Scope of this Manual Scope of this Manual This manual contains information necessary to test and maintain the TETRA radio at the module level. It also contains information on radio assembling and disassembling.

  • Page 15: Notations Used In This Manual

    MN004528A01-AF Notations Used in This Manual Notations Used in This Manual Throughout the text in this publication, you will notice the use of warning, caution, and notice notations. These notations are used to emphasize that safety hazards exist, and due care must be taken and observed.

  • Page 16: Safety Information

    Compliance with RF Exposure Standards Your Motorola Solutions two-way radio is designed and tested to comply with various national and international standards and guidelines for human exposure to radio frequency electromagnetic energy. Your Motorola Solutions two-way radio complies with the following RF energy exposure standards and guidelines: •...

  • Page 17: Rf Energy Exposure Awareness, Control Information, And Operational Instructions For Occupational Use

    • When worn on the body, always place the radio in a Motorola Solutions-approved clip, holder, holster, case, or body harness. The use of non-Motorola Solutions-approved accessories may result in exposure levels exceeding the IEEE/ICNIRP occupational/controlled environment RF exposure...

  • Page 18: Approved Accessories

    Use of non-Motorola Solutions-approved antennas, batteries, and accessories may exceed IEEE/ ICNIRP RF exposure guidelines. For a list of Motorola Solutions-approved antennas, batteries, and other accessories, contact your dealer or local Motorola Solutions contact. Your nearest dealer can be found at www.motorolasolutions.com.

  • Page 19: Repair

    Repairs for Motorola Solutions products with intrinsically safe approval are the responsibility of the user. Repairs to a Motorola Solutions FM approved radio product should only be done at a location that has been FM audited under the FM 3605 repairs and service standard. Contact Motorola Solutions for assistance regarding repairs and service of Motorola Solutions intrinsically safe equipment.

  • Page 20: Electromagnetic Interference/Compatibility

    MN004528A01-AF Safety Information Using a non-Motorola Solutions intrinsically safe battery and/or accessory with the Motorola Solutions approved radio unit voids the intrinsically safe approval of that radio unit. Electromagnetic Interference/Compatibility If inadequately shielded, designed, or otherwise configured for electromagnetic compatibility, nearly every electronic device is susceptible to Electromagnetic Interference (EMI).

  • Page 21: Operational Warnings

    MN004528A01-AF Safety Information Operational Warnings WARNING: For vehicles with an air bag, refer to the manual of the vehicle manufacturer before installation of electronic equipment to avoid interference with air bag wiring. Do not mount or place a radio in the area over an air bag or in the air bag deployment area. Air bags inflate with great force.

  • Page 22: Warranty And Service Support

    Warranty Period and Return Instructions The terms and conditions of warranty are defined fully in the Motorola Solutions Dealer or Distributor or Reseller contract. These conditions may change from time to time and the following notes are for guidance purposes only.

  • Page 23: Related Publications

    MN004518A01 fi-FI MN004978A01 ca-ES MN005279A01 tr-TR Table 3: User Manuals Part Number Description Language MN004519A01 ST7500 Feature User Guide en-US MN004520A01 en-US and zh-TW MN004521A01 en-US and ja-JP MN004523A01 en-US and ko-KR MN004524A01 en-US and es-LA MN004525A01 en-US and pt-BR...

  • Page 24: Table 4: Other Related Manuals

    MN004528A01-AF Related Publications Part Number Description Language MN004526A01 en-US and de-DE MN004527A01 ST7500 Product Information en-US Manual Table 4: Other Related Manuals Part Number Description Language MN004530A01 ST7500 Detailed Service Man- en-US...

  • Page 25: Chapter 1: Model Information

    MN004528A01-AF Model Information Chapter 1 Model Information This manual applies to the following ST7500, Class 3L, TETRA Handportable Terminal model: Table 5: ST7500 Sales Models Sales Model No. Short Description AZH94PCL6TZ5AN ST7500 380–430 MHz PTM412DER MDH94PCL6TZ5AN ST7500 380–430 MHz PTM412DER MDH94PCL6TZ5ANB ST7500 380–430 MHz BULK PTM412DER...

  • Page 26: Table 7: Receiver Specifications For 380-430 Mhz Sales Models

    MN004528A01-AF Chapter 1: Model Information GENERAL (HxWxD in mm) 142x63x22 mm with 28 mm antenna 171x63x22 mm with 57 mm antenna Weight: With standard battery and 28 mm antenna 199 g Table 7: Receiver Specifications for 380–430 MHz Sales Models RECEIVER Receiver Type: Class A and B...

