Table 10: Key '4' Display In Credit Mode - Secure Liberty 100 Technical Reference Manual

Followed by value
Press key 4 to return to the 1
Press key B to scroll back up the display list.
No key press at the end of this display sequence will
cause the auto-cycle display to resume.
Key 5: No function allocated
For credit mode no functions are allocated to this key. A short press will display 'Not Used' as shown below:
Key 6: Tariff name, active rate register, tariff rates and costs
A short press of key '6' will initiate the associated display sequence. After each set of information comprising a
title followed by its data, either a four (4) seconds wait or short press of the key will advance the display to the
next set of information as described below.
Title 1: Tariff name
Followed by value
Press key 6 to advance to the next display
Title 2: Active rate register
Followed by value
Page 60 of 116 Liberty 100 Smart Electricity Meter Technical Reference Manual
st
display.

Table 10: Key '4' display in Credit mode

The 1
indicating the currently active tariff name.
The example shows that 'Green 20' is the name of
(timeout 2 secs)
the currently active tariff.
(timeout 4 secs)
The 2
applicable.
The example shows that IMP R01 is the active import
(timeout 2 secs)
TOU rate register.
In the case of a hybrid tariff the active import hybrid
st
set of displays associated with key 6
nd
set displays the active rate register currently
BGX501-767-R02
