  • Page 1 H110T-CM-A R2.0...
  • Page 2 First Edition November 2021 Copyright © 2021 ASUSTeK COMPUTER INC. All Rights Reserved. No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC.

  • Page 3: Table Of Contents

    Contents Chapter 1 Product overview Package contents ................. 1-1 Features ..................1-1 1.3 Specifications ................1-2 Chapter 2 Motherboard information Before you proceed ..............2-1 Motherboard layout ..............2-2 Central Processing Unit (CPU) ........... 2-4 2.3.1 Installing the CPU ............2-5 2.3.2 CPU heatsink and fan assembly installation ....
  • Page 4 Monitor ..................3-16 Boot menu .................. 3-19 3.6.1 ASUS EZ Flash 3 Utility ..........3-24 3.6.2 ASUS SPD Information ..........3-24 Exit menu ..................3-25 Appendix Notices .......................A-1 Service and Support .................A-5...

  • Page 5: Chapter 1 Product Overview

    Product overview Package contents Check your industrial motherboard package for the following items. 1 x ASUS H110T-CM-A R2.0 Industrial Motherboard 1 x SATA 6.0 Gb/s cable 2 x M.2 screw packages 2 x I/O shields (1 x mini-ITX, 1 x thin mini-ITX) NOTE: If any of the above items is damaged or missing, contact your distributor or sales representative immediately.

  • Page 6: Specifications

    1 x Chassis Intrusion header Internal I/O connectors 1 x Front Panel Audio header (AAFP) 1 x System Panel header (10-1 pin) 1 x Clear CMOS header 1 x Speaker header 1 x Internal Stereo Speaker header (continued on the next page) H110T-CM-A R2.0...
  • Page 7 1 x DMIC header 1 x RTC Battery header 1 x LVDS Signal header 1 x LCD Panel Monitor Switch header 1 x LVDS Panel VCC power selection jumper Internal I/O connectors 1 x LVDS Backlight Panel selection header 1 x Display Panel Backlight Power selection jumper 1 x LPC Debug header 1 x DC Power connector 1 x SPI TPM header...
  • Page 8 H110T-CM-A R2.0...

  • Page 9: Chapter 2 Motherboard Information

    Chapter 2 Motherboard information Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. CAUTION! • Unplug the power cord from the wall socket before touching any component. • Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity.

  • Page 10: Motherboard Layout

    ® H110 LAN1 Intel ® I219V LGA1151 128Mb BIOS U31G1_34 BATT_CON LINE_OUT MIC IN LPC_DEBUG DMIC CHASSIS 21 20 NOTE: The audio codec may vary between motherboards, please consult your sales window for the motherboards’ exact codec type. H110T-CM-A R2.0...
  • Page 11 Connectors/Jumpers/Slots Page ATX power connector (2-pin ATX19V) 2-14 CPU and Chassis Fan headers (4-pin CPU_FAN, 4-pin CHA_FAN) 2-14 USB 2.0 headers (10-1pin USB56, USB78, 5-1 pin USB9) 2-15 SATA 6.0 Gb/s ports (7-pin SATA6G_1-2) 2-15 SATA Power connector (15-pin SATA_PWR) 2-16 DDR4 SO-DIMM slots COM Port header (10-1 pin COM)

  • Page 12: Central Processing Unit (Cpu)

    Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA1151 socket. • The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/ incorrect removal of the PnP cap. H110T-CM-A R2.0...

  • Page 13: Installing The Cpu

    2.3.1 Installing the CPU CAUTION! LGA1156 CPU is not compatible with the LGA1151 socket. DO NOT install an LGA1156 CPU on the LGA1151 socket. Chapter 2: Motherboard information...
  • Page 14 H110T-CM-A R2.0...

  • Page 15: Cpu Heatsink And Fan Assembly Installation

    2.3.2 CPU heatsink and fan assembly installation CAUTION! Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the heatsink and fan if necessary. To install the CPU heatsink and fan assembly Chapter 2: Motherboard information...
  • Page 16 To uninstall the CPU heatsink and fan assembly H110T-CM-A R2.0...

