Hornady SnapSafe 75413 Owner's Manual

Installation (CON'T)
1. When choosing an installation location, use an interior wall that is free of
all hidden obstructions.
2. Use a stud finder to locate the two wall studs the safe will be installed
between. Use a pencil to mark the inside edge of each stud and confirm
there is 14.5" between each stud.
3. Mark the intended location for the bottom of the safe on one of the studs.
To mark the top edge of the safe, measure up 20" for the standard In-Wall
Safe (75413), or 42" for the In-Wall Safe Tall (75414). Use a level to mark
the top and bottom cut line between the two studs.
4. Using a drywall saw, cut along the top and bottom cut lines until
reaching each stud.
5. Using a level, mark the vertical cut lines along the inside edge of each
stud. Cut along the vertical cut lines to remove the drywall section.
6. Slide the In-Wall Safe into the opening.
7. Open the safe to expose the mounting holes (5 on the 75413, and 8 on
the 75414 safes). Using a 1/4" drill bit, pre-drill through the stud in each
hole location.
8. Place a washer and lag screw into each mounting hole and tighten.
NOTE: Do not over-tighten lag screws as it may distort the housing and
affect operation.
9. Shelves may be installed by first placing the shelf tab into the latch side
of the safe, then setting the other end on the shelf bracket along the
hinge side of the safe.
10. Install floor mat and other accessories. The picture frame hook can be
placed over the top edge of the safe and used to hang a picture or other
object in front of the safe (up to 8 pounds).

KEYPAD TONES ON/OFF

Press and hold the "1" button for three seconds to toggle sound ON
and OFF.
Note: Toggling the sound off will turn off the keypad, program, and alarm
beeps. Toggling the sound on will turn on the keypad, program, and
alarm beeps.

LOW BATTERY WARNING

If the batteries become weak, the keypad will remain red during operation.
Replace batteries immediately to ensure proper operation of the safe.
SnapSafe Customer Service: PO Box 1848, Grand Island, NE 68802-1848
1-877-214-4470 | Email: info@snapsafe.com
21SNAP0034
In-Wall Safe
Item No. 75413
Ext. Dimensions: 22.0" H x 16.25" W x 4.0" D
Int. Dimensions: 19.7" H x 11.8" W x 3.6" D
Weight: 36 Lbs
Power: 4 AA batteries (not included)
REV1 12/2021
Owner's Manual
Item No. 75413
Register your product to receive
the full benefit of its warranty.
https://www.snapsafe.com/warranty
In-Wall Safes
In-Wall Safe Tall
Item No. 75414
Ext. Dimensions: 44.0" H x 16.25" W x 4.0" D
Int. Dimensions: 41.6" H x 11.8" W x 3.6" D
Weight: 63 Lbs
Power: 4 AA batteries (not included)
Item No.
75414
