Launch TWC Series Manual page 46

LAUNCH
No.
903
Five-way reversing valve
904
Quick L end joint
905
Limit washer on swivel arm
906
Hexagon socket screw M10X16
907
Back swivel arm assembly
908
Quick three-way end joint
909
Adjustable silencer
910
Spring seat of back swivel arm
911
Spring on back swivel arm
912
Washer of spring seat
913
Spring washer
914
Hexagonal socket bolt M8X16
915
Washer 8
916
Small washer of roller
917
Roller
918
Slide board hood
919
Washer of back swivel arm
920
Washer of back swivel arm
921
Hexagonal socket screw M8X20
922
Washer on back swivel arm
923
Pin of back swivel arm
924
Sliding guide
925
Regulating chip of slider
926
Right slider
927
Cover of post
928
Inner hexagonal screw M6 X 10
929
Carriage
930
Roller arm assembly
931
Washer of roller
932
Hexagonal socket bolt M8X16
933
Post assembly
934
Hexagonal socket screw M12 X 30
935
Washer 12
936
Washer 12
937
Seat weldment
938
Seat board
939
Spring washer15
940
Post carriage weldment
941
Slide board weldment
942
Left slider
943
Spring washer
944
Pin on cylinder top
Description No.
945
Lifting cylinder assembly
946
Cylinder hood right carriage
947
Cross recessed pan head screws
948
Pin on bottom of cylinder
949
Hexagonal nut M20
950
Pressure board of slide board hood
951
Cylinder hood left carriage
952
Cylinder hood assembly
953
Cover of cylinder hood
954
Control box
955
Disk arm assembly
956
Handle of locking rod
957
Disk
958
Disk axis
959
Handle on locking bar
960
Nut
961
Washer of swivel arm
962
Pin of fore swivel arm
963
Hexagon socket screw M8 X 16
964
Press block
965
Screw
966
Fore swivel arm assembly
967
Cone arm
968
Washer of pressure bar
969
Cone
970
Washer 8
971
Right supplementary arm assembly
1001
Roller assembly
1002 Socket screw
1003
Fore swivel arm weldment
1004
Control box
1005
Adjustable muffler (metal)
1006
Manual reversing valve
1007
Quick L end joint (metal)
1008
Handle of locking rod
1009
Socket screw
1010
Limit washer of swivel arm
1011
Back swivel arm weldment
1012
Slide hood
1013
Left slider
1014
Sliding guide
1015
Regulating chip
45
Tyre Changer(TWC Series)
Description
