5. The Sensor Cable connect to the connector on the motherboard to match the orientation of the
arrow.
Sensor Cable connector.
6. Install the dust-proof bezel in reverse order of removal procedure of front bezel.
Caution:Be careful to do not pinch the sensor cable when attached
to the server dust-proof bezel.
7. Install the side cover by the reverse procedure of removing.
②
14
Connector for the
Sensor cable.
③Fix a screw
①
①Insert two tabs at the right of
dust-proof bezel