  • Page 27: Sales Model Nomenclature

    MD = Europe, Middle East, and Africa (EMEA) Type of Unit H = Hand-Held Portable M = Mobile Product Model Series 94 = Motorola Solutions ST7500 Family Frequency Band P = 380–430 MHz NOTICE: Values given represent range only; they are not absolute.
  • Page 28 MN004528A01-AF Chapter 1: Model Information Position Description Value F = 6.1–10.0 W Physical Packages L = Limited Controls – Limited Display Channel Spacing 1 = 5 kHz 2 = 6.25 kHz 3 = 10 kHz 4 = 12.5 kHz 5 = 15 kHz 6 = 25 kHz 7 = 30 kHz Primary Operation...

  • Page 29: Chapter 2: Overview

    MN004528A01-AF Overview Chapter 2 Overview To achieve a high spectrum efficiency, the radio uses digital modulation technology and sophisticated voice-compression algorithm. The voice of the person speaking into the microphone is converted into a digital bit stream consisting of zeros (0) and ones (1). This stream is then modulated into a radio frequency (RF) signal, which is transmitted over-the-air to another radio.

  • Page 30: Digital Section

    MN004528A01-AF Chapter 2: Overview 2.3.1 Digital Section The digital section is based on a Dual Core System On a Chip (SoC) processor, a low-power Applications processor with dual core architecture based on Advanced RISC Machine (ARM) application core and Digital Signal Processor (DSP) core with floating point. The dual-core architecture of the Dual Core Processor SoC provides benefits of both DSP and Reduced Instruction Set Computing (RISC) technologies.

  • Page 31: Frequency Generating Section

    MN004528A01-AF Chapter 2: Overview • Off Channel Detector and Inverting Schmitt Trigger • Balanced-Unbalanced Converter (BALUN) • Limiter • 2-bit 6/12/18 dB Step Attenuator • Discrete Front Filter • Low Noise Amplifier (LNA) integrated with Step Attenuator and Automatic Gain Control (AGC) continuous attenuation •...

  • Page 32: Chapter 3: Programming The Radio

    MN004528A01-AF Chapter 3: Programming the Radio Chapter 3 Programming the Radio NOTICE: For programming the radio, refer to 6802974C10 TETRA Customer Programming Software (CPS) Plus Start-up User Guide.

  • Page 33: Chapter 4: Test Setup And Testing

    CAUTION: Any level 3 repairs can deeply affect the performance of the terminal and may cause a new tuning procedure. Certain authorized Motorola Solutions depots, where the appropriate test and tune equipment is available, applies this tuning procedure. The appropriate test and tune equipment is a special automated test equipment which is only available at some Motorola Solutions factories and Motorola Solutions repair centers.

  • Page 34: Figure 1: Battery Eliminator Overview

    MN004528A01-AF Chapter 4: Test Setup and Testing Figure 1: Battery Eliminator Overview Table 11: Battery Eliminator Overview Description UART Communication Mode USB/Normal Power ON Mode Blank Board Flashing Mode UART Connector CAUTION: Connect the red (+) and black (-) wires of the battery eliminator to the respective positive and negative points of the power supply, and use the correct voltage (3.8 VDC, maximum 4.2 VDC).

  • Page 35: Assembly Procedures

    MN004528A01-AF Chapter 4: Test Setup and Testing Figure 2: Typical Test Setup Description 3.8 V Power Supply Battery Eliminator connected to Power Supply RF Cable N-type RF Connector IFR 39xx/IFR 2968 4.1.1 Assembly Procedures Procedure: 1 Insert the bottom area of the battery eliminator into the compartment.

  • Page 36: Figure 3: Battery Eliminator Insertion

    MN004528A01-AF Chapter 4: Test Setup and Testing Figure 3: Battery Eliminator Insertion Description Battery Eliminator Banana Plug 2 Press down the top area of the battery eliminator into the compartment until it clicks. 3 Remove the retainer by loosening the thumb screw. WARNING: Use the right RF cable kit for testing, else it damages the RF connector.

  • Page 37: Disassembly Procedures

    MN004528A01-AF Chapter 4: Test Setup and Testing Figure 4: RF cable kit insertion GND +ve GND +ve Description IFR 39xx/IFR 2968 RF Cable Thumb Screw Retainer RF Cable (Part Number TL000100A01) RF Plug Slot Battery Eliminator Banana Plug 4.1.2 Disassembly Procedures Procedure: 1 Loosen the thumb screw.

