- Page 1 ELKO - SmartDim Multiwire Universal LED Push Device user guide Information about features and functionality of the devices 11/2022 www.elko.no...
- Page 2 Legal Information The ELKO brand and any trademarks of ELKO AS and its subsidiaries referred to in this guide are the property of ELKO AS or its subsidiaries. All other brands may be trademarks of their respective owners. This guide and its content are protected under applicable copyright laws and furnished for informational use only.
-
Page 3: Table Of Contents
Table of Contents Safety information ..................4 ELKO - SmartDim Multiwire Universal LED Push ........5 For your safety ...................5 About the device..................7 Installing the device ..................7 Pairing the device ..................7 Pairing device manually.................7 Pairing device with auto scan..............9 Checking the type of wiring mode ..............10 Configuring the device ................10... -
Page 4: Safety Information
Safety information Safety information Important information Read these instructions carefully and look at the equipment to become familiar with the device before trying to install, operate, service, or maintain it. The following special messages may appear throughout this manual or on the equipment to warn of potential hazards or to call attention to information that clarifies or simplifies a procedure. -
Page 5: Elko - Smartdim Multiwire Universal Led Push
ELKO - SmartDim Multiwire Universal LED Push ELKO - SmartDim Multiwire Universal LED Push EKO0727X EKO07277, EKO30197 For your safety DANGER HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH Safe electrical installation must be carried out only by skilled professionals. - Page 6 ELKO - SmartDim Multiwire Universal LED Push CAUTION THE DEVICE MAY BE DAMAGED Only connect dimmable load. Failure to follow these instructions can result in injury or equipment damage. DUG_SmartDim MW Push_ELKO-01...
-
Page 7: About The Device
LED, ohmic, inductive or capacitive loads manually or remotely. Control options Home control: To control the dimmer through the ELKO app you will need the ELKO SmartHUB. Direct operation: The dimmer can always be controlled directly on-site. You can also connect any number of mechanical push-buttons to control the device. - Page 8 ELKO - SmartDim Multiwire Universal LED Push 4. To pair the device with install code, tap Add Device with Install Code to display the slide-up menu. Select any one of the options (B): – Scan Install Code - you can scan the device for the install code –...
-
Page 9: Pairing Device With Auto Scan
3. If you have multiple hubs, do Step 4 or proceed to Step 5. 4. Tap Select hub and select the ELKO SmartHub from the slide-up menu. 5. Short press the upper part of the push button 3 times (< 0,5 s). -
Page 10: Checking The Type Of Wiring Mode
ELKO - SmartDim Multiwire Universal LED Push Checking the type of wiring mode Using the ELKO Smart app, you can check whether the dimmer is connected with or without neutral wire. To check the type of wiring mode: 1. On the Home page, tap All devices > Push-button Dimmer. -
Page 11: Renaming The Device
Name Save Changing the device location You can change the device location using the ELKO Smart app. 1. On the Home page, select the device for which you wish to change the location. 2. At the top-right corner of the screen, tap... - Page 12 ELKO - SmartDim Multiwire Universal LED Push 3. Tap edit next to the device name. 4. Tap Location. 5. Select the desired location from the list (A) and then tap Save. Device location Save Living Room Master Bedroom Dining Room...
-
Page 13: Managing Dimmer Settings
ELKO - SmartDim Multiwire Universal LED Push Managing dimmer settings Using the ELKO Smart app, you can manage the Dimmer modes and settings. To access the dimmer settings: 1. On the Home page, tap All devices > Push-button Dimmer. 2. On the device control panel page, tap Settings. - Page 14 ELKO - SmartDim Multiwire Universal LED Push Auto Auto levels are too close to each other. Close NOTE: The Dimming range is limited if the min. and max. levels are too close to each other. LED indicator mode You can select the LED indicator mode for easy identification of the device status.