  • Page 17: System Memory

    System memory This motherboard comes with two Double Data Rate 4 (DDR4) Small Outline Dual Inline Memory Module (SO-DIMM) sockets. The figure below illustrates the location of the DDR4 SO-DIMM sockets: DIMM_A1 DIMM_B1 Channel Sockets Channel A SO-DIMM_A1 Channel B SO-DIMM_B1 IMPORTANT! •...

  • Page 18: Jumpers

    LVDS Panel VCC Power selection jumper (6-pin VCC_PWR_SEL) VCC_PWR_SEL (Default) Setting Pins 12V (Default) Connector type HEADER 1 x 6p, 2.54mm pitch, S/T Display panel backlight power selection (3-pin BLKT_PWR_SEL) BLKT_PWR_SEL DC_JACK_IN (Default) Pins 12V (Default) Connector type HEADER 1x3p, 2.54mm pitch, S/T H110T-CM-A R2.0 2-10...
  • Page 19 Clear RTC RAM (2-pin CLRTC) This header allows you to clear the CMOS RTC RAM data of the system setup information such as date, time, and system passwords. CLRTC PIN 1 Connector type HEADER 1x2p, 2.54mm pitch, S/T To erase the RTC RAM: Turn OFF the computer and unplug the power cord.

  • Page 20: Connectors

    Activity/Link LED Speed LED Status Description Status Description No link 10Mbps connection Orange Linked ORANGE 100Mbps LAN port connection Green (Blinking) Data activity GREEN 1Gbps connection Green (Blinking Ready to wake then steady) up from S5 mode H110T-CM-A R2.0 2-12...
  • Page 21 Line Out port (lime). This port connects to a headphone or a speaker. In the 4.1, and 5.1 channel configurations, the function of this port becomes Front Speaker Out. Microphone port (pink). This port connects to a microphone. LAN port LED indications Headset Port 4.1-channel...

