  • Page 1 OTAG User Guide...

  • Page 2: Table Of Contents

    Technical Specifications ................49 Systems ....................... 10 Care Instructions ................... 50 Schematic Explanation ................. 12 Warranty Text ....................51 Use of OTAG385 ..................13 Warranty Form ....................52 Opening the Entry Door ................13 Using the Stairs..................... 13 CRAWLER Model: OTAG 385...

  • Page 3: Foreword

    * Certain countries may have legal requirements that affect the level of equipment. * CRAWLER continues its continuous product development efforts to provide a better experience. Features, designs and illustrations in the user manual are not binding. CRA WLER reserves the right to make changes without prior notice.

  • Page 4: Basic Warnings

    - Electrical inlets and outlets should be checked. and garage entrances. - Do not keep flammable and explosive materials in OTAG 385. - Make sure the diesel heater is off. - Make sure the lightning is off. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 5 - Make sure the fuel tank is full when using diesel heaters. - Provide external cleaning of OTAG 385 at regular intervals. - Make sure there are no mosquito nets or curtains left outside when upper awning is closed. CRAWLER Model: OTAG 385 Version: EN 1.00.422...

  • Page 6: Safety

    Sensitivity Immediately after the OTAG 385 is purchased, and sometimes after a long period of inactivity, a strong odor and/or chemical sensitivity may be experienced. It is not a fault of OTAG 385. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 7 - The appearance of these conditions can indicate a serious problem. When signs of excessive humidity and condensation appear on the OTAG 385 it is important to take action to minimize their effects. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 8 - In extremely humid conditions, using a dehumidifier may help. warm air to circulate around plumbing lines and fixtures. - Regular cleaning of mold, which is caused by frequent use of KMP190 and/or growing, is an important preventive measure. CRAWLER Model: OTAG 385 Version: EN 1.00.422...

  • Page 9: Hardware List

    - Storage Cabinets - Electrostatic Powder Coating (Cabinet and Interior Walls) - Compact Laminate Flooring - Ceramic Based Internal Heat Insulation Kitchen Area - Inner Storage Cabinets - Chrome Kitchen Countertops - Kitchen Ware Drawers CRAWLER Model: OTAG 385 Version: EN 1.00.422...

  • Page 10: Bathroom/ Toilet

    - Truma Duo Control Panel * Electrical/ Control Installation - Truma Gas Antifreeze * - Truma Gas Valve * - Truma Collision Sensor * - Crawler Smart Panel - Schmid Solar Panel 380W * - Gas Filter - Inverter 600W * - Gas Regulator...
  • Page 11 - Weaponry - Victron Energy 220 Ah Battery (Extra) - Neta Portable Satellite - Truma Aventa Compact Plus Ceiling Air Conditioner - Water Freeze Protection Unit - Front Land Winch 24 V (18000lb) CRAWLER Model: OTAG 385 Version: EN 1.00.422...

  • Page 12: Schematic Explanation

    Entrance Ladder Side Track Lights Side Horn Lamps Chrome Cylinder Locks Rear View Cover LED Outdoor Lighting Sleeping Area Roof Pop-up System with Openable Window Seating Area Roof Pop-up System with Openable Windows CRAWLER Model: OTAG 385 Version: EN 1.00.422...

  • Page 13: Use Of The Kitchen Area

    Bottom Lock; (3) Turn the vertical lower lock hub clockwise. (4) After the lock bolt is in, turn the key back to the vertical position and remove it. CRAWLER Model: OTAG 385 Version: EN 1.00.422...

  • Page 14: Use Of Living Area (Converting To Secondary Bedroom)

    Set the table horizontally to use the seating area. Raise the top awning. Turn the seating area into a bed area thanks to the iron bars in the middle of the seating area. CRAWLER Model: OTAG 385 Version: EN 1.00.422...

  • Page 15: Using The Inner Upper Awning

    Then move the awning to the desired position by attaching the hook part to the upper right mechanism of the awning. CRAWLER Model: OTAG 385 Version: EN 1.00.422...

