Tatu Marchesan GCRO 7010 Operator's Manual

Hide thumbs Also See for GCRO 7010:
Table of Contents

Advertisement

Quick Links

Download this manual
GCRO 7010
GCRO 7010
GCRO 7012
OPERATOR'S
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GCRO 7010 and is the answer not in the manual?

Questions and answers

Related Manuals for Tatu Marchesan GCRO 7010

Summary of Contents for Tatu Marchesan GCRO 7010

  • Page 1 GCRO 7010 GCRO 7010 GCRO 7012 OPERATOR’S MANUAL...
  • Page 2 IDENTIFICATION Dealer: Owner: Firm / Farm: City: State: No. of the Certificate of Guarantee: Serial / No.: Date: Invoice No.: Product: Notes:...
  • Page 3 Introduction The GCRO 7010 and 7012 disk harrows were specially designed for great areas. They are ideal for the initial preparation or for leveling the soil, with excellent application and soil preparation for annual or perennial crops. Their reinforced and adequate structure are made of folded steel plates joined by a good penetration weld and fine finishing, with resistant parts on the load concentrations.

  • Page 4: Table Of Contents

    Hydraulic cylinder maintenance / assembly 78 & 79 Hydraulic safety Disk harrow maintenance Tires inflation 10. Important data 83 to 85 Hourly income calculation Average income table Torque table 11. Important Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 5: To The Owner

    NOTE purchaser thereof at retail has used or allowed to be used parts, not made or supplied by Marchesan. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 6: To The Operator

    This procedure will prevent a possible rupture of any hydraulic hose or breaks on the hitching system, what would make the equipment tilt up. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 7 For your protection and safety, always wear adequate clothes and footwear while operating the equipment. Always use the safety locks to carry out any maintenance or to transport the equipment. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 8 • If there is any doubt after reading it, ask your dealer. For more complicated operations, there will be the right person to help you there. • Please check the general safety instructions on the back cover of this manual. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 9 • Check all laws and regulations regarding the height limits and load width while transporting the equipment on truck or trailer. If necessary use banners, lights and other devices in order to give adequate warning to the other drivers. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 10 Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 11 Use chains, of at least 3 meters long, to lift the equipment safely. Use the adequate points for lifting and be sure that the equipment is safe. Avoid accidents. Always keep a safe distance from the equipment. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 12 Para evitar accidentes, instale las trabas de los cilindros antes del transporte o antes de efectuar trabajos en el equipo. 05.03.03.1738 Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 13 To the operator Safety decals Decal set Qty. Model Serial number GCRO 7010 decal set 05.03.03.3943 GCRO 7012 decal set 05.03.03.3944 Tatu logotype decal 05.03.03.5340 05.03.03.1738 Warning decal Lifting points decal 05.03.03.4078 Read the manual decal 05.03.03.1428 05.03.03.1827 Lubricate and tighten daily decal Danger decal 05.03.03.1896...

  • Page 14: Data Sheet

    Data sheet GCRO 7010 Model: ......................GCRO 7010 Spacing between disc blades: ................270 mm Disc blades dimension: ..........Ø 26" x 7.5 mm, Ø 28" x 7.5 mm, ............. Ø 30" x 7.5 mm, Ø 30" x 9 mm, ..........Ø 32" x 7.5 mm and Ø 32" x 9 mm Disc blade type: ............
  • Page 15 GCRO 7012 7,380 9,695 450 - 480 Folding wings 7,940 10,020 480 - 510 NOTE • The weights above were obtained using Ø 32" x 9 mm disc blades. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 16 Data sheet General dimensions Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 17 • * For these models, there are two versions that feature the measures below: • Disk harrow with 52 disc blades - Height (F): 3435 or 3640; • Disk harrow with 56 disc blades - Width (H): 4400 or 4855. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 18 • Disk harrow 28, 32, 36, 40, 44 and 48 - Non folding wings. • Disk harrow 44D, 48D, 50, 52, 56 and 60 - Folding wings. • Disk harrow 72, 76 and 80 - Side frames. • *These measures may suffer changes according to the disc blade size. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 19: Components

    Components GCRO 7010 / 7012 - non-folding wings 01 - Frame 09 - Mechanical leveling system 02 - Front disc gang 10 - Transport lock 03 - Rear disc gang 11 - Depth stops 04 - Wheels 12 - Rear hitch (optional)
  • Page 20 Components GCRO 7010 / 7012 - folding wings 01 - Frame 09 - Hydraulic leveling system (optional) 02 - Folding front disc gang 10 - Transport lock 03 - Folding rear disc gang 11 - Depth stops 04 - Wheels...
  • Page 21 Components GCRO 7010 - folding frame 01 - Central frame 09 - Transport lock 02 - Right side frame 10 - Wheels 03 - Left side frame 11 - Hose support 04 - Front disc gang 12 - Depth stops...