  • Page 22: Internal Connectors

    CAUTION: Do not forget to connect the fan cables to the fan headers. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! Do not place jumper caps on the fan headers! H110T-CM-A R2.0 2-14...
  • Page 23 USB 2.0 headers (10-pin USB56, USB78, 5-1 pin USB9) These headers are for USB 2.0 ports. Connect the USB cables to the headers. The USB headers comply with USB 2.0 specifications and support up to 480 Mbps connection speed. USB9 USB78 PIN 10 PIN 9...
  • Page 24 PIN 2 PIN 10 PIN 9 PIN 1 Connector type Header 2x5p, K10, 2.54mm pitch NOTE: The serial port cables are purchased separately. H110T-CM-A R2.0 2-16...
  • Page 25 Panel switch (2-pin PANEL_SW) This 2-pin header is for connecting a monitor switch that can turn off the LCD panel display backlight. PANEL_SW PIN 1 Speaker header (4-pin SPEAKER) The 4-pin header is for the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings.
  • Page 26 ATX power button/soft-off button (2-pin PWR_BTN) This 2-pin header is for the system power button. • Reset button (2-pin RESET) This 2-pin header is for the chassis-mounted reset button for system reboot without turning off the system power. H110T-CM-A R2.0 2-18...
  • Page 27 10. LVDS connector (40-pin LVDS) This connector is for an LCD monitor that supports Low Voltage Differential Signalling (LVDS) interface. LVDS LVDS_DAT_PANEL BLKT_PWR BLKT_PWR BLKT_PWR LVDS_TX_TCLK1N PIN 40 LVDS_TX_TCLK1P H_LCD_BL_PWMLV INV_ENABKL_SLV LVDS_DDC_SCL LVDS_TX_TCLK0N LVDS_TX_TCLK0P LVDS_Detect LCD_VCC LCD_VCC LCD_VCC LVDS_TX_TA1N_R LVDS_TX_TA1P_R LVDS_TX_TB1N_R LVDS_TX_TB1P_R LVDS_TX_TC1N_R...
  • Page 28 The internal mono speaker header allows connection to an internal, low- power speaker for basic system sound capability. The subsystem is capable of driving a speaker load of 4 Ohms at 3 Watts (rms). SPK_OUT PIN 1 AMP IC Connector type BOX WAFER HD 4P,S/T 2.0mm H110T-CM-A R2.0 2-20...
  • Page 29 14. TPM header (14-1 pin TPM) This header supports a Trusted Platform Module (TPM) system with a Serial Peripheral Interface (SPI), allowing you to securely store keys, digital certificates, passwords and data. A TPM system also enhances network security, protects digital identities, and ensures platform integrity. PIN 13 PIN 1 PIN 14...
  • Page 30 • If you want to connect a high-definition front panel audio module to this header, set the HD Audio Controller item in the BIOS setup to [Enabled]. H110T-CM-A R2.0 2-22...
  • Page 31 18. Battery header (2-pin BATTERY) This header is for the lithium CMOS battery. BATT_CON PIN 1 19. M.2 Wi-Fi slot This slot connects to an M.2 Wi-Fi device. M.2(WIFI) +3VSB_WIFI +3VSB_WIFI S_USB_PP10_CN S_USB_PN10_CN M.2_BT_PCMCLK S_CNV_RF_RESET_N S_CNV_WR_D1_N M.2_BT_PCMIN S_CNV_WR_D1_P S_XTAL_CLKREQ S_CNV_WR_D0_N S_CNV_WR_D0_P PIN 1 S_CNV_BRI_RSP...
  • Page 32 When using PCI cards on shared slots, ensure that the drivers support “Share IRQ” or that the cards do not need IRQ assignments. Otherwise, conflicts will arise between the two PCI groups, making the system unstable and the card inoperable. H110T-CM-A R2.0 2-24...

  • Page 33: Chapter 3 Bios Setup

    Chapter 3 BIOS setup Scan the QR code to view the BIOS update guide. BIOS setup program Use the BIOS Setup program to update the BIOS or configure its parameters. Entering BIOS Setup at startup To enter BIOS Setup at startup: Press <Delete>...

  • Page 34: Bios Menu Screen

    The Main menu provides you an overview of the basic system information, and allows you to set the system date, time, language, and security settings. 3.2.1 System Date [Day MM/DD/YYYY] Allows you to set the system date. 3.2.2 System Time [HH:MM:SS] Allows you to set the system time. H110T-CM-A R2.0...

  • Page 35: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Be cautious when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. 3.3.1 Platform Misc Configuration The items in this menu allow you to configure the platform-related features.

  • Page 36: Cpu Configuration

    The items shown in the submenu may be different depending on the type of CPU installed. Hyper-Threading The Intel Hyper-Threading Technology allows a hyper-threading processor to appear as two logical processors to the operating system, allowing the operating system to schedule two threads or processes simultaneously. H110T-CM-A R2.0...
  • Page 37 [Enabled] Two threads per activated core are enabled. [Disabled] Only one thread per activated core is enabled. Active Processor Cores This item allows you to select the number of CPU cores to activate in each processor package. Configuration options: [All] [1] [2] [3] For some CPU types, only [All] and [1] appear.

  • Page 38: System Agent (Sa) Configuration

    Allows you to select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device. Configuration options: [32M] [64M] ~ [512M] [1024M] DMI/OPI Configuration Allows you to control various DMI functions. DMI Max Link Speed Allows you to configure PEG 0:1:0. Configuration options: [Auto] [Gen1] [Gen2] H110T-CM-A R2.0...

  • Page 39: Pch Configuration

    Memory Configuration Allows you to change memory configuration parameters.. Memory Remap Allows you to enable or disable Memory Remap above 4GB. Configuration options: [Enabled] [Disabled] 3.3.4 PCH Configuration IOAPIC 24-119 Entries This item allows you to enable or disable IOAPIC 24-119 Entries. IRQ124-119 may be used by PCH devices.

