Koki Holdings WH 18DE Service Manual

18 v cordless impact driver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NAME
18 V Cordless Impact Driver
WH 18DE, WH 18DEX
Models
CONTENTS
TROUBLESHOOTING GUIDE ---------------------------------------------------------------------------------------------- 1
REPAIR GUIDE ----------------------------------------------------------------------------------------------------------------- 2
1. Precautions on disassembly and reassembly ------------------------------------------------------------- 2
• Disassembly ----------------------------------------------------------------------------------------------------- 2
• Reassembly ----------------------------------------------------------------------------------------------------- 6
• Type of silicone rubber --------------------------------------------------------------------------------------- 15
• Lubrication points and type of lubricant ------------------------------------------------------------------ 15
• Tightening torque ---------------------------------------------------------------------------------------------- 16
• Checking after reassembly ---------------------------------------------------------------------------------- 16
• No-load current value ---------------------------------------------------------------------------------------- 16
• Wiring diagram ------------------------------------------------------------------------------------------------- 17
2. Precautions on disassembly and reassembly of the charger ---------------------------------------- 17
WH 18DEX: For the USA and Canada
WH 18DE: For other regions
WH 18DE
Overseas Sales Management Dept.
CONFIDENTIAL
Jul. 2022
Page
W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WH 18DE and is the answer not in the manual?

Questions and answers

Summary of Contents for Koki Holdings WH 18DE

  • Page 1: Table Of Contents

    PRODUCT NAME 18 V Cordless Impact Driver WH 18DE, WH 18DEX Models WH 18DEX: For the USA and Canada WH 18DE: For other regions CONTENTS Page TROUBLESHOOTING GUIDE ---------------------------------------------------------------------------------------------- 1 REPAIR GUIDE ----------------------------------------------------------------------------------------------------------------- 2 1. Precautions on disassembly and reassembly ------------------------------------------------------------- 2 •...

  • Page 2: Troubleshooting Guide

    TROUBLESHOOTING GUIDE When troubleshooting, be sure to wipe off all dust, water, and other foreign matter from the internal parts, and then dry the parts adequately before conducting the following investigation. Trouble Cause Check method Corrective action • Switch connector •...

  • Page 3: Repair Guide

    1. Precautions on disassembly and reassembly [Bold] numbers in the description below correspond to the item numbers in the parts lists and exploded assembly diagrams for the Models WH 18DE and WH 18DEX. Disassembly 1. Removal of the guide sleeve (1) Remove the Retaining Ring [1], Washer (D) [2], Guide Spring [3], and Guide Sleeve [4] in this order with a small flat-blade screwdriver.
  • Page 4 (1) Remove the eight Tapping Screws (W/Flange) D3 x 16 (Black) [32]. Remove housing (B) of Housing (A).(B) Set [29]. Then, remove the Strap (Black) [40] (Model WH 18DE only). (2) Remove the Hammer Case [6], hammer assembly, Inner Cover [26], and Wiring Ass'y [35] (including the DC-Speed Control Switch [36]).
  • Page 5 • Disassembly of the hammer assembly (1) [19] [17] [22] • Disassembly of the hammer assembly (2) Press down. Hand press Raised faces of Hammer [10] Press down. [18] [18] Top of spindle cam [10] [13] [14] Jig (block etc.) [15] Steel ball guide groove [16] (2 pcs.)
  • Page 6 7. Disassembly of the power supply unit (1) Peel off the silicone from the connectors of the DC-Speed Control Switch [36] with a flat-blade screwdriver. Slowly push down the zip of the connector cable and slowly pull out the connector cable of the Wiring Ass’y [35].

