Step 1: Attach 24mm T-bar bracket to AP with two M3*8 screws
Step 2: Slide T-bar bracket onto recessed T-bar and rotate AP clockwise to secure
Recessed T-Bar
DROP CEILING MOUNT
Using 24mm Recessed T-Bar Bracket
24mm T-Bar Bracket
M3*8 Screws: 2pcs
MOUNTING INSTRUCTIONS
poewit.com
WAP-1
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PoeWit WAP-1
Summary of Contents for PoeWit WAP-1
- Page 1 MOUNTING INSTRUCTIONS WAP-1 DROP CEILING MOUNT Using 24mm Recessed T-Bar Bracket Step 1: Attach 24mm T-bar bracket to AP with two M3*8 screws Step 2: Slide T-bar bracket onto recessed T-bar and rotate AP clockwise to secure 24mm T-Bar Bracket...
- Page 2 NOTE: To release, push in release clips on both sides of security bracket simultaneously and rotate AP counterclockwise. Hard Ceiling/Wall 32 mm I3*20 Self-Tapping Housing Bracket Screws: 2pcs Security Bracket M3*8 Screw: 2pcs Plastic Anchors: 2pcs 6.5mm (Depth:30mm) poewit.com PoEWit Technologies Inc. All Rights Reserved 2023.