  • Page 16: Refrigerator Usage

    Storage areas are planned according to the user's own needs. There are two drawers and two upper and two lower cabinets. 1. Power cord 2. Control housing 3. Control PCB 4. Built-in fan 5. Thermistor CRAWLER Model: OTAG 385 Version: EN 1.00.422...

  • Page 17: Battery/ Sink Usage

    What if the battery does not work? 21. Built-in lamp cover 22. By Bin (3x) 23. Lid slide box - Attention is paid to the water level indicator on the Crawler Smart Panel 24. Slide out or control panel. 25. Diameter (4x) and screw (4x) 26.

  • Page 18: Using The Cassette Toilet

    6. The unloading process is done by sliding and dismounting, thanks to the cover on the front left cabinet of caravan. 7. Do not forget to turn off the lock after emptying and cleaning. CRAWLER Model: OTAG 385 Version: EN 1.00.422...

  • Page 19: Crawler Smart Panel

    Crawler Smart Panel battery capacity, time and date adjustment menu, and the menu that provides Crawler Smart Panel is opened by pressing the physical unlock button at the access to the screen brightness controls. bottom of its screen once. Each time the physical button is pressed, the system is restarted.
  • Page 20 The Water Control menu is accessed by pressing the button with the "Water Drop” symbol on the main screen. When you enter the menu, a page appears as seen in the image below. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 21 If the caravan is not going to be used, it is recommended that the tanks be completely emptied and parked in winter, otherwise, there may be damage to the tanks due to freezing. CRAWLER Company is not responsible for malfunctions and damages that may occur due to freezing.
  • Page 22 As the amount of current drawn per minute increases, the remaining time decreases, and as the current drawn decreases, the remaining time increases. The electrical page is shown in the image below. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 23 In this case, the battery should be charged as soon as possible. If the battery charge at the critical energy level drops further, the battery may be damaged The sensor on the Crawler Smart Panel measures the atmospheric pressure completely by chemical degradation or its lifespan may be shortened. Devices instantly.

  • Page 24: Diesel Heater

    In order not to cause any damage due to splashing water while washing the vehicle, water should not be poured directly into the chimney. CRAWLER Model: OTAG 385 Version: EN 1.00.422...

