SO-LOW FDC nCOMPASS Instructions Manual

INSTRUCTIONS:
1.1 RANGE OF ENVIRONMENTAL CONDITIONS FOR WHICH
THIS EQUIPMENT IS DESIGNED
1. Indoor use.
2. Altitude up to 2000m.
3. Temperatures 15°C to 30°C ( 60°F TO 85°F )
4. Recommended humidity range of 30% to 90%.
5. Mains supply fluctuations up to -5% to +10% of the nominal voltage.
6.
Transient overvoltages typically present on the mains supply (overvoltage category II). Pollution
degree 1.
CAUTION! THIS FREEZER IS PROVIDED WITH AN INPUT CIRCUIT
PROTECTIVE DEVICE WHICH SHALL BE MAINTAINED AND SERVICED
BY QUALIFIED PERSONNEL ONLY.
FUSES OR BREAKERS USED INSIDE PROTECTIVE DEVICE
15A OR 20A 250V TIME DELAY
WARNING! UPLUG FREEZER BEFORE ANY TECHNICAL SERVICE IS
PREFORMED ON THE UNIT!
CAUTION! DO NOT POSITION EQUIPMENT SO IT IS DIFFICULT TO
DISCONNECT FROM THE POWER SUPPLY.
1.2 STARTING INSTRUCTIONS
1. Plug the freezer into the proper outlet with an adequate power supply.
2. Confirm the freezer has at least 6" of air space on each side, for air circulation.
3. Turn the refrigeration switch (located in back of unit) to the ON position (if applicable).
4. The compressor(s) will start to operate and pull down to the set point on the
temperature control.
5. When the freezer reaches the set point, the compressor(s) will cycle on and off to
maintain the set point desired by the user on the temperature control.
SINGLE STAGE FREEZER