-
Page 15: Removing The Device
ELKO - SmartDim Multiwire Universal LED Push Removing the device Using the ELKO Smart app, you can remove a device from the device list. To remove a device: 1. On the Home page, tap All devices > Push-button Dimmer. 2. Tap to display more details. -
Page 16: Resetting The Device
ELKO - SmartDim Multiwire Universal LED Push Resetting the device You can reset the device to factory default manually. To reset the device: Short press push button 3 times (< 0.5 s) and then long press the push button once (>10 s). after 10 s, LED starts blinking red then release the push button. -
Page 17: Switching/Dimming The Device Using App
Long press the push-button (> 0,5 s) on the device to increase/decrease the brightness of the dimmer. > 0,5 s Switching/Dimming the device using app Using the ELKO Smart app, you can turn on/off and increase/decrease the brightness of the device. Switch On/Off the device To turn on/off the device: 1. -
Page 18: Creating A Schedule
ELKO - SmartDim Multiwire Universal LED Push 1. On the Home page, tap the ˅ (B) next to the device name and drag the slider to adjust the brightness of the Dimmer. 2. Alternatively, you can navigate to the control panel, page 16 of the device and drag the sliding bar up/down to increase/decrease the brightness. -
Page 19: Creating A Moment
8. Tap Save. Creating a moment Moment allows you to group multiple actions that are usually done together. Using the ELKO Smart app, you can create moments based on your needs. To create a moment: 1. On the Home page, tap 2. - Page 20 ELKO - SmartDim Multiwire Universal LED Push 5. In the Add task menu, you can do either or all of the following actions (C): – Run the device - Select the devices that you want in a moment. – Select Automation - Select the automation that you want to enable or disable.
-
Page 21: Creating An Automation
Creating an automation Automation allows you to group multiple actions that are usually done together, triggered automatically or at scheduled times. Using the ELKO Smart app, you can create automations based on your needs. To create an automation: 1. On the Home page, tap the 2. - Page 22 ELKO - SmartDim Multiwire Universal LED Push 4. Tap Any condition is met to select any one of the condition type (B): – All conditions are met - The automation is triggered when all the conditions are met. – Any condition is met - The automation is triggered when at least one condition is met.
- Page 23 ELKO - SmartDim Multiwire Universal LED Push 7. Tap When device status changes > Push-button Dimmer and select either or both the functions: – Dimmer - Turn the Dimmer on/off (D). – Brightness - Adjust the brightness level (E). Select function...
- Page 24 ELKO - SmartDim Multiwire Universal LED Push 10. Tap on Effective period to set the time range for the automation. You can select any one of the following (G): – All-day - 24 hours – Daytime - From sunrise to sunset –...
- Page 25 ELKO - SmartDim Multiwire Universal LED Push 6. Tap Brightness (B), adjust the brightness to 50% and tap Save. TIP: Adding the brightness level turns on the light when the automation is triggered. You need not add a task to turn on the Dimmer separately.
-
Page 26: Led Indication
ELKO - SmartDim Multiwire Universal LED Push 1. On the Automation tab, locate the automation that you want to delete and then tap 2. Tap Delete and tap Ok. NOTE: After deleting an automation, the device action can no longer be triggered. - Page 27 ELKO - SmartDim Multiwire Universal LED Push Symptom Solution Only slight dimming capability • Change dimming range. • Change the load (if the load is incompatible with the Dimmer). • Set to RL LED mode. The device is not ready to pair after the device is...
-
Page 28: Technical Data
ELKO - SmartDim Multiwire Universal LED Push Technical Data Nominal power Load value Load type Load name 2 wire (without neutral) 3 wire (with neutral) 7–130 W (max. 0,8 A) 0–130 W (max. 0,8 A) 7–80 W (max. 0,5 A) 0–80 W (max. - Page 29 Trademarks This guide makes reference to system and brand names that are trademarks of their relevant owners. • Zigbee ® is a registered trademark of the Connectivity Standards Alliance. • Apple ® and App Store ® are brand names or registered trademarks of Apple Inc. •...
- Page 30 ELKO AS Sandstuveien 68 0680 Oslo Norway +47 67 80 73 00 elko@elko.no www.elko.no As standards, specifications, and design change from time to time, please ask for confirmation of the information given in this publication. © 2022 – ELKO AS. All rights reserved.
