LAUNCH
No.
712
Cross recessed countersunk head
screws M6×16
*713
Cushion mat
714
Hexagon socket set screws with flat
point M12×12
715
Metal Mount/demount head
716
Mount/demount head mat
717
Hexagon socket set screws with flat
point M10×25
718
Piston of cylinder of tilting post
719
Horizontal arm
720
Rubber board
721
Hexagon bolt M8×16
722
Post weldment
723
Back locking board
724
Self-locking nuts M12
725
Pull-out piece spring
726
Hexagon socket screw M6×45
727
Lock cylinder cover
728
Lock cylinder body
729
Sealing mat
730
L Elbow coupling
731
Clamping cylinder assembly
732
Tilting post cylinder
733
Column bottom rotating shaft
734
Axle pin mat
735
Spring washer
736
Hexagon bolt M10×25
737
Nut M10
738
Hexagon Bolt M12×70
739
Front cover of tilting post cylinder
740
Tilting post cylinder body
741
Cylinder stay stud
742
Back cover of tilting post cylinder
743
Locking nut M8
744
Hexagon Bolt M12×120
745
Casing
746
Sleeve of shaft
747
Buffer block
748
Cushion mat 2
749
Cylinder piston lever
750
Cushion mat 1
Description
φ10
No.
751
Cushion base
752
Thin nut M12
*753
Slide
*754
Insert
755
Roller
756
Roller pin
801
Thread T connector
802
Thread connector
803
Muffler
804
Five-way valve body
*805
O Sealing ring φ11.8×4
806
Five-way valve casing
807
Hexagonal bolt M6×25
808
Locking nut M6
Cross recessed pan head screws
809
M4×35
810
Plain washer φ4
811
Nut M4
812
Cam hood
813
Tapping screw ST2.9×4.5
814
Cam body
815
Cam spring sheet
816
Steering switch cover
817
Motor power switch
Cross recessed pan head screws
818
M4×16
819
Transfer shift bar
820
Pedal support units
821
Reed type support
822
Pedal release spring
823
Reed type
824
Transfer shift connecting rod
825
Hexagon bolt M8×55
826
Cam connecting rod
827
Pedal casing
828
Locking nut M8
829
Transfer shift pedal
830
Five-way valve pedal
831
Pedal bearing
832
Pedal assembly
901
Roller assembly
902
Adjustable silencer
44
Tyre Changer(TWC Series)
