Lightwave Link Plus L2 Quick Start Manual page 3

2
Setting up the Link Plus
2.1 Attach the Ethernet cable
Link Plus indicator light
Take the Ethernet cable (supplied) and connect it to
The LED indicator is used to indicate the status of the
any spare available LAN port on your wireless router. Link Plus and also to indicate if there is a connection
Connect the other end of the cable to the Lightwave
problem (see list on the right).
Link Plus' single port.
Connectivity issues
A solid red LED indicates that there is no connection
to the server. Check that the Ethernet cable is securely
connected to a spare Ethernet port on your Wifi router.
If the red LED persists, please contact tech support on
0121 250 3625 or at www.lightwaverf.com.
Firmware updates
Firmware updates are over the air software improvements
that keep your device up to date as well as providing new
features. Updates generally take 2-5 minutes. The LED
will flash amber whilst new firmware is being downloaded
and solid white during installation. It is important not to
2.2 Attach the power supply
remove power to the device during this time.
Plug in the power supply and push the Micro USB
Changing the colour of the indicator LED
connector into the socket on the back of the Link Plus.
The Link Plus will now enter its startup sequence and
The colour of the LED indicator light on the Link Plus
will attempt to find a connection to the Lightwave
can be personalised or the LED dimmed using the
server. A solid amber light indicates that a connection is
Lightwave App. See the App for more details.
being attempted, and a solid green light will show once
a connection has been established. Once the green
light appears, the Link Plus is ready to be set up on the
Lightwave Link Plus App.
LED Indicator lights
Steady green (or personalised colour):
Status normal Cannot contact server
Flashing green:
Transmitting Device restarting/updating
Flashing green / amber:
Linking mode Firmware installing (do not remove power)
Need some help?
support@lightwaverf.com www.lightwaverf.com
3.1 Download & open the App
Download the Lightwave Link Plus App from the
App Store. Open the App and follow the instructions
Steady red: and tutorials which will take you through the setup
procedure.
You can also use the Lightwave Web App to set up and
control your Link Plus. This is a more extensive platform
very suited to setting up and viewing large installs. This
can be accessed at www.lightwaverf.com.
Flashing amber:
3.2 Follow the in-app instructions
Once your Link Plus is set up, you will be able to register
Solid white:
multiple smartphones or tablets to control any number
of Lightwave devices in your home.
+44 (0)121 250 3625
3
Setting up the App
HomeKit
You will also be able to control Lightwave devices via
HomeKit using the code below. To do this, open the
Home app on your iPhone or iPad, select the Link Plus
and manually enter the code.
Communication between iPhone, iPad, or iPod
touch and the HomeKit-enabled Link Plus is secured
by HomeKit technology. Controlling this HomeKit
enabled accessory automatically and away from home
requires an Apple TV with tvOS 10.3.2 or later or an
iPad with iOS 10.3.2 or later set up as a home hub.
Apple, iPhone, iPad and iPod touch are trademarks of
Apple Inc., registered in the U.S. and other countries.
HomeKit is a trademark of Apple Inc.
xx-xx-xx-xx
