- Page 1 Titan Inclined Platform Lift Installation Guide Residential and Commercial Please read this installation guide carefully to ensure correct installation of your Titan Inclined Platform Lift.
-
Page 2: Table Of Contents
Table of Contents Disclaimers and Important Information ..........................Before you Get Started - Checklist ............................Staircase Blueprint ..................................Installing Your Titan Inclined Platform Lift ..........................Step 1: Unboxing ................................Step 2: Create Jig for the Rails ............................Step 3: Rail Installation .............................. - Page 3 Prepare Your Tool Bag 1/4’’ Drive Hex Bits Philips - (PH2) (PH3) Electrical Tools Square - (#2) Extension Tester - AC/DC Clamp On Power Meter (100 A dc Min) Adapter - 1/4’’ Hex Shank to 3/8’’ socket Square drive Impact Driver - 1/4’’ Hex Drive Impact Driver Drill - 1/2’’...
- Page 4 Hand Tools 1/2’’ Drive Hex Deep Socket Hammer - 16 Oz. Min hammer Hexagon - (9/16’’) (3/4’’) Pry Bar Rubber Mallet - 16 Oz. Min Rubber head mallet Utility Knife - Snap Off Utility Knife Drill Bits and Taps 25mm Blade Drill Bits - (9/64’’) (5/32’’) (13/64’’) Tape Measure - 16’...
- Page 5 This guide describes how to install the AmeriGlide Titan Inclined Platform Lift. The AmeriGlide Titan Model offers a smoother and more stable ride due to it’s unique c-shaped rail system design. The platform fits most staircases and can be folded when not in use. Additionally, it doesn’t require a mechanical room - everything fits into the sleek and slim upper landing column.
-
Page 6: Disclaimers And Important Information
AmeriGlide, Inc. shall not be held responsible or liable for any personal injury or property damage caused by or resulting from inappropriate operation of original product or of a product that has been modified or altered from the original Titan Inclined Platform Lift (IPL) design. - Page 7 Installation Disclaimer The AmeriGlide Titan Inclined Platform Lift shall be installed and serviced only by an authorized AmeriGlide dealer only. The authorized dealer should refer to this guide for installation and servicing. For Care & Troubleshooting, please refer to the Titan Inclined Platform Lift Owner’s Manual.
- Page 8 NOTE: Failure to comply the these Installation Safety Instructions could render the AmeriGlide Limited Warranty null and void. If you have any question or concerns that are not covered in this installation guide, please contact your dealer immediately.
- Page 9 Site Requirements The Titan must be installed on a Supporting Wall, Supporting Posts and Floor that is capable of supporting the minimum load and standards as laid out in the Technical Drawings. Please refer to and verify with the Technical Drawings before beginning the installation of the Titan.
-
Page 10: Before You Get Started - Checklist
1. Understand your client’s intended use of the lift. 2. Determine the local code and regulations requirements. 3. Upon receipt of the Titan Inclined Platform Lift, verify the lift for shipping damage immediately. Report any discrepancies or damage claims to your dealer. -
Page 11: Installing Your Titan Inclined Platform Lift
Installing Your Titan Inclined Platform Lift Step 1: Unboxing • Remove box cover. • Inspect for damage (ie. take damaged photos) • Remove boxes and cabin parts and set them aside. Step 2: Create Jig for the Rails TIP: Use a plywood to cut a jig to sit on the top of the staircase to make ensure your bottom rail is located as per measurement A of your installation drawings. -
Page 12: Step 3: Rail Installation
Step 3: Rail Installation Procedure 1a. Lower section of the bottom rail installation • Referring to the measurement (A) from 1 of 2 in the installation drawings • Use the plywood jig to sit on the top of the staircase. (Plywood width = measurement (A)) •... -
Page 13: Step 4: Tower Installation
1c. Upper section of the top rail installation • Install the top section of the top rail parallel with the bottom rail. It must finish equal with the lower rail. - Top and bottom rails must be PARALLEL and have 18” between. - Top rail must finish aligned with the lower at the upper landing to receive the tower 90º... -
Page 14: Step 6: Lower Platform Floor
Step 6: Lower Platform Floor Procedure ATTENTION: DO NOT manually open. 1. Stick the 8x adhesive flint pads on to the underpan. (11) • Locate loose wire behind the carriage (floor motor leads) • Bring voltage to these wires to lower floor (tip: use one of the batteries to do it) •... -
Page 15: Step 8: Cab Installation
Step 8: Cab Installation Procedure 1a. Emergency Stop Button in Cab • The stop button needs to be bypassed for installer to set panel cover aside to not damage it. • Install jumper wire from CN21-5 and CN21-6 to install the two red wires from the stop button). 1b. - Page 16 1d. Connecting Batteries • Wire the 2 batteries in series for 24vdc. 1e. Start Up Conditions • Start up conditions are performed with 2 safety bypasses the brake switch and cab emergency stop button. (BS) and (ESC). • Perform the start up conditions test. Verify voltages from start up points they must all have at least 24v.
-
Page 17: Step 9: Landing Switch Adjustment
1g. Lower chain with call button once start-up conditions are met. 1h. Once the chain is lowered, attach it to the top wheel assembly and slightly lift cabin off the floor. Step 9: Landing Switch Adjustment Procedure 1a. Adjusting landing switches •... -
Page 18: Step 10: Arms And Flaps Adjustment
1c. Upper Landing • Lift must only stop on the upper landing switch. • The platform should be level with the top landing floor or just above. • Engage the upper switch with the cam to stop platform. 1d. Once upper landing SET, add the mechanical stop on the upper rail 2” above the upper wheel assembly. •... -
Page 19: Step 11: Floor Adjustments
Step 11: Floor Adjustments... -
Page 20: Step 12: Reinstall Covers
Step 12: Reinstall Covers Procedure 1. Mount Upper Tower and Carriage Covers • Mount the upper tower cover and the two carriage covers the #10-24 screws from steps 5 and 6 respectively. • Remove all Philips-head screws holding cover and remove it for the tower. Step 13: Emergency Lowering Device Procedure Recovery Mode... -
Page 21: Before Leaving The Job Site
Before Leaving the Job Site Procedure 1. Clean the work site. 2. Make sure all hardware has been tightened to specifications. 3. Explain and demonstrate the safe operation of the lift and emergency procedures to the operator / owner. 4. Assist the operator / owner on an orientation ride. 5. - Page 22 5110 Atlantic Ave. Raleigh, NC 27616 AmeriGlide.com...
