  • Page 1 Log Crane Adaptor/Drawbar Kit AM31 LW228 Log Crane/Drawbar Kit AM32 LW16 Manual Winch Kit AM33 RK26 Rake Kit AM34 © Copyright 2013 by C. F. Struck Corp. Patents pending Magnatrac ® is a registered trademark of C. F. Struck Corp 1.14.14...
  • Page 2 Remember, left & right are always determined from the rear of your RS196K Magnatrac. 1740L 1740R...
  • Page 3 Fully remove NOTE: The following instructions these two will show you in detail how to mount Bolts inside Body. your #1740L Left Mud Scraper. When completed, you will be asked to repeat the similar assembly for the #1740R Right Mud Scraper. STEP 1.
  • Page 4 1740L STEP 3. Slip #1759 Tubes into Left Mud Scraper 7/8” slots in outside face of #1740L Mud Assembly Scraper. Align Tubes with mating “lower” 3/8” holes on inside face of #1691 Expander. [See Photo bottom of page above] From outside, insert a YY Bolt into each YY Bolts of the aligned Tubes.
  • Page 5 Manual Front Hitch Kit RS196K - MFH15 Parts & Fastener List 001654sfp Latch Plate 3/8-16x1-1/2 Carriage Bolt 001661sfp Plate 3/8-16 Dot Lock Nut 001665sfp Handle 3/8-16x1 Carriage Bolt 001666sfp Lift Linkage 3/8-16x1-1/2 Bolt 001667sfp Arm Latch 1/2-13x1-1/4 Bolt 001670sfp 1/2-13x4-1/2 Bolt...
  • Page 6 CAUTION The #2203 Springs used in this assembly are common “extension springs”. Their assembly re- Left quires that the assembler wears gloves Body and has sufficient arm strength to pull Wall on the Spring with approximately 30 lbs. HH Nuts Right of vertical force.
  • Page 7 2209 STEP 3. From above, insert #1665 Handle into slot in #1605 Right Fender... see Photo at right. 1665 Slip #2209 Grip over #1665 Han- dle on right side of Body... see Photo at right. 1665 “slot” 1605 Right Fender STEP 4.
  • Page 8 STEP 6. Remove #Q Bolt and Remove Q Bolt 1665 #HH Nut from location in lower center of and HH Nut from Right Wall... see Photo at right. this location. 1811 STEP 7. In the following order: Insert #AD Bolt into #2005 Washer, #2207 Bushing, 5/8”...
  • Page 9 STEP 11. Following Photo below, slip Slip two (2) #2203 Springs over each end #1654 Latch Plate around #1665 Handle... se- of #1670 Pin. Secure each end with #AG Bolt, cure with two (2) #I Bolts and #NN Nuts... finger #RR Washer, second #RR Washer and secure tight.
  • Page 10 STEP 13. Pull #1665 Handle fully rearward and secure it behind rear “tab” of its #1654 Latch Plate... see Photo at right. STEP 14. With “gloved” hands, rotate each #2203 Spring rearward and loop the top loop of each Spring over the head of its appropriate #AO Bolt...
  • Page 11 STEP 17. Following the instruc- DB44 tions closely, completely assemble your Dozer DB44 Dozer Blade. Blade When completed, slip DB44 4121 Dozer Blade’s “Top Mount and Bottom Mount” around #1694 Front Hitch. Bolts Mount & MM Nuts Align 1/2” holes in Top & Bottom Mounts with mating 1/2”...
  • Page 12 STEP 20. Totally remove #1654 Latch Plate. Invert it and turn it “end to end”. Remount it per Photo at right... use orignal #I Bolts & #NN Nuts... tighten... see Photo at right. Slip 5/8” hole end of #1666 Lift Cross Shaft “resting on”...
  • Page 13 1665 KK Nut 1654 1667 Arm Latch “locked position” Upper Stud Lower Stud SAFETY NOTE: For transporting, you should al- ways have the #1665 Handle [Front Hitch] in the “Rearward Locked” posi- tion... Handle should be behind “rear tab” of #1654 Latch Plate..see Photo at right.

