Johnson & Starley ELJAN 4/SE User Instructions

Gas fired water heaters

IMPORTANT: STATUTE LAW DEFINES THAT ALL GAS APPLIANCES MUST BE INSTALLED AND

MAINTAINED BY COMPETENT PERSONS, (i.e. CORGI REGISTERED INSTALLERS) IN ACCORDANCE

WITH THE GAS SAFETY (INSTALLATION AND USE) REGULATIONS (CURRENT EDITION). FAILURE

TO COMPLY WITH THESE REGULATIONS MAY LEAD TO PROSECUTION.

THIS APPLIANCE HAS BEEN TESTED AND CERTIFIED FOR USE WITH NATURAL GAS.

ELJAN 4/SE is a gas fired appliance which provides domestic hot water and/or space heating when installed in a Johnson and

Starley HI-SPEC J25 or SCS25 MkI air heater. The water temperature is controlled automatically by an integral thermostat in the

appliance. In addition, ELJAN 4/SE can be electrically switched by the air heater time control.

Leave these instructions with the User or with the appliance

GAS FIRED WATER HEATERS

USER'S INSTRUCTIONS

WARNING: THIS APPLIANCE MUST BE EARTHED.

Temperature

control knob

OFF button

START

button

ELJAN 4/SE

Publication No. ZZ 601/4

November 1998

Ignition

button

Pilot

burner

viewing

port

Table of Contents

Need help?

Do you have a question about the ELJAN 4/SE and is the answer not in the manual?

Page 1 WARNING: THIS APPLIANCE MUST BE EARTHED. ELJAN 4/SE is a gas fired appliance which provides domestic hot water and/or space heating when installed in a Johnson and Starley HI-SPEC J25 or SCS25 MkI air heater. The water temperature is controlled automatically by an integral thermostat in the appliance.
Page 2 ZZ 601/4 TO LIGHT YOUR APPLIANCE TO STOP THE APPLIANCE: (a) For short periods: Turn the temperature WARNING: If the pilot light is extinguished either Control Knob to the ‘OFF’ position and where intentionally or otherwise, no attempt should be made applicable turn of the electrical supply to the to relight the gas until at least 3 minutes have elapsed.
