Linea Underwater MK3
Code / Codice
Power consumption
Consumo di energia
Power supply
Alimentazione elettrica
Electrical class
Classe elettrica
Weight / Peso
Operating temperature*
Temperatura di funzionamento*
IP rating / Grado IP
IK rating / Grado IK
*WARNING ! The product must only be operated under water and must be protected against freezing in!
*ATTENZIONE ! Il proiettore va utilizzato solo sott'acqua e dev'essere protetto dal rischio di congelamento!
40°
Size / Dimensioni
Micro Waterled MK3
155
6.10"
Waterled MK3
255
10.04"
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goffredo
Mantova - Italy
Micro Waterled MK3 Mini Waterled MK3
AL8365
9W - RGBW
9W - DW/W
2.3 Kg / 5.1 lb
66.2
2.61"
89.45
3.30"
Tel. +39.0376.779483
© Copyright Griven 2018 - Griven reserves the right to make
changes to this product and related instructions at any time
E-mail: sales@griven.com
without prior notice and such changes shall be effective
Web: www.griven.com
immediatly
User Manual
Rev. 5.00
Date: 31/01/2023
AL8369
25W - RGBW
25W - DW/W
24 Vdc
III
3.7 Kg / 8.2 lb
ta max = 50° C / ta max = 122° F
IP68 (-3
IK10
Mini Waterled MK3
Maxi Waterled MK3
.
551163
Waterled MK3
Maxi Waterled MK3
AL8373
39W - RGBW
48W - DW/W
4.9 Kg / 10.8 lb
)
M
215
8.46"
298
11.73"
AL8377
65W - RGBW
86W - DW/W
6.0 Kg / 13.23 lb
89.45
3.30"
89.45
3.30"
page 1 of 7