  • Page 38: Figure 5: Removing Rf Cable Kit

    MN004528A01-AF Chapter 4: Test Setup and Testing Figure 5: Removing RF Cable Kit GND +ve GND +ve Description IFR 39xx/IFR 2968 RF Cable Thumb Screw Retainer RF Cable (Part Number TL000100A01) RF Plug Slot Battery Eliminator Banana Plug 4 Push up the battery latch. The battery eliminator is slightly ejected from the slot. 5 Pull the top part of the battery eliminator outward from the compartment.

  • Page 39: Flashing Mode

    This section lists the applicable flashing mode for the radio and its procedures. • Blank Flash Mode NOTICE: Blank Board Flashing Mode is not supported and can only be performed at authorized Motorola Solutions Repair Center. • Normal Mode •...

  • Page 40: Figure 7: Connecting The Radio In Blank Flash Mode (1 Of 2)

    MN004528A01-AF Chapter 4: Test Setup and Testing 2 Connect the serial data cable to the PC. 3 To enter Boot Me mode, press the On/OFF button or connect the programming cable to the PC. Figure 7: Connecting the Radio in Blank Flash Mode (1 of 2) Description Personal Computer Power Supply 3.8 V...

  • Page 41: Connecting The Radio In Normal Mode

    MN004528A01-AF Chapter 4: Test Setup and Testing Figure 8: Connecting the Radio in Blank Flash Mode (2 of 2) Description Personal Computer Power Supply 3.8 V Serial Data Cable Programming Cable 4.2.2 Connecting the Radio in Normal Mode The function of this mode is for radio normal power-up and programmng cable connection between the radio and the PC(Tetracom).

  • Page 42: Connecting The Radio In Uart Mode

    MN004528A01-AF Chapter 4: Test Setup and Testing Figure 9: Connecting the radio in Normal mode Description Personal Computer Power Supply 3.8 V Programming Cable 4.2.3 Connecting the Radio in UART Mode Procedure: 1 Push down the switch. 2 Connect the radio and PC with the serial data cable. 3 Power on the radio.

  • Page 43: Test Check List

    MN004528A01-AF Chapter 4: Test Setup and Testing Figure 10: Connecting the radio in UART mode Description Personal Computer Power Supply 3.8 V Serial Data Cable Test Check List Table 12: Test Setup for 380–430 MHz Radio Models The following table summarizes the required test setup for 380–430 MHz radio models. Test Name Test Setup Radio Setup...

  • Page 44: Transmitter Tests

    MN004528A01-AF Chapter 4: Test Setup and Testing Test Name Test Setup Radio Setup Test Condi- Limits tions Access Parame- -53 dBm Mobile Power 30.0 dBm (1 W radio) 32.5 dBm (1.8 W radio) Burst Type Normal Transmitter RF Gen Level -90 dBm 30.5–34.5 dBm Burst Power...

  • Page 45: Duplex Test

    MN004528A01-AF Chapter 4: Test Setup and Testing 4.3.3 Duplex Test Digital Duplex Test (Tx) Measurement Capabilities: • Bar charts (Tx Power, Frequency Error, Vector Error RMS) • Spectrum Analyzer • Power Analyzer • Vector Analyzer • Vector Diagrams Configuring IFR 3901/IFR 3902/IFR 3920 Setup Use these procedures to configure the IFR 3901/IFR 3902/IFR 3920 setup.

  • Page 46: Configuring Ifr 2968 Setup

    MN004528A01-AF Chapter 4: Test Setup and Testing NOTICE: The displayed values are factory defaults and should not be changed. BROADCAST: Not Supported BROADCAST INTERVAL: 5 s NEIGHBOUR CELL CHANNEL: 3500 NEIGHBOUR CELL LOCATION AREA: 0017 NEIGHBOUR CELL IDENTIFIER: 01 SLOW RE-SELECT THRESHOLD ABOVE FAST: 10 dB FAST RE-SELECT THRESHOLD: 10 dB SLOW RE-SELECT HYSTERESIS: 10 dB FAST RE-SELECT HYSTERESIS: 10 dB...

  • Page 47: Configuring Ifr 3901/Ifr 3902/Ifr 3920 Manual Screen Test

    MN004528A01-AF Chapter 4: Test Setup and Testing 18 Press More. TETRA Voice Service: Supported Circuit Mode Data Service: Supported (Reserved): Available SNDCP Service: Available Air Interface Encryption: Not Available Advanced Link: Not Supported 19 Press Return. Select Neighbor Cell. 20 Verify that the following NEIGHBOUR CELL INFO values are displayed: NOTICE: The displayed values are factory defaults and should not be changed.