  • Page 22: Assembly

    • Use the L-type socket wrench (E) to tighten the nuts on the bearing bolts. NOTE • We recommend wearing gloves, especially while assembling the disc gangs. • The wrenches (A1) are used on 2.1/8" axles. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 23: Assembly Of Bearings And Spacer Spools

    (Ø 2.1/8" axle) 32 disc blades 32 disc blades 12 bearings 12 bearings 14 spacer spools 14 spacer spools 1 furrow filler 1 furrow filler Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 24 (Ø 2.1/8" axle) 40 disc blades, 40 disc blades, 12 bearings 12 bearings 22 spacer spools 22 spacer spools 1 furrow filler 1 furrow filler Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 25 (Ø 2.1/8" axle) 44 disc blades, 44 disc blades, 16 bearings 16 bearings 20 spacer spools 20 spacer spools 1 furrow filler 1 furrow filler Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 26 (Ø 1.5/8" axle) 44 disc blades, 44 disc blades, 16 bearings 16 bearings 20 spacer spools 20 spacer spools 1 furrow filler 1 furrow filler Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 27 (Ø 2.1/8" axle) 50 disc blades, 50 disc blades, 16 bearings 16 bearings 26 spacer spools 26 spacer spools 1 furrow filler 1 furrow filler Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 28 52 disc blades, 52 disc blades, 16 bearings 16 bearings 28 spacer spools 28 spacer spools 1 furrow filler 1 furrow filler Spacer spool Spacer spool Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 29 52 disc blades, 16 bearings 16 bearings Bearing Bearing 28 spacer spools 28 spacer spools 1 furrow filler 1 furrow filler Spacer spool Spacer spool Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 30 52 disc blades, 16 bearings 16 bearings 28 spacer spools 28 spacer spools 1 furrow filler 1 furrow filler Bearing Bearing Spacer spool Spacer spool Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 31 56 disc blades, 16 bearings 16 bearings Bearing Bearing 32 spacer spools 32 spacer spools 1 furrow filler 1 furrow filler Spacer spool Spacer spool Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 32 56 disc blades, 16 bearings 16 bearings 32 spacer spools 32 spacer spools Bearing Bearing 1 furrow filler 1 furrow filler Spacer spool Spacer spool Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 33 56 disc blades, 16 bearings 16 bearings Bearing Bearing 32 spacer spools 32 spacer spools 1 furrow filler 1 furrow filler Spacer spool Spacer spool Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 34 60 disc blades, Bearing Bearing 16 bearings 16 bearings 36 spacer spools 36 spacer spools 1 furrow filler 1 furrow filler Spacer spool Spacer spool Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 35 72 disc blades, 28 bearings 28 bearings 32 spacer spools 32 spacer spools Bearing Bearing 1 furrow filler 1 furrow filler Spacer spool Spacer spool Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 36 76 disc blades, Bearing Bearing 28 bearings 28 bearings 36 spacer spools 36 spacer spools 1 furrow filler 1 furrow filler Spacer spool Spacer spool Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 37 80 disc blades, 80 disc blades, 28 bearings 28 bearings 40 spacer spools 40 spacer spools 1 furrow filler 1 furrow filler Spacer spool Spacer spool Furrow filler Furrow filler Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 38: Disc Gangs Assembly Sequence

    • Lastly, put the bolt (H-1) and position the lock nut (I-1), fastening with a flat washer and nut. • Check the correct side of the bearings and spacer spools according to IMPORTANT the disc blades concavity. Grease fitting Grease fitting or plug or plug Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 39 3150 2.1/8" 3300 The axle threads (B) must be greased NOTE 2.1/2" 3500 before their assembly. Consult the 2.3/4" 3750 torque table on the 'important data' page. 3" 4000 Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 40 Lastly, place the bolt (H2) and position the lock nut (I1), fastening with flat washer and nut. Check the correct side of the bearings and spacer spools according to IMPORTANT the concavity of the disc blades. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 41 Consult the torque table on the 'important data' page. Torque table Axle diameter Ft. - lbs. 1.1/2" 2670 1.5/8" 2890 1.3/4" 3020 2" 3150 2.1/8" 3300 2.1/2" 3500 2.3/4" 3750 3" 4000 Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 42: Assembly Of The Disc Gangs On The Frame

    • Place the bolt (A) with square washer (B) and pass it through the bearing housing and through the bearing hanger hole. On the upper part, place a flat washer (B) and nuts (C); • Repeat this operation for the other bearings. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 43: Scrapers Assembly