  • Page 7: Reassembly

    Reassembly Reassembly can be conducted by reversing the disassembly procedure, but note the following. 1. Reassembly of the power supply unit (1) When connecting the DC-Speed Control Switch [36], insert the connector of the connector cable into the connector of the DC-Speed Control Switch [36] securely until it is locked. •...
  • Page 8 • Reassembly of the power supply unit (1) [35] [36] Internal wire (A) Connector Connector cable Connector cable Insert the connector cable into Capacitor LED light Ribbon PCB ass’y the connector until it is locked. cable Internal wire (C) Internal wire (B) Internal wire (C) Terminal support Enlarged view of B...
  • Page 9 • Reassembly of the power supply unit (2) Internal wire (C) Put internal wire (C) between the ribs on housing (A). Internal wire (A) Internal wire guide grooves Put internal wire (C) of the LED light between the ribs on housing (A). Push the ribbon cable and internal wire (A) in the internal wire guide grooves.
  • Page 10 2. Mounting the mechanical parts (1) With twenty-eight Steel Balls D3.175 [11] inserted into the Hammer [10], mount Washer (J) [12], Hammer Spring (J) [13], Washer (S) [14], and the Spindle [18] to the Hammer [10] in this order. (2) Align the top of the cam groove on the Spindle [18] with the steel ball guide groove on the Hammer [10]. Push down the tab at the tip of the Hammer [10] with a hand press or similar tool to compress Hammer Spring (J) [13] until it contacts the Spindle [18] and hold it there.
  • Page 11 (3) After coating shaded areas of housing (A) with silicone rubber (Three Bond TB1211), insert the Strap (Black) [40] into the boss as shown in the figure on page 12 (Model WH 18DE only). Also coat housing (B) with silicone rubber (Three Bond TB1211) at the similar location. Apply grease (Nippeco SEP-3A) to the entire circumference of the Rear Bumper [38] and mount it to the housing.
  • Page 12 • Reassembly of housing (A).(B) set (2) Mount the Hammer Case [6] to housing (A) securely. Retaining tabs The retaining tabs on the Hammer Case [6] are in contact with housing (A) here. Push internal wire (C) of the LED light in this groove, and then put it in place between the retaining tabs on the Hammer Case [6] and housing (A).
  • Page 13 • Reassembly of housing (A).(B) set (3) Strap (Black) [40] insertion boss (Model WH 18DE only) Housing (B) Rear Bumper [38] mounting portion Housing (A) • Reassembly of housing (A).(B) set (4) Improperly assembled. Properly assembled. (The stator is mounted parallel to the housing.) (The stator is slanted off the housing.)
  • Page 14 4. Mounting the rotor pinion ass’y and tail cover (1) Press-fit the Rotor Pinion Ass’y [27] into Housing (A).(B) Set [29] from behind. NOTE: After mounting, check that the Rotor Pinion Ass’y [27] rotates smoothly. If the Rotor Pinion Ass’y [27] does not rotate smoothly, the gear is improperly engaged. In such a case, mount the Rotor Pinion Ass’y [27] properly.
  • Page 15 5. Mounting the exterior parts (1) Mount the Front Cap [5] to the Hammer Case [6] so that the Front Cap [5] groove is positioned at the top of the product. • Mounting the exterior parts Front Cap [5] groove (2) Insert the Hook [34] into the groove under the side of Housing (A).(B) Set [29], and then secure it in place with the Truss Hd.

  • Page 16: Type Of Silicone Rubber

    Type of silicone rubber Please purchase the following silicone rubber as necessary. Item Registered part name Net weight Code No. Three Bond 1211 Silicone rubber 100 g 306927 Lubrication points and type of lubricant Apply specified amount of grease to the following portions. MOLUB-ALLOY 777-1 •...

  • Page 17: Tightening Torque

    Tightening torque • Tapping Screws (W/Flange) D3 x 16 (Black) [32] ··························· 1.3 ± 0.3 N•m {13 ± 3 kgf•cm} • Truss Hd. Screw M4 (Black) [33] ················································ 1.8 ± 0.4 N•m {18 ± 4 kgf•cm} Checking after reassembly After reassembly, check the following. (1) Check that the equipment runs smoothly and starts, stops, changes speed, and changes direction securely.

  • Page 18: Wiring Diagram

    Wiring diagram • Wiring diagram [35] Internal wire (C) Push the ribbon cable and internal wire (A) in the LED light internal wire guide grooves. [37] Internal wire (A) (2 pcs.) Capacitor PCB ass’y [36] Screw boss Connector cable Screw boss Ribbon cable Put connector cable, ribbon cable, internal wire (B), and internal wire (C)
  • Page 19 505 506 507 508 M O D E L Rev.1 WH18DE...
  • Page 20 ITEM CODE DESCRIPTION REMARKS USED 330619 RETAINING RING 330856 WASHER (D) 370581 GUIDE SPRING 376528 GUIDE SLEEVE 372204 FRONT CAP 378650 HAMMER CASE 370579 WASHER (F) 319535 STEEL BALL D3.5 (10 PCS.) 378647 ANVIL (S) 378648 ANVIL (L) FOR CHN, TPE, MAL, IND 378646 HAMMER 959148 STEEL BALL D3.175 (10 PCS.) 315978 WASHER (J)
  • Page 21 M O D E L WH18DEX Rev.1...
  • Page 22 ITEM CODE DESCRIPTION REMARKS USED 330619 RETAINING RING 330856 WASHER (D) 370581 GUIDE SPRING 376528 GUIDE SLEEVE 372204 FRONT CAP 378650 HAMMER CASE 370579 WASHER (F) 319535 STEEL BALL D3.5 (10 PCS.) 378647 ANVIL (S) 378646 HAMMER 959148 STEEL BALL D3.175 (10 PCS.) 315978 WASHER (J) 335316 HAMMER SPRING (J) 316172 WASHER (S)
