TECHNICAL DATA
Battery type
Rated capacity of battery pack
Rated voltage of battery pack
Maximum charging voltage
Minimum discharge voltage
Rated charge/discharge current
Maximum charge/discharge current
Charging temperature range
Discharge temperature range
Depth of discharge
Discharge magnification
Self-discharge (25°C)
Cycle life
Interactive mode (APP)
Dimension
Weight
Compatible with Solar Inverter [VT-66036103, VT-6605103, VT-12040]
Thank you for selecting and buying V-TAC Product. V-TAC will serve you
the best. Please read these instructions carefully & keep this user manual
handy for future reference. If you have any another query, please contact
our dealer or local vendor from whom you have purchased the product.
They are trained and ready to serve you at the best.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
INSTRUCTION MANUAL
BATTERY STORAGE
0 to +45°C
-20°C to +50°C
＜3%/Month
＞5000 times（＜0.5C）
LCD+Button+Bluetooth
700*515*250mm
(Error±2mm)
About 65KG
INTRODUCTION
Multi-Language Manual QR CODE
Please scan the QR code to access the manual
in multiple languages.
LFP
200Ah
51.2V
57.6V
40V
100A
120A
＞80%
＜1C
Advertisement
Table of Contents
Related Manuals for V-TAC VT-10240
Summary of Contents for V-TAC VT-10240
- Page 1 Please scan the QR code to access the manual in multiple languages. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B...
-
Page 2: Control Panel
WARNING 1. Please make sure to turn off the power before starting the installation. 2. Installation must be performed by a qualified electrician. This marking indicates that this Caution, risk of product should not be disposed electric shock. of with other household wastes. CONTROL PANEL POWER BUTTON UP BUTTON... - Page 3 HUMAN-COMPUTER INTERACTION CONTENT Project Functi on There are 6 display interfaces in total: 1. Main interface information (voltage/current/SOC/status code); 2. Secondary main interface information (maximum and minimum cell voltage/maximum and minimum temperature); 3. Display 1~4cell voltage; 4. Display 5~8cell voltage; 5.
-
Page 4: Interface Definition
INTERFACE DEFINITION Port Port type NO Signal name Remark BAT+ Battery positive output interface Battery output interface BAT- Battery negative output interface Battery output switch (control Battery output switch Battery positive) CAN-H CAN bus high level CAN-L CAN bus low level null null 485-A... -
Page 5: Installation
Port Port type NO Signal name Remark Dry contact 1 Dry contact 1 (3.81 3P COM1 Dry contact 1public Terminal Phoenix Terminal) Dry contact 1 normally closed Terminal Dry contact 2 normally open Terminal Dry contact 2 (3.81 3P COM2 Dry contact 2 public Terminal Phoenix Terminal) Dry contact 2 normally closed... -
Page 6: App Installation
APP INSTALLATION For ANDROID For IOS Step 1: Scan the given QR code to download App then install the app. Step 2: A�er the installa�on is complete, open the phone se�ngs - applica�on se�ngs - authoriza�on management, and authorize the Bluetooth and posi�oning of this APP. - Page 7 Step 5: A�er successfully pairing the device with the app, you can start reading the relevant data, including "CONNECTION, DEVICE INFO, LIVE DATA, HISTORY INFO, WARNING INFO, CONTACT" to switch (See the below pic).