    5 - 10 mm The scrapers feature an adjustment to approach or distance them from the disc NOTE blades; it ranges from 5 mm (minimum) to 10 mm (maximum). Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 44 Right after, lock using flat washer (C), spring washer and nuts. Lantern support assembly Fasten the lantern support (D) to the frame (E) using bolts (C), spring washers and nuts. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 45: Wheel Arm Assembly

    Then, fasten the cylinders (D) to the wheel arm (A) locking with articulation axles, flat washers and elastic pins. Side frame Side frame Central frame Central frame Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 46 The adjustment is done through the adjusting nut of the stabilizer (A). To lift the disk harrow totally, note the stabilizer leveling. To mount the stabilizer, fasten it to the support using pins (B) and cotter pins. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 47: Hitch Bar Assembly

    Hitch bar assembly (72 - 80 disc blades) Couple the hitch bar (A) to the frame (B) arms and lock using an axle with lock (C), flat washer, castle nut and cotter pin. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 48: Hydraulic Traction Set Assembly

    Fasten the hydraulic cylinder (K) to the spindle (I) and to the articulator (J) with its respective axles and cotter pins. Assemble the hose support (L) and the jack (M) to the drawbar (E). Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 49: Mechanical Traction Set Assembly

    Fasten the articulator (H) to the stabilizer bar (K) using junction axle and cotter pin. Couple the stabilizer bar (K) to the wheel arm (L) using a bolt, flat washer and hex nut. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 50: Folding Wings Assembly

    (H) to the wing (A). Lock the arm (K) to the articulator (H) using an axle lock, spring fastener (L) and nut. Repeat the same procedure on the other side of the frame. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 51 (K). Detail Detail NOTE • The lock pin (Q) is used only to lock the wing (A) on the central frame (B) for transportation. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 52: Side Frames Assembly

    • When assembling the cylinders (G), the hose ports must be installed facing backwards to avoid dirt accumulation. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 53 Assembly Wheel arm hydraulic circuit with cylinder and valve Relief valve Relief valve "Blue" "Blue" Return Return "Black" "Black" Lifting Lifting cylinder cylinder "Red" "Red" Pressure Pressure Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 54 • The cylinder rod must remain facing the front part of the equipment. NOTE • Always use thread sealing tape to couple the male quick couplers to the hoses. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 55 Assembly Wheel arm hydraulic circuit with stabilizer bar Relief valve Relief valve "Blue" "Blue" Return Return "Black" "Black" Lifting Lifting cylinder cylinder "Red" "Red" Pressure Pressure Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 56 • The cylinder rod must remain facing the front part of the equipment. NOTE • Always use thread sealing tape to couple the male quick couplers to the hoses. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 57 Assembly Wheel arm hydraulic circuit - GCRO 72 - 80 "Blue" "Blue" Return Return Relief valve Relief valve "Black" "Black" Lifting Lifting cylinder cylinder "Red" "Red" Pressure Pressure Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 58 • The cylinder rod must remain facing the front part of the equipment. NOTE • Always use thread sealing tape to couple the male quick couplers to the hoses. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 59 Assembly Frame articulation hydraulic circuit - GCRO 44 - 60 "Blue" "Blue" Return Return "Brown" "Brown" Articulation Articulation cylinders cylinders "Red" "Red" Pressure Pressure Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 60 • The cylinder rod must remain facing the front part of the equipment. NOTE • Always use thread sealing tape to couple the male quick couplers to the hoses. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 61 Assembly Frame articulation hydraulic circuit - GCRO 72 - 80 "Blue" "Blue" Return Return "Brown" "Brown" Articulation Articulation cylinders cylinders "Red" "Red" Pressure Pressure Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 62 • The cylinder rod must remain facing the front part of the equipment. NOTE • Always use thread sealing tape to couple the male quick couplers to the hoses. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 63: Set-Up Instructions

    Check the tires inflation and keep the same pressure on all tires (check the 'tires inflation' page in the 'maintenance' section); Lubricate all grease fittings appropriately (see the 'lubrication' page in the 'maintenance' section). Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 64 However, the hitch and the hoop must pass through the chain links as shown on the illustration from the next page. Never hitch the hook without passing it through the chain. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 65 NOTE After hitching, place the jack (D) in transport position, as shown in the illustration below. Keep the three-point hitch arms always opened, locked and lifted to the maximum. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 66: Important Recommendations

    • To transport the disk harrow over great distances, it is necessary to use the axle locks (B), which are coupled to the central frame and to the folding wing. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 67: Adjustments And Operations

