DTS DTS300 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DTS300
Specifications
Length:510mm
Width:115mm
Height:200mm
Main Rotor Diameter: 555mm
Weight:approximately 360g(Without Battery)
2086-4050
Brushless Motor
Before this model has being significantly changed to another new version, the parts, appearance and the existing version can be developed and
modified that would lead to a slight difference from the original design. DTS reserve ALL the Rights of change of parts and contents WITHOUT
specified notification.
25A Brushless Motor ESC
GWY2013
3-axis Gyro
.
Swash Servos*3(1.2kg cm,0.08s/60 )
.
Tail Servos*1(0.6kg cm,0.04s/60
GWY 6TL V2 2.4GHz
6-Channel Transmitter
11.1V 1200mAh 25C Li-polymer Battery
R
D T S
)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTS300 and is the answer not in the manual?

Questions and answers

Related Manuals for DTS DTS300

Summary of Contents for DTS DTS300

  • Page 1 Before this model has being significantly changed to another new version, the parts, appearance and the existing version can be developed and modified that would lead to a slight difference from the original design. DTS reserve ALL the Rights of change of parts and contents WITHOUT...

  • Page 2: Table Of Contents

    Foreword Thank you for choosing DTS's product. For better understand usage of DTS300 helicopter, please read this manual carefully before installation and operation. This can ensure proper usage and safe operation! For your convenience of adjustment, maintenance and other operation, please keep this manual in a proper manner.

  • Page 3: Statement

    5.Do Not re-equip, upgrade or repair your helicopter with the accessories outside the DTS parts catalog in order to ensure the safety of the model structure! 6.Keep people and objects away from the spinning unit and parts in case of damage or injury!

  • Page 4: Check Of Package's Parts And Accessories

    11.1 V, 1200 mAh Li-Po Battery Tool Pack Battery Bandage Package Box Content RFR with AH6 Radio System DTS 300 6TL - 2.4GHz 6-Channel Transmitter AH6T - 2.4GHz 6-Channel Transmitter GWY2013 - Receiver & Gyro G02 - Gyro AH6R - Receiver 2S &...

  • Page 5: Electronic Parts And Connection Procedure

    Electronic Parts and Connection Procedure Aileron Servo Pitch Servo Elevator Servo Receiver 3-axis Gyro Li-Po Battery Rudder Servo Brushless ESC Brushless Motor Receiver Connection Procedure Power Supply Plug Aux 02 Aux 01 Pitch Servo Plug Gyro Gain Signal Plug Gyro Rudder Plug Elevator Servo Plug Aileron Servo Plug Brushless ESC Plug...

  • Page 6: Pre-Flight Controls Test

    Pre-Flight Controls Test 1.Control Test: Throttle Push up the throttle stick slowly until the motor rotate. Make sure that the motor rotates clockwisely and the main blade rotates anti-clockwisely. Throttle Position: Right Throttle Position: Left Please don't push the throttle stick upward over 1/5. The motor will spins at high velocity if the throttle stick is over pushed.
  • Page 7 3.Control Test: Pitch (only aerobatics use) Swashplate's upward and Throttle Position: Right Throttle Position: Left downward movement 4.Control Test: Aileron (The rudder's control is the same in both Swashplate's Left and Right declining movement left and right-hand throttle transmitter) Rear View Rear View Rear View...
  • Page 8 5.Control Test: Rudder (The rudder's control is the same in both Tail rotor blades pitch change left and right-hand throttle transmitter) 6.Gyro adjustment Disconnect the connection between ESC and motor, turn on the power of the transmitter and helicopter, move the pushrod to check the sercos direction. 1.

  • Page 9: Flight Operation Procedure

    Flight Operation Procedure 1.Take Off Procedure Insert the battery to the battery notch Fix the battery's position with the bandage Mode1 Mode2 Adjust the antenna to the shown position. Pull the Connect helicopter's electricity throttle to the most downward position then switch on the transmitter.

  • Page 10: Main Blade Adjustment

    Blade tracking is an important step to affect the flight performance. Main rotor blades that are out of track may cause vibration and instability. Although the main rotor blades of each DTS 300 models are tracked at the factory, minor adjustment to blade tracking may be required after blade changes.

  • Page 11: Tail Drive Belt Adjustment

    Tail Drive Belt Adjustment Loosen Belt is one of the reason for tail-lock fail besides gyro setting. Adjust by following the above: Loosen the screws that mounting the tail boom to the main frame, then pull the tail boom backward. Pay attention to the belt's elasticity.

  • Page 12: Main Rotor Head And Gears Assemble Procedure

    Main Rotor Head and Gears Assemble Procedure Pay attention to the install-position of the Thrust Bearing Main Shaft Blade Grip Washer (3.5mm* 3mm * 8mm)x2 ( 3mm*38.2mm*M2)x1 Hexagon Socket Head Screw (0.10mm* 5mm * 8mm) Washer (M2*6mm) (0.1mm* 3.1mm* 5.6mm) Blade Grip Control Arm Bushing Hexagon Socket Head Screw...