  • Page 25: Truma Combi

    The water temperature depends on the selected operating mode and the heating power output. If the temperature at the FrostControl automatic safety/drain valve is about 3 degrees, the valve opens and the boiler empties. CRAWLER CRAWLER Model: OTAG 385 Model: OTAG 385 Version: EN 1.00.422...
  • Page 26 Have faults rectified immediately by qualified personnel. temperature depends on the selected operating mode and the heating power After flashing (misfire), have the device and the exhaust gas system checked output. by a specialist. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 27 8= Rotary/ push button 9= Back key With the rotary push button indicated with number 8, you can navigate between the menus on lines 3 and 4, make selections and make various settings. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 28 Press button 8 for more than 4 seconds to turn it off. Shutdown of the Truma preserved. CP plus VarioHeat control unit may be delayed by several minutes due to the internal subsequent operation of the heating or air conditioning system ("OFF" is displayed during this time period). CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 29 APP mode is turned off. and left. Click on button 8 to confirm the value. Changing the room temperature Select the room temperature setting icon in the menu line number 3 with the button number 8. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 30 Press button 8 to switch to the setting level. Bring the button number 8 to the desired setting level by turning it to the right and left. Click on button 8 to confirm the selection. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 31 When the Combi is switched on, the fan level selected in the previous heating operation is displayed in the 2nd status line of the room temperature setting. The default setting is "AUTO". CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 32 The hour is flashing when the screen is first turned on. Swipe left and right using button 8 and set the clock to the desired value. When the time reaches the desired value, confirm the time by clicking on the 8 button. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 33 Select energy type (HEATER only) For detailed information, see “Selecting the energy type”, page 19, select the energy type you want with the button number 8. Click on button 8 to confirm the selection. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 34 Press button 8 to switch to setting level. Example: Deactivate the timer with button 8. (OFF) Set room temperature 23 °C OFFSET= -1 °C Click on button 8 to confirm the selection. Nominal value for heater = 22 °C CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 35 Changing the backlight Standard setting: 24 hour mode. Changing the language Changing the backlighting of the Truma CP plus VarioHeat control unit in 10 Selection of the desired language (German, English, French, Italian). steps. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 36 230 V air conditioning systems and Truma E-Kit. Example: H 1.20.01–= Device; 1.20.01= Version number Resetting Select "RESET" with the 8 button. Click on button number 8. "PR SET" appears on the screen. Click on button 8 to confirm. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 37 The Truma CP plus VarioHeat CI-BUS control unit is only a special model fitted at the factory. Energy type indicator Energy type in heating operation e.g. gas (a) is displayed (see”Selecting the energy type“on page 19) CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 38 Fault In the event of a fault, the Truma CP plus VarioHeat control unit immediately switches to the "Warning / Fault" menu level and the fault code of the fault is displayed: CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 39 Click on button number 8. If the screen is in- mode tapping activates the backlight and the fault must be confirmed by tapping the screen again. If necessary, the relevant device will be restarted automatically. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 40 FrostControl is a non-electric safety / drain valve. When there is a danger of freezing, the boiler automatically empties the water in it via a drain port. When high pressure occurs in the system, pressure balancing is performed intermittently via the safety valve. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 41 This heating element heats the FrostControl to approx. 10 °C when the Truma Combi is on. The boiler can thus be filled after a short time, regardless of the temperature at the installation site. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 42 Turn on the power to the water pump (main switch or pump switch). a= Lever in "Operating– off" position b= Lever in "Operating– off" position c= Lever in "Drain" position d= Drain opening (outward from the vehicle floor) CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 43 900 W (3.9 A) or 1800 W (7.8 A) power set via the energy selection switch. The cable reel must be fully opened to prevent the power supply cable from overheating. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 44 The burner switches off when the water in the boiler reaches 60 °C. The device must remain in operation for at least 30 minutes and hot water should not be used. The residual heat in the heat exchanger heats the water up to 70 °C. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 45 12 V voltage supply is interrupted during operation or during replacing the fuse or power supply lines. the following operation, temperatures in the device may cause the overheating protection to trip. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 46 "Operation" and then press the rocker switch until it engages. drained even though the closed. / Check the hole for dirt (snowy, mud, safety/drain valve is open. ice, brushwood, etc.) and clean if necessary. CRAWLER Model: OTAG 385 Version: EN 1.00.422...
  • Page 47 Truma or the Truma control unit (e.g. Truma CP plus, Truma iNet Box) is not used only for Truma devices or for Truma approved devices. CRAWLER Model: OTAG 385 Version: EN 1.00.422...

  • Page 48: Technical Specifications

    Technical Specifications Body: Aluminum Insulation: Ceramic Based Internal Heat Insulation Cabin Length: 3,250 mm Structure: 3,850 mm Cabin Width: 2,350 mm Cabin Height: 1,900 mm TO BE ADDED! CRAWLER Model: OTAG 385 Version: EN 1.00.422...

  • Page 49: Care Instructions

    Sunlight After washing OTAG 385: Always check the brakes so that moisture and heat can cause permanent damage. Consult CRAWLER about this. and corrosion do not affect or damage the brake pads! Dry the OTAG 385 with a clean and soft cloth.
  • Page 50 Removing stains on fabric upholstery For soiled fabric upholstery, it is recommended to use a special cleaning agent, available from your CRAWLER dealer. Other chemicals may damage the fire resistance of the flooring. Never try to remove the stain by scraping or rubbing.

  • Page 51: Warranty Text

    3. Failures caused by the use of OTAG 385 contrary to the terms in the user manual are not covered by the warranty. 4. You can apply to CRAWLER for any problems that may arise regarding the Warranty Certificate. 5. If OTAG 385 fails within the warranty period, the time spent in repair is added to the warranty period.

  • Page 52: Warranty Form

    CRAWLER VENDOR’S; Title: Warranty Form Address: Phone: Company: Crawler Türkiye Invoice Date and No: Sign (Seal): HQ Address: Cumhuriyet Mahallesi, 23 Nisan Caddesi, No: 33 Çekmeköy / İstanbul TURKEY Phone: +90 (216) 606 17 51 E-mail: bilgi@crawler.com.tr VEHICLE OWNER’S; VEHICLE’S;...