  • Page 14: Operating Note

    STEP 24. On top front face of #1606 Left Fender, locate a point 29-1/2” forward of rear edge and 7/8” inward of left edge... see Photos below. At this point, accurately drill a 5/16” hole if it has not already been provided. Locate 5/16”...
  • Page 15 Dozer Blade Kit RS196K - DB44 [BM13] Parts & Fastener List 5/16-18x1 Spin Lock Bolt 5/16-18 Spin Lock Nut 004118sfp Blade, 42” wide 004119sfp Edge, 42” wide 004120sfp Bottom Blade Mount 004121 Top Blade Mount 4118 4119 4120 4121 AM15...
  • Page 16 STEP 1. Locate the five (5) 4118 5/16” slots in #4119 Edge with mating five 5/16” holes in lower edge of #4118 Blade. From the front, slip a #R Bolt into R Bolts (5) each of these mating five slots & holes. STEP 2.
  • Page 17 Bucket Mouth Kit RS196K - BM13 Parts and Fastener List 001168sfp Hitch Pin, #8 1/4-20x3/4 Bolt 002209 Grip 5/16-18x3/4 Carriage Bolt (5) 002232sfp Handle 5/16-18x1 Spin Lock Bolt (6) 004104sfp Side Assembly 3/8-16x1 Bolt 004105sfp Bucket Bottom 5/16-18 Spin Lock Nut...
  • Page 18 4105 4119 M Bolts STEP 1. Invert #4105 Bucket Bottom. Locate #4119 Edge over forward edge of Bucket Bottom. Align the five (5) 5/16” wide slots in Edge with mating five (5) 5/16” holes in Bucket Bottom. Insert a #M Bolt in each set of 5/16” holes and slots. Secure inside with #HH Nuts. Push Edge evenly to the rear...
  • Page 19 4107 5/16” hole used 4106L Left STEP 4. Per Photo at right, align R Bolt Bracket the two (2) 5/16” holes of #4106L Left & HH Nut Bracket with mating holes in top left 4118 front of #4118 Blade. Insert #R Bolt into Blade each pair of mating holes and secure behind with HH Nuts...
  • Page 20 1168 2232 STEP 6. When both #4107 Locks are fully closed, secure each with a #1168 Hitch Pin... inset Photo at far 2209 right. 4107 2232 STEP 7. Your installation of the 4106L #2232 Handle is strictly “operator pref- Left erence”.
  • Page 21 Rear Hitch Kit RS196K - MRH35 Parts & Fastener List 000126sfp Pin, attachment 3/8-16x1-1/2 Bolt 001172 Lynch Pin 1/2-13x1-1/4 Bolt 001680sfp Hitch Channel 1/2-13x4-1/2 Bolt 001693sfp Bail 3/8-16x1 Spin Lock Bolt 001701sfp Bushing, 1/2IDx3/4OD 5/8-11x1-1/2 Bolt 001703sfp Handle 1/2-13 Dot Lock Nut 001906 Cotter Pin, 1/8x1-1/4”...
  • Page 22 STEP 1. Align the six (6) 3/8” Holes in #1680 Hitch with mating six (6) 3/8” Holes in rear surface of #1601 1680 Body Pan. Hitch 1601 1680 “tab” Body From outside, insert a #AH Bolt into each of the six 3/8” holes aligned above.
  • Page 23 1680 Hitch STEP 5. Per Photo at right, in- Channel 1906 Cotter Pin sert end of #1703 Handle into two (2) parallel 7/8” holes in top of #1680 Hitch Channel. Secure left end of Handle with 2579 Washers two (2) #1906 Cotter Pins on left and 1703 Handle right face of Left Channel “side”...
  • Page 24 STEP 7. With #1703 Handle ro- 1703 tated fully forward, insert “opened” Handle #1172 Lynch Pin into aligned 3/8” hole “arm” in #1703 Handle “arm” and #4131 1172 Link... close Lynch Pin... see Photo at Lynch right. NOTE: #1172 Lynch Pin is used as a “safety device”...
