Technical data
3.1 Flexible connecting cables
Technical specifications
Attenuation
Resistance to fire
Fire prevention
Standard for fire behavior
Smoke emission
Flame resistance
Toxic gas emission
Dimensions, materials and weight
Number of plug-in connections
Outer diameter
Materials
Degree of protection
Silicone-free
Halogen-free
UV resistant
Weight
Permitted ambient conditions
Ambient temperature
Mechanical data
Smallest bend radi‐
us
Number of bending cycles
Tensile strength
(1) The specified attenuation values relate only to the cable without connectors. For the assembled cable,
approximately 0.1 dB at 2.4 GHz and approximately 0.3 dB at 5 GHz must be added per plug-in connector.
32
at 2.4 GHz
(1)
at 5.1 GHz
at 5.7 GHz
Inner conductor
Dielectric
Cable jacket
when bending once
when bending more
than once
0.47 dB/m
0.77 dB/m
0.83 dB/m
According to DIN 5510-2, NF F 16-101
EN 61034-2
EN 60332-1-2, IEC 60332-3-22, EN 50305,9.1.2
NF-X 70-100
2
5.5 mm
• Silver-coated copper
• Diameter: 1.4 mm
• SPEX
• Diameter: 3.8 mm
• RADOX, black
• Diameter: 5.5 mm
IP67
yes
yes
resistant
47.8 kg/km
-30 °C ... +100 °C
2.5 cm
9 cm
50
30 ... 80 N