  • Page 13: Main Frame And Tail Boom Assemble Procedure

    Main Frame and Tail Boom Assemble Procedure Washer head Phillips screw Washer head Phillips screw (M2*6mm)x2 (M2*8mm)x4 254mm Washer head Phillips screw 200mm (M2*6mm) Linkage Ball 7.5g SERVOx1 (M2* 2mm*0.4mm)x1 (S 4.0mm*6.5mm*2.9mm)x4 (M2* 2mm*0.4mm) Flat Fillister Head Flat Fillister Head Phillips Screw Phillips Screw Linkage Ball...

  • Page 14: Tail Rotor Assemble Procedure

    Tail Rotor Assemble Procedure CAUTION Paste necessary lubricant Apply a little amount of T43 thread lock on the thrust bearing when fixing a metal part. Bladex2 Washer Bearing Please confirm that the screw is fastened (0.1mm* 5mm * 6mm) (2.5mm* 3mm * 6mm) tightly before use.

  • Page 15: Power System Assemble Procedure

    Power System Assemble Procedure Washer head Phillips screw Washer head Phillips screw (M2*6mm)x2 (M2*8mm)x4 Linkage Ball Linkage Ball (S 4.0mm*6.5mm*L2.9mm) 7.5g SERVO x3 (S 4.0mm*6.5mm*2.9mm)x3 (M2* 2mm*0.4mm) Hexagon Socket Head Bolt Nylon insert lock nut Flat Fillister Head ( 2mm*2.8mm)x4 (M2*14mm)x2 Phillips Screw (M1.7*4mm)x5...

  • Page 16: Exploded View

    Exploded View...
  • Page 17 Parts List Description Quantity Specification Description Quantity Specification Main Blade 254*28*4 M2*6 Washer Head Phillips Screw M2*6 Main Frame Right Hexagon Socket Head Screw 2* 5*0.5 Main Frame, Left Washer 3.0* 8*3.5 Thrust Bearing Hexagon Pan Head Screw M3*10 5* 8*0.1 Stabilizer Washer 3* 6*2.5...