  • Page 48: Configuring Ifr 2968 Manual Screen Test

    MN004528A01-AF Chapter 4: Test Setup and Testing Configuring IFR 2968 Manual Screen Test Use these procedures to configure the IFR 2968 manual screen test. Procedure: 1 Press Manual to enter the Manual Test screen. 2 Press Control Channel. Enter 3605 and press Control Channel. (IFR 3605 = Rx 390.125000 MHz) 3 Press Traffic Channel.

  • Page 49: Testing Receiver Using Ifr 2968

    MN004528A01-AF Chapter 4: Test Setup and Testing 4.8.2 Testing Receiver using IFR 2968 Prerequisites: This test requires programming the radio. Refer to TETRA Customer Programming Software (CPS) User Guide. Procedure: 1 Turn ON the radio. The screen is Idle. 2 Do one of the following to enter the radio test page: •...

  • Page 50: Call Processing Tests

    MN004528A01-AF Chapter 4: Test Setup and Testing NOTICE: Press and hold the PTT to read the results. Monitor the IFR Manual Test screen which displays the Power Profile, Burst Timing, Vector Peak, Vector RMS, Freq Error, and Residual Carrier. Burst Power Required Results: 28.0–32.0 dBm (Class 4) or 30.5–34.5 dBm (Class 3L) Power Profile: Passed Burst Timing: ±...

  • Page 51: Call To Mobile

    MN004528A01-AF Chapter 4: Test Setup and Testing 4.9.3 Call to Mobile Procedure: 1 Press Call Mobile on the IFR. 2 Press Private. NOTICE: Select the type of call. The handset beeps. 3 Press Abort Call. 4 Repeat step 1 through step 3 for Phone and Emergency calls.

  • Page 52: Digital Duplex Test (Tx) Using Ifr 2968

    MN004528A01-AF Chapter 4: Test Setup and Testing 5 Press End on the handset. 4.11 Digital Duplex Test (Tx) using IFR 2968 Procedure: 1 On the radio, press Menu → Contact → Contact 1 → Send. The following results are displayed on IFR Manual Test Screen. Burst Power Required Results: 28.0–32.0 dBm (Class 4) or 30.5–34.5 dBm (Class 3L) Power Profile: Passed...

  • Page 53: Manual Mode Testing

    MN004528A01-AF Chapter 4: Test Setup and Testing 4.12 Manual Mode Testing When and where to use: Use these procedures to set up radio for DALT Mode testing. Procedure: 1 Verify that the radio is turned OFF. 2 Press and hold P2 Programmable button and PTT simultaneously and press the Power button for more than 5 seconds to enter DALT mode.
  • Page 54 MN004528A01-AF Chapter 4: Test Setup and Testing 5 Do the following: Action The display shows: Press any key. • If passed, the display shows: Battery Interface Test PASSED • If failed, the display shows: Battery Interface Test FAILED 6 Press the corresponding key to proceed to the next test. SD Card Test 7 The display shows: SD card...
  • Page 55 MN004528A01-AF Chapter 4: Test Setup and Testing 12 Press the corresponding key to proceed to the next test. Vibrator Test 13 The display shows: Vibrator Test 14 Do the following: Action Result Press any key. The display shows: Vibrator On The radio vibrates.
  • Page 56 MN004528A01-AF Chapter 4: Test Setup and Testing Action Result Press any key. The display shows: Up LED on The Up button lights up. Press any key. The display shows: Down LED on The Down button lights up. Press any key. The display shows: Back LED on The Back button lights up.
  • Page 57 MN004528A01-AF Chapter 4: Test Setup and Testing VBUS 5 V Output Test 25 The display shows: VBUS 5V Output Test WAIT!!! 26 Do the following: Action Result Wait for response • If passed, the display shows: VBUS 5V Output Test PASSED •...
  • Page 58 MN004528A01-AF Chapter 4: Test Setup and Testing Action Result Connect/Disconnect Not Connected Press any key To Continue Attach the PHF to the The display shows: RSM. Connect/Disconnect Connected Press any key To Continue NOTICE: Press the P1 Programmable Button to proceed. Otherwise, the Accessory Connect Test restarts.
  • Page 59 MN004528A01-AF Chapter 4: Test Setup and Testing Action Result INT MIC to INT EAR Loopback Test Speak into the internal mi- You hear your voice from the internal earpiece. crophone. Press any key to continue. The display shows: Connect RSM accessory to the radio Attach RSM accessory to...
  • Page 60 MN004528A01-AF Chapter 4: Test Setup and Testing Action Result Press any key. The display shows: BACK DOWN PROG3 Press the corresponding The respective display disappears every time you press a key to continue. key. Continue until display is empty. 42 Press the corresponding key to proceed to the next test. Gyro Sensor Test 43 The display shows: Gyro Sensor...

