- Page 1 ZP787-3 Addressable Outdoor Manual Call Point Installation Sheet © 2022 Carrier. All rights reserved. 1 / 4 P/N 20-8030-501-2103-08 • ISS 13JUN22 D1073-5...
- Page 2 Figures Description Figure 1: Product illustration The ZP787-3 Addressable Outdoor Manual Call Point (MCP) is used to manually initiate a fire alarm. It is designed for outdoor Figure 2: Wiring diagram use and features an IP67 enclosure. (1) Loop + IN (4) Loop −...
- Page 3 Maintenance To install the MCP, follow these general steps. Set the device address Figure 5, item 1 illustrates how to perform a test and reset for the device. Use the supplied test key to perform routine testing Install the backbox without breaking the glass element.
- Page 4 Product identification See model number on product identification label Intended use See the product Declaration of Performance Declared performance/s See the product Declaration of Performance 2012/19/EU (WEEE Directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union.
