LAUNCH
.
No
428 Pulley of speed reducer
429 TWC-501 gear reducer assembly
430 Rotary pneumatic valve assembly
431 V Vee belt A-28'
432 Hexagon Bolt M8×25
433 Motor plain cushion
434A Motor pulley 60Hz
434B Motor pulley 50Hz
435 Plain key C8×30
436 Hexagon bolt M10×35
437 Motor cushion mat
438 Hexagonal bolt M8×80
439 Motor support
440A Motor ~230V/50Hz 1.1kw
440B Motor ~230V/60Hz 1.1kw
440C Motor ~220V/50Hz 1.1kw
440D Motor ~220V/60Hz 1.1kw
440E Motor ~110V/60Hz 1.1kw
440F Motor ~110V/50Hz 1.1kw
441 Nozzle of rotary valve
Capacitance
442A (110V/60Hz)
Capacitance
442B (220V/50Hz)
501 Thread tee joint
502 L Elbow coupling
503 Muffler
504 Pentagamma valve units
*505 O Sealing ring φ11.8×4
506 Pentagamma casing
507 Hexagon Bolt M6×25
508 Lock nut M6
Cross recessed pan head screws
509 M4×35
510 Plain washer φ4
511 Nut M4
512 Cam hood
513 Tapping screw ST2.9×4.5
514 Cam body
515 Cam spring sheet
516 Steering switch cover
517 Motor master switch
Description
125V/800μF
50V/200μF
No.
Cross recessed pan head screws
518 M4×16
519 Transfer shift bar
520 Pedal support units
521 Reed type support
522 Pedal release spring
523 Reed type
524 Transfer shift connecting rod
525 Hexagon bolt M8×55
526 Cam connecting rod
527 Pedal casing
528 Locking nut M8
529 Transfer shift pedal
530 Pentagamma valve pedal
531 Pedal bearing
532
Pedal assembly
601
Pedal mat
602
Hexagon socket screws M6×12
603
Hexagon socket screw M6×50
604
Side plate
605
Cabin
606
Power cable clip
607
Power cable
608
Rubber pad
609
Hexagon socket screw M8×25
610
Flat matφ8
611
Hexagon bolt M8×25
612
Spring washer, light type φ8
613 Nut M8
614 Hood
615 Pedal screen printing diagram
701
Cap
702
Return spring
703
Plain washer M6
704
Hexagonal column
705
Locking board
706
Lock cylinder
707
T coupling
708
Sleeve
709
Hexagon socket screw M6×35
710
Air compressing hose
711
Locking handle units
43
Tyre Changer(TWC Series)
Description