  • Page 61: Testing Charger Recognition

    MN004528A01-AF Chapter 4: Test Setup and Testing Action Result BT test - SPEAKER SPEAKER STARTED Speak into the internal mi- You will hear yourself in the paired Bluetooth audio speaker. crophone. 48 Press the corresponding key to proceed to the next test. The display shows: The test is completed.

  • Page 62: Service Flowchart

    MN004528A01-AF Chapter 4: Test Setup and Testing 4.13 Service Flowchart The service flowchart shows the expected results and their next required actions for the testing procedure of the radio. Figure 11: Service Flowchart Connect the radio to the IFR (1) Fail Pass Perform all...

  • Page 63: Man Down Calibration Data

    This hotfix contains the default Man Down calibration data. The hotfix is only available at the Motorola Solutions Service Center or Depot. To enable the Man Down feature, you must bring your radio to the center to have it serviced for calibration data setup.
  • Page 64 MN004528A01-AF Chapter 4: Test Setup and Testing If… Then… a Turn off the radio. b Contact the nearest Motorola Solutions Service Center or Depot to set up the calibration data.

  • Page 65: Chapter 5: Maintenance

    MN004528A01-AF Maintenance Chapter 5 Maintenance This chapter provides information about the care and maintenance of this radioRSM. Preventive Maintenance Periodic visual inspection and cleaning are recommended. IMPORTANT: To avoid compromising the ingression protection of IP67, do not remove the seal label at the side of the radio.
  • Page 66 For reliable performance, it is important to ensure that the electrical contact interface remains clean and free of foreign material. To maintain optimal performance of the contact interface, Motorola Solutions recommends inspecting and cleaning the contacts every six months or before Radio programming.

  • Page 67: Safe Handling Of Cmos And Ldmos Devices

    (ESD) shoes, and an ESD chair. • Wear a conductive wrist strap in series with a 100k resistor to ground. Replacement wrist straps that connect to the bench top covering are Motorola Solutions part number 4280385A59. • Do not wear nylon clothing while handling CMOS/LDMOS devices.

  • Page 68: Table 14: Lead Free Solder Wire Part Number List

    Parts Replacement and Substitution When damaged parts are replaced, identical parts must be used. If the identical replacement part is not locally available, check the parts list for the proper Motorola Solutions part number and order the part. Rigid Circuit Boards This family of radios use bonded, multi-layer, printed circuit boards.

  • Page 69: Pre-Baking Of Integrated Circuits

    MN004528A01-AF Chapter 5: Maintenance Care After Submersion The radio (device with antenna and battery assembled) is IP67 compliant. It is fully protected from dust, can withstand being submerged in one meter of static water for up to 30 minutes. If the device has been submerged in water, shake the device to remove any water that is trapped inside the speaker grille and microphone port.

  • Page 70: Level 1 And Level 2 Maintenance

    MN004528A01-AF Chapter 5: Maintenance Part Number Moisture Sensitivity Description Level (MSL) 51012475004 Dual Core Processor 2.3, U4020_A 51016003001 mDDR RAM, U4050_A MM000157A01 FLASH, U4000_A Level 1 and Level 2 Maintenance This manual covers Level 1 and Level 2 Maintenance. At Level 1 maintenance, you replace the terminal and/or accessories and send the faulty unified chassis and/or accessories to a higher level of maintenance.

  • Page 71: Figure 12: Exploded View

    MN004528A01-AF Chapter 5: Maintenance Figure 12: Exploded View Table 17: Radio Replacement Parts List No. from Ex- Part/Kit Number Description ploded View PMHN4389_ Battery Door Kit LB001049A01 Vent Label 3286058L01 Gore Port Membrane FN000147A04 Machined Screw, M2 x 0.4 x 5.3 (mm)
  • Page 72 MN004528A01-AF Chapter 5: Maintenance No. from Ex- Part/Kit Number Description ploded View HW001058A01 Battery Latch 0104077J56 Sim Door Assembly 33012021018 Model Label 54012164001 Tamper Label PMHN4387_ Rear Housing Kit LB000755A01 Test Point Label LB001045A01 Battery Floor Cosmetic Label HW001102A01 Battery Pad HW001593A01 20-pin Board-to-Board Connector Pad 3980667Z06...