  • Page 18: Parts List

    Parts List DTS006324 DTS004495 DTS004035 DTS004494 Main Blade Set Main Blade Grip Set Main Blade Spindle Set Main Blade Fix Screw Set DTS004036 DTS004037 DTS004038 DTS003922 Main Rotor Head Set Hiller Control Arm Set Push rod Set Main Shaft Set DTS004039 DTS004094 DTS003925...
  • Page 19 DTS003932 DTS004040 DTS004041 DTS003935 Tail Rotor Pitch Control Fork Set Tail Case Set Vertical & horizontal tail blade set Tail Rotor Hub DTS003936 DTS004042 DTS004043 DTS004044 Tail Blade Grip Rear stay bar Tail Blade Tail Rotor Spindle DTS004045 DTS003939 DTS004122 DTS004126 O-ring Tail Drive Belt...
  • Page 20 DTS003950 GWY003914 GWY003746 DTS003951 11.1V 1200mAh KV 4050 Li-Polymer Battery Swash Servo Brushless Motor 25A Brushless Motor ESC GWY003770 GWY003751 GWY004011 GWY003752 3.7V 1100mAh 2&3 Li-Po Battery of Transmitter 5A Charger Charger Wire Connection Wire GWY004540 GWY003768 GWY005451 GWY004716 High Frequency Transmission LCD Setting Module GWY 6TL\V2 2.4G GWY2013...
  • Page 21 DTS300 D T S 510mm GWY2013 115mm *3pcs 1.2kg cm 0.08s/60 200mm *1pcs 0.6kg cm 0.04s/60 555m m GWY 6TL V2 2.4GHz 360g( 11.1V 1200mAh 25C 2086-4050...
  • Page 22 DTS300 www.zondahobby.com...
  • Page 23 :-10 50 )
  • Page 24 2.6TL V2 2.4G 3.2-3 4.SD 5.11.1V 1200mAh DTS 300 6TL - 2.4GHz 6 AH6T - 2.4GHz 6 GWY2013 - G02 - AH6R - 2S & 3 S : 1200mAh 3S1P 11.1V Ec3...
  • Page 25 GWY2013...
  • Page 29 Mode1 Mode2...
  • Page 31 ( 1) ( 2) 1/3 )( 3), ( 4)
  • Page 32 (3.5mm* 3mm * 8mm)x2 (0.10mm* 5mm * 8mm) ( 3mm*38.2mm*M2) X1 ( M2*6) (0.1mm* 3.1mm* 5.6mm) ( 3mm* 4.5mm*1.3mm) ( M2*6) x2 ( 3mm*38.2mm*M2) (0.55mm* 3mm * 5.5mm)x2 (0.5mm* 2mm * 5mm) (3.5mm* 3mm * 8mm) (0.5mm* 2mm * 5mm) x4 (0.1mm* 3.1mm* 5.6mm)x3 (2.5mm* 3mm * 6mm) (0.55mm* 3mm * 5.5mm)
  • Page 33 (M2*6mm)x2 (M2*8mm)x4 (M2*6mm) 7.5 g (M2* 2mm*0.4mm)x1 (S 4.0*6.5*2.9) x4 254mm (M2*4mm*1.6 mm) 200mm (M1.4*5mm)x2 (M1.7*4mm)x1 ( S 4.0*6.5 mm*2.9 mm) (M2*8mm) (M1.7*4mm) (C10*287mm) (M1.4*5mm) (2.5mm* 2mm* 5mm)x2 (M1.7*4mm)x2 ( 8.2mm* 4.3mm) x2 (M2*8) x2 ( 2mm*2.8mm)x4 ( 8.2mm* 4.3mm) ( M3*10mm) (R360MXL 2.5)x1 (2.5mm* 2mm* 5mm)
  • Page 34 (0.1mm* 5mm * 6mm) (2.5mm* 3mm * 6mm) ( 2.5mm* 2mm*3.2mm) M2 *12 ( M2 *10 ( 3mm* 4.5mm*1.6mm) (0.5mm* 2mm * 5mm) (2.5mm* 3mm * 6mm) ( 2mm*2.8mm)x4 ( 2.5mm* 2mm*3.2mm)x2 ( 3mm* 4.5mm*1.6mm)x2 (2.5mm* 3mm * 6mm) x2 (M2 *10 ) x2 (S 4mm*L2.5mm*7.5 mm)
  • Page 35 ( S 4.0*6.5*2.9) x3 (S 4.0*6.5*2.9) x3 7.5 g (M2* 2mm*0.4mm)x3 (M2*6mm)x2 (M2*8mm)x4 (M1.7*4mm)x5 ( 2mm*2.8mm)x4 (M1.7*4mm) ( M2*14mm (M2* 2mm*0.4mm)x3 ( M2 *16mm) x1 (M2 *12mm) x2 ( M2*4mm) ( M2*6) x2 ( M2*14mm (M2*8mm) ( 2mm*2.8mm) ( 2mm*2.8mm) ( M2 *12mm) ( M2 *16mm) 11.
  • Page 37 254*28*4 M2*6 M2*6 2* 5*0.5 3.0* 8*3.5 M3*10 5* 8*0.1 3* 6*2.5 M1.7*9 M2*12 M2*14 M1.7*6 7.5 g 3.0* 4.5*1.3 1.6*38*20 3.0* 5.5*0.55 3.1* 5.6*0.1 2.9* 6*3 3*38.2 M2*8 2.5* 2*3.2 M2*4 34.5*26.4*3 20*15*1 M2*10 2* 3.8*0.4 11.1V 1200mAh 2* 5*2.5 160*14 20.5*6.5*3.8 9* 10*287...
  • Page 38 DTS006324 DTS004495 DTS004035 DTS004494 DTS004036 DTS004037 DTS004038 DTS003922 DTS004039 DTS004094 DTS003925 DTS003929 DTS003926 DTS003969 DTS003927 DTS004095 DTS004097 DTS004099 DTS004102 DTS003928 DTS004105 DTS004110 DTS003930 DTS003931...
  • Page 39 DTS003932 DTS004040 DTS004041 DTS003935 DTS003936 DTS004042 DTS004043 DTS004044 DTS004045 DTS003939 DTS004122 DTS004126 DTS004127 DTS004129 DTS004130 DTS004048 5 2.5 7 2.5 DTS003940 DTS003941 DTS003942 DTS004046 8 3.5 DTS004047 DTS004050 DTS004049 GWY003721...
  • Page 40 DTS003950 GWY003914 GWY003746 DTS003951 11.1V 1200mAh KV 4050 GWY003770 GWY003751 GWY004011 GWY003752 3.7V 1100mAh 2&3 GWY004540 GWY003768 GWY005451 GWY004716 GWY2013 GWY6TL 2.4GHz 6 GWY003315 GWY004718 GWY006195 GWY006228 GWY6TL 2.4GHz AH6R GWY006227 DTS004034 AH6T 2.4GHz 6...
  • Page 41 Global Distribution Office Zonda Hobby Technologies Electronic Ltd Workshop No.1, 1st Floor, Kam Hon Industrial Building, No.8 Wang Kwun Road, Kowloon Bay, Kowloon, Hong Kong Tel : 852-3160 8886 Fax : 852-3160 8884 Email: Michael@zondahobby.com, Jason@zondahobby.com Official Website: www.zondahobby.com...