  • Page 25 Double Ripper Kit RS196K - DR30 Parts & Fastener List 000143 Chisel Tooth 004110sfp Ripper Channel 1/2-13x1-1/2 Spin Lock Bolt 1/2-13 Spin Lock Nut 5/8” hole 4110 [“top & bottom”] AM25...
  • Page 26 STEP 1. From outside, screw your two (2) #AI Bolts into 5/8” Nuts welded inside #1693 Bail “channel”... leave approximately 3/4” of each Bolt 1172 exposed... see Photo at right. Lynch STEP 2. Slip #4110 Channel around #1693 Bail “channel”... align 5/8” holes in #4110 Channel with mating “tube”...
  • Page 27 Drawbar Kit RS196K - BD23 Parts & Fastener List 002330sfp Drawbar 3/8-16x1 Spin Lock Bolt 3/8-16 Spin Lock Nut NOTE: depending on your use, the #2330 Drawbar is able to be mounted in a low position [5-1/2” above ground 2330 Drawbar level] or a high position [9-1/2”...
  • Page 28 Grouser Track Shoe Kit RS196K - TSO58 Parts & Fastener List 001161sfp Grouser Shoe (58) 5/16-18x3/4 Spin Lock Bolt (174) 5/16-18 Spin Lock Nut (174) NOTE: To clarify the assembly proce- dure, the following Photos show the Grouser Track Shoe being installed on the rear end of the Track.
  • Page 29 Rubber Track Shoe Kit RS196K - RS58 Parts & Fastener List 001641sfp Channel (58) 001642sfp Rubber Shoe (58) 5/16-18x1 Carriage Bolt (174) 5/16-18 Spin Lock Nut (174) 1641 Channel 1642 Rubber Shoe NOTE: To clarify the assembly procedure, the following Photos show the Rubber Track Shoe being installed on the rear end of the Track.
  • Page 30 Hitch Adapter Kit RS196K - HA14 Parts & Fastener List 001750sfp Receiver Assembly [Class #2 opening] (1) NOTE: AF Bolts and AK Nuts described and shown below are provided with your MRH35 Manual Rear Hitch Kit. STEP 1. Slip “channel” portion of 1750 Receiver “tube”...
  • Page 31 Log Crane Adaptor/Drawbar Kit RS196K - LCA9 Parts & Fastener List 001708sfp Adaptor, Drawbar NOTE: 1. AF Bolts and AK Nuts described and shown below are provided with your MRH35 Manual Rear Hitch Kit. 2. AH Bolts and JJ Nuts described and shown below are provided with with the LW228 Kit.
  • Page 32 Log Crane/Drawbar Kit RS196K - LW228 Parts & Fastener List 002270sfp Crane Assembly 3/8-16x1 Spin Lock Bolt 3/8-16 Spin Lock Nut LW228 Log Crane/Drawbar Assembly Mounting Plate AH Bolt (4) & JJ Nut (4) STEP 1. Align the pattern of four (4) 3/8” holes in #LW228 Log Crane/Drawbar Assembly with mating 3/8”...
  • Page 33 Manual Winch Kit RS196K - LW16 Parts & Fastener List 000160 Hand Winch 000161 Cable & Hook 3/8-16x1 Spin Lock Bolt 3/8-16 Spin Lock Nut LW228 Log Crane/Drawbar Assembly Hand Winch Optional LW16 Manual Winch Kit 161 Cable & Hook Mount your Winch per instructions furnished by Winch manufacturer.
  • Page 34 Rake Kit RS196K - RK26 Parts & Fastener List 002260sfp Yoke 002261sfp 002262sfp Channel 002263sfp Angle 002264 Spikes (40) 3/8-16 Spin Lock Nut 1/2-13 Spin Lock Nut 3/8-16x1 Spin Lock Bolt 1/2-13x1 Spin Lock Bolt 2262 2263 2264 2264 2261...