    To control the depth through the tires use the depth stops (A) which are placed on the cylinder rods and work as course limiters, thus providing several cutting depth adjustments. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 68: Tractor Position Related To The Previous Pass - Lateral Displacement

    Position #1: Normal position (centered) - used on most situations. Position #2: Allows the tractor to get closer to the previous furrow. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 69: Ways To Start The Harrowing

    • Note that the harrowed ground is always on the left hand side of the operator. • Being the disc gangs lowered, only maneuver to the left hand side. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 70: Correct Way Of Use

    Adjustments and operations Correct way of use Correct Correct Incorrect Incorrect IMPORTANT • Never work with the tires over the already harrowed soil. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 71 To align the frames related to the front and rear disc gangs, use the extensor (A). Loosen up the bolts that join the frame with the disc carriers and use the wrench (C) from the 'set of wrenches' page to make adjustments if necessary. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 72: Troubleshooting Guide

    Use the depth stops to decrease the gangs. depth. Deep penetration on wet soil. Lift the disc blade to reduce the penetration. Worn out / incorrectly Adjust or change the scrapers when adjusted scrapers. necessary. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 73 Normal pressure: 180 Kgf/cm Insufficient tightening. Retighten carefully. Lack of sealing material on the Use thread sealing tape and retighten Quick couplers thread. carefully. leaking. Damaged repairings. Replace the repairings. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 74: Operations - Important Points

    • During work or transportation, do not allow passengers on the tractor or in the equipment. • To carry out any verification on the equipment, lower it to the ground and shut down the tractor engine. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 75 • The harrow activation to open or close the gangs must be done gradually, being the tractor in movement. • As previously mentioned, this disk harrow has several settings. However, only the local conditions can determine its best adjustment. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 76: Optional

    GCRO with 28 - 48 disc blades 48 disc blades Hitch for a Hitch for a GCRO with 52 - GCRO with 52 - 80 disc blades 80 disc blades Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 77 • The cylinder rod must remain facing the front part of the equipment. NOTE • Always use thread sealing tape to couple the male quick couplers to the hoses. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 78: Maintenance

    A s s e m b l e d w i t h a h i g h - performance lubricant, the Duromark steel-plated bearing do not have a plug since there is no need to refill it, avoiding the risk of mixing incompatible lubricants. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 79: Lubrication Points

    Maintenance Lubrication points Lubricate every 24 hours of service. ATTENTION Lubricate the points shown above and all grease fittings as well. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 80: Hydraulic Cylinder Maintenance / Assembly

    7) Inspect the inside of the cylinder barrel, piston, rod and other polished parts for burrs and scratches. Smooth areas as needed with an emery cloth. NOTE Do not clamp rod by chrome surface. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
  • Page 81 6) Torque cylinder end cap (A) to 400 lb.ft (600 N.m). Insert the gland (E) on the cylinder head and align it with the tube so it will IMPORTANT fit correctly on the cylinder barrel. NOTE Do not clamp rod by chrome surface. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 82: Hydraulic Safety

    Carry out the operations on a carefully and controlled manner. Avoid to let the hydraulic system working when it is not being used. Failure to follow these procedures may lead to fatal accidents or even death. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 83: Disk Harrow Maintenance

    If it is necessary to totally lower the equipment, do not place locks and neither the pin on the jack, as such procedure may result in damages to the jack itself. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 84: Tires Inflation

    For the cases where the maximum pressure is not specified on the tires, NOTE consult the tire manufacturer and adopt the pressure indicated by them. Use TATU original parts only. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 85: Important Data

    V = Average speed of the tractor (meters per hour); E = Efficiency: 0.90; X = Hectare value = 10,000 m Example - GCRO 7010 with 36 disc blades: R = ? L = 4.6 m V = 6,000 m/h (6 km/h) E = 0.90...

  • Page 86: Average Income Table

    To know how many hours will be spent to work in a certain previously known area, it is necessary to divide the value of the area by the hourly income. Example: An area of 50 hectares to be worked with a GCRO 7010 model that has 36 disc blades (Hourly income = 2.48 ha).

  • Page 87: Torque Table

    M 39 x 1.5 1073 d) Nominal thread diameter in millimeters x thread pitch 1454,988 2860,5 3878,84 4201,5 5697,234 Values are for reference and are based on average steel-to-steel friction conditions. Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...

  • Page 88: Important

    March, 2022 Serial number.: 05.01.09.1554 Revision: 05 MARCHESAN IMPLEMENTOS E MÁQUINAS AGRÍCOLAS "TATU" S.A. Marchesan Av., 1979 - Zip Code 15994-900 - Matão - SP - Brazil Telephone 55.16.3382.8282 www.marchesan.com.br Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GCRO 7010 / 7012...