  • Page 73: Accessories Replacement Parts List

    MN004528A01-AF Chapter 5: Maintenance No. from Ex- Part/Kit Number Description ploded View FN000361A01 Keypad Machine Screw KP000143A01 P1 Programmable Button HW001618A01 Side Keypad Support 5.6.2 Accessories Replacement Parts List Choose from a variety of accessories designed, tested, and certified to optimize the performance of this radio.

  • Page 74: Table 22: Batteries And Chargers

    Carry Holster with Peter Jones (ILG) Klick Fast Clip Table 24: Power Cords Part Number Description 3087791G01 Power Cord, US/NA Table 25: Power Supply Part Number Description PS000242A01 100–240 VAC Power Supply Table 26: Programming Cable Part Number Description PMKN4024_ ST7500 to Si700 Cable PMKN4203_ Programming Cable...

  • Page 75: Radio Disassembly And Reassembly

    FN000147A04 3.5±0.1 lb-in 5.7.2 Disassembling the Radio Only Motorola Solutions Service Centers or Authorized Motorola Solutions Service Dealers can disassemble the radio for repair or maintenance. Prerequisites: Prepare a torque screwdriver with 5 IP and 6 IP TORX Plus ®...

  • Page 76: Removing The Antenna

    MN004528A01-AF Chapter 5: Maintenance Mobile: +6012-5808783 Fax: +604-6261708 Email: stevenboey@accesshitech.com / hq@accesshitech.com MSI Part Number TL000111A01 Supplier Part Number MT062/17 5.7.2.1 Removing the Antenna Procedure: Unscrew the antenna counterclockwise until it is detached from the radio. The antenna must be removed each time the back housing is removed.

  • Page 77: Removing The Battery

    MN004528A01-AF Chapter 5: Maintenance Figure 15: Removing the Battery Cover 5.7.2.3 Removing the Battery Procedure: Push the battery release button upward to release the battery from the radio. Figure 16: Removing the Battery 5.7.2.4 Removing the Back Cover Procedure: 1 Remove the tamper label. Figure 17: Removing the Tamper Label 2 Follow the sequence in Figure 18: Removing the Main Screws on page 78...

  • Page 78: Removing The Main Board

    MN004528A01-AF Chapter 5: Maintenance Figure 18: Removing the Main Screws 3 Lift the back cover upward. Figure 19: Removing the Back Cover 5.7.2.5 Removing the Main Board Procedure: 1 Detach the top flex connector. Figure 20: Detaching the Top Flex Connector 2 Detach the bottom connector flex connector.

  • Page 79: Removing The Internal Antenna Module Assembly

    MN004528A01-AF Chapter 5: Maintenance Figure 21: Detaching the Bottom Connector Flex Connector 3 Flip over the main board and detach the OLED flex connector to remove the main board. Figure 22: Removing the Main Board 5.7.2.6 Removing the Internal Antenna Module Assembly Procedure: Detach the internal antenna module assembly.

  • Page 80: Removing The Vibrator

    Skip this section if your radio uses the Front Housing Kit (part number: PMHN4393_). The ST7500 Front Keypad Service Removal Fixture is required to perform the Front Keypad removal. Purchase the ST7500 Front Keypad Service Removal Fixture from the supplier listed in...

  • Page 81: Figure 27: Removing The Front Keypad Screw

    1 Use a torque screwdriver with 5 IP Torx Plus bit to unscrew front keypad screw in a counterclockwise direction. Figure 27: Removing the Front Keypad Screw 2 Insert the front housing kit into the ST7500 Front Keypad Service Removal Fixture. Figure 28: Inserting the Front Housing Kit Into the ST7500 Front Keypad Service Removal Fixture 3 Press down the fixture toggle to detach the front keypad.

  • Page 82: Reassembling The Radio

    Skip this section if your radio uses the Front Housing Kit (part number: PMHN4393_). The ST7500 Front Keypad Service Assembly Fixture is required to perform the Front Keypad removal. Purchase the ST7500 Front Keypad Service Assembly Fixture from the supplier listed in...

  • Page 83: Installing The Vibrator

    MN004528A01-AF Chapter 5: Maintenance Figure 32: Inserting the Front Housing Kit Into the ST7500 Front Keypad Service Assembly Fixture 3 Press down the fixture toggle to attach the front keypad. Figure 33: Installing the Front Keypad 4 Use a torque screwdriver with 5 IP Torx Plus bit to fasten the front keypad screws in a clockwise direction.

