- Page 1 BY-P11 LED Fresnel Light 300W CW Or WW LED Fresnel Light (Auto zoom 15-50°) User manual Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Technical Specifications ............3-4 2. Description .................4 3. Unpacking ................5-6 4. Menu...................6-9 5. DMX Channels.................9-10 6. Photographic Charts..............10-11 7. LUX Date..................11 8. Size...................12 9. Fixture Cleaning ................13 10. Warning ..................13 Statement It is a powerful LED Fresnel which using a 300W LED COB. A massive zoom range of 15°... -
Page 3: Technical Specifications
by DMX512 controller. Enjoy the benefits of LED lighting without being held back by previous investments made in major dimming systems! 1. Technical Specifications Light Source: LED POWER: 300W or Warm White 3200K (300W) COB LED Cool White 5600K Led Lamp: Imported LED Color Rendering Index(CRI): Ra≥90 LED Life Time: over 50,000 hours Power supply:... -
Page 4: Description
Manual zoom: 1/3CH Working Environment : Environment Temperature: -30°C~40°C Cooling system : No noise fan of Pccooler IP Grade: IP20 Package : Dimensions: 397(D)*211(W)*378(H)mm Net weight: 8.5kgs Gross weight: 11kgs Packing Size: 58x32.5x32cm (1pc/carton) 2. Descriptions ··Works perfectly on conventional dimmers or constant power with DMX ·Motorized zoom angle between 15°... -
Page 5: Unpacking
3. Unpacking Thank you for choosing our P11. For your own safety, please read this manual before installing the device. This manual covers the important information on installation and applications. Please install and operate the fixture with following instructions. Meanwhile, please keep this manual well for future needs. - Page 6 4. Menu Operations Menu Data Menu State Operative Mode DMX address DMX channel Mode...
-
Page 7: Menu
Speed of Dimmer No DMX signal Screen Savers Main Vice Menu Screen Rotation Menu Language switching Speed of Dimmer Manual mode System information Reset Restore the default settings Key Operation Vice Menu State Master/Slave Mode：Receive DMX signal from Operative Mode control console or host Press “ENTER”... - Page 8 Language Press”ENTER” twice, switch between Chinese switching and English Turn off Close without delay, fast on/off Dimmer 1 Speed 4 linear dimmer pattern：1~4 (the fastest and Dimmer 2 Dimmer slowest ) Dimmer 3 Dimmer 4 Press “ENTER” to Manual mode, Not receive Manual mode control signals System...
-
Page 9: Dmx Channels
NO.（Ver) Using of time Displays the total using time information Total using time Displays the time using of this Manual mode Option State Dimmer Speed of dimmer Press”ENTER”to edit. Change value by press Strobe 0~255 UP/DOWN, press “ENTER” to ensure . zoom Speed of zoom Special Instructions... -
Page 10: Photographic Charts
70~129 speed of dimmer 2 130~189 speed of dimmer 3 190~255 speed of dimmer 4 0~10 no strobe the speed of strobe (255 is 11~255 the fastest) 0-255 focus Speed of focus (0 is the 0-255 fastest) 2 CH Mode (Basic channel model) channel data Function... -
Page 11: Lux Date
7. LUX Date... -
Page 12: Size
8. Size Size of the fixture: 379 (D)*211(W)*378(H)mm... -
Page 13: Fixture Cleaning
9. Fixture Cleaning Before disconnecting the lighter or starting maintenance work, ensure that the power supply of the light is turned off to maintain the maximum brightness output of the light, and it can also prolong its service life. It is recommended to use high-quality professional glass cleaner and to clean it with cloth.