  • Page 84: Installing The Oled Display Module Assembly

    MN004528A01-AF Chapter 5: Maintenance 5.7.3.3 Installing the OLED Display Module Assembly Prerequisites: Clean the residue on the OLED flex surface and on the housing surface before replacing a new OLED flex adhesive. Procedure: 1 Replace the OLED flex adhesive with a new adhesive. Figure 36: Replacing the OLED Flex Adhesive 2 Slot in and press down the OLED Display Jacket.

  • Page 85: Installing The Main Board

    MN004528A01-AF Chapter 5: Maintenance Figure 39: Installing the Internal Antenna Module Assembly 5.7.3.5 Installing the Main Board Prerequisites: CAUTION: Check and ensure there is no damage to the vibrator spring, internal antenna spring, speaker/bottom mic spring, earpiece flex spring, PTT and side buttons spring. If there is damage, replace the parts.

  • Page 86: Installing The Back Cover

    MN004528A01-AF Chapter 5: Maintenance Description Vibrator spring PTT and side buttons spring Procedure: 1 Insert OLED Flex connector to the main board. Figure 41: Inserting the OLED Flex Connector 2 Insert the main board into the front housing. NOTICE: Ensure the top flex and bottom connector flex are on top of the main board. Figure 42: Insert the Main Board 3 Insert the top flex and the bottom connector flex connector to the main board.

  • Page 87: Figure 44: Checking The Thermal Pad And Butterfly Clips

    MN004528A01-AF Chapter 5: Maintenance Figure 44: Checking the Thermal Pad and Butterfly Clips Description Butterfly clip Thermal pad Procedure: 1 Slide in the back housing into the front housing slot from the top and then press down on the bottom area of the back housing. Figure 45: Installing the Back Housing 2 Follow the sequence in Figure 46: Attaching the Main Screws on page 87...

  • Page 88: Inserting The Battery

    MN004528A01-AF Chapter 5: Maintenance Figure 47: Placing a New Tamper Label 5.7.3.7 Inserting the Battery Procedure: 1 Insert the battery into the battery compartment until the contacts align and the battery hooks in place. Figure 48: Inserting the Battery 2 Press the battery downward until it clicks. 5.7.3.8 Attaching the Battery Cover Prerequisites: Ensure the battery cover latch is at the unlock state before attaching the battery cover.

  • Page 89: Installing The Antenna

    MN004528A01-AF Chapter 5: Maintenance Figure 50: Attaching the Battery Cover 2 Slide the latch to the left to lock the battery cover. Figure 51: Locking the Battery Cover 5.7.3.9 Installing the Antenna Procedure: 1 Insert the screw-in base of the antenna into the antenna terminal at the top of the radio. 2 Turn clockwise until tight.

  • Page 90: Radio Leak Test

    MN004528A01-AF Chapter 5: Maintenance Radio Leak Test This section discusses radio immersibility concerns, tests, and disassembly and reassembly of the radios. 5.8.1 Vacuum Leak Test The vacuum leak test is performed to ensure that the radio is IPx7 compliant. Perform this test after servicing the radio and before returning the radio to the customer.

  • Page 91: Performing Vacuum Leak Test

    MN004528A01-AF Chapter 5: Maintenance Motorola Solutions Part Number: TL000116A01 Supplier Part Number: MT057#17 5.8.1.1 Performing Vacuum Leak Test This test is performed to determine if the radio is properly sealed. Prerequisites: • Remove the antenna, side escutcheon, and battery cover from the radio.

  • Page 92: Performing Leak Area Troubleshooting

    MN004528A01-AF Chapter 5: Maintenance Figure 54: Radio in Leak Test Fixture 9 Start the vacuum leak test and observe the gauge for 20 seconds while the vacuum leak tester is running. NOTICE: Maximum allowable pressure drop after 20 seconds is 0.10 inHg. 10 Perform one of the following actions: If…...

  • Page 93: Performing Front Housing Kit Troubleshooting

    MN004528A01-AF Chapter 5: Maintenance 1 On the front housing kit, remove the side escutcheon. 2 On the rear housing kit, remove the ventilation label and the GORE membrane. 3 Place the leak test spacer on the GORE membrane recess. 4 Prepare a golden sample for the front housing kit. IMPORTANT: Golden sample kit must pass the vacuum leak test.

  • Page 94: Performing Battery Cover Kit Troubleshooting

    MN004528A01-AF Chapter 5: Maintenance If… Then… Pass Front housing kit is good for reuse. Proceed Performing Miscellaneous Troubleshoot- ing on page Fail Replace the front housing kit. 5.8.2.2 Performing Battery Cover Kit Troubleshooting Procedure: 1 Inspect the sealing path of the battery cover kit. 2 Use IPA to clean the sealing path of the battery cover kit from contamination.

  • Page 95: Appendix A: Service Information

    The radios are programmed at the factory. They cannot be tuned at the field service level. Level 3 Maintenance Level 3 maintenance can only be done at the Motorola Solutions Service Center/Depot. To find out more about Motorola Solutions Service Center, visit https://www.motorolasolutions.com/.

  • Page 96: Service Information - Apac

    If you need help in identifying non-referenced spare parts, direct a request to the Customer Care Organization of a local area Motorola Solutions representative. Orders for replacement parts, kits, and assemblies should be placed directly at the local distribution organization of Motorola Solutions or through the Extranet site Motorola Online at https://emeaonline.motorolasolutions.com.
  • Page 97 3220 Sukhumvit Road, Klongtoey, Bangkok 10110 Contact: Nitas Vatanasupapon E-mail: Nitas@motorolasolutions.com India +91-9844218850 Motorola Solutions India Pvt. Ltd. C/o Communication Test Design India Private Limited, #4, 5 Maruthi Industrial Estate, Rajapalya, Hoodi Village, Bangalore - 560048, India Contact: K. Umamaheswari E-mail: umamaheshwari@motorolasolutions.com...

  • Page 98: Recommended Programming Equipment

    Some replacement parts, spare parts, and/or product information can be ordered directly. If a complete Motorola Solutions part number is assigned to the part, it is available from Motorola Solutions Service Organization. If no part number is assigned, the part is not normally available from Motorola Solutions.

  • Page 99: Service Replacement Kit Matrix

    Table 33: Service Replacement Kit Matrix (for EMEA) Service Tanapa Description PMUE5331_S ST7500 380-430MHz CLR PMUE5434_S ST7500 380-430MHz TEA1 GMUE0004_S ST7500 380-430MHz TEA2 (for Alsdorf DC) PMUE5389_S ST7500 380-430MHz TEA3 PMUE5435_S ST7500 380-430MHz CLR SIM GMUE0005_S ST7500 380-430MHz TEA2 BSI (for Alsdorf PMUE5436_S...

  • Page 100: Table 35: Service Replacement Kit Matrix For Mainboard (For Emea)

    ST7500 380-430MHz CLR SIM Mainboard PEN PMUE5331_W ST7500 380-430MHz CLR Mainboard PMUE5434_W ST7500 380-430MHz TEA1 Mainboard GMUE0004_W ST7500 380-430MHz TEA2 Mainboard (for Alsdorf DC) PMUE5389_W ST7500 380-430MHz TEA3 Mainboard PMUE5435_W ST7500 380-430MHz CLR SIM Mainboard GMUE0005_W ST7500 380-430MHz TEA2 BSI Mainboard (for Alsdorf...

  • Page 101: Appendix B: Service Aids

    The supplier for this equipment is listed in Disassembling the Radio on page The supplier for this equipment is listed in Vacuum Leak Test on page This test equipment is not provided by Motorola Solutions. Customers are required to obtain the equipment from external vendors.

  • Page 102: Glossary

    MN004528A01-AF Glossary Glossary Advanced RISC Machine (ARM) Default A pre-defined set of parameters. processor architecture based on a 32-bit reduced instruction set (RISC) computer. Differential Quadrature Phase Shift Keying (DQPSK) A sub-class of the QPSK Air Interface Encryption (AIE) Provides methods of transmitting data.
  • Page 103 Pins whose function is programmable. std 1149.1a, which defines signals and behavior for serial testing. Global Core Accessory Interface Abbreviation: JTAG Motorola Solutions proprietary accessory port for kilohertz (kHz) use with Motorola Solutions approved cables. One thousand cycles per USB and RS232 styles supported.
  • Page 104 MN004528A01-AF Programming Cable circuit board with copper strips on one or both System-On-a-Chip An integrated circuit sides to replace wires. with all the required circuitry and components of an electronic system on a single chip. Programming Cable A cable that allows the Abbreviation: SoC computer to communicate directly with certain Time Division Multiple Access (TDMA)

Table of Contents