  • Page 40: Pch-Fw Configuration

    This item allows you to select the ME operation mode When set to [Temporary Disabled], the system will reset immediately. This option is for Debugging purpose (e.g Update ROM by Intel FPT utility), and ME Operation Mode will be normal in the next bootup. Configuration options: [Normal] [Temporary Disabled] H110T-CM-A R2.0...

  • Page 41: Lvds Configuration

    3.3.7 LVDS Configuration All-in-One Chassis Allows you to select All-in-One (AiO) Chassis (if applicable) for simplified AiO configuration. Configuration options: [None] [ESC (21.5\x22] [Mitac Maestro (21.5\ x22)] [Gigabyte (18.5\x22)] [LP-215x (21.5\x22)] [Wibtek A21 (21.5\x22)] [Wibtek A23 (23.6\x22)] [Jumper Sail (21.5\x22)] [Pixxo HP-A206D (21.5\x22)] [22AM33NB (21.5\x22)] [3nod (21.5\x22)] [AUO (19.5\x22)] Be cautious when selecting AiO chassis.
  • Page 42 Configuration options: [10 ms] [15 ms] [20 ms] [25 ms] BKLT_Enable OFF to BKLT_PWM OFF (T11) Configuration options: [5 ms] [10 ms] [15 ms] [20 ms] BKLT_PWM OFF to Video_Data OFF (T12) Configuration options: [100 ms] [200 ms] [250 ms] [300 ms] H110T-CM-A R2.0 3-10...

  • Page 43: Onboard Devices Configuration

    Video_Data OFF to Panel_Vcc OFF (T13) Configuration options: [10 ms] [20 ms] [30 ms] [40 ms] Min Panel_Vcc OFF Time (T15) Configuration options: [600 ms] [700 ms] [800 ms] [1000 ms] LVDS POWER Allows you to configure LVDS power. Configuration options: [Disabled] [Enabled] LVDS Spread Spectrum Control Allows you to configure LVDS spread spectrum clocking.
  • Page 44 [On] [Off] The following items appear only when you set Serial Port to [On]. Change Settings Allows you to select an optimal setting for Super I/O devices. Configuration options: [IO=3F8h; IRQ=4;] [IO=2F8h; IRQ=3] [IO=3E8h; IRQ=4] [IO=2E8h; IRQ=3] H110T-CM-A R2.0 3-12...

  • Page 45: Apm Configuration

    3.3.9 APM Configuration ErP Ready Allows you to switch off some power at S5 to get the system ready for ErP requirement. When set to [Enabled], all other PME options will be switched off. Configuration options: [Disabled] [Enable(S4+S5)] [Enable(S5)] Restore AC Power Loss [Power Off] The system goes into off state after an AC power loss.

  • Page 46: Hdd/Ssd Smart Information

    This menu displays the SMART information of the connected devices. NVM Express devices do not support SMART information. 3.3.12 USB Configuration The USB Devices item lists auto-detected values. If no USB device is detected, the item shows None. H110T-CM-A R2.0 3-14...
  • Page 47 Legacy USB Support [Enabled] Enables the support for USB devices on legacy operating systems (OS). [Disabled] USB devices are only available when running BIOS Setup. [Auto] Allows the system to detect the presence of USB devices at startup. If detected, the USB controller legacy mode is enabled.

  • Page 48: Monitor

    Sets to [Silent] to minimize the fan speed for quiet CPU fan operation. [Turbo] Sets to [Turbo] to achieve maximum CPU fan speed. [Manual] Sets to [Manual] to assign detailed fan speed control parameters. The following four items appear only when you set CPU Fan Profile to [Manual]. H110T-CM-A R2.0 3-16...
  • Page 49 CPU Upper Temperature Use the <+> and <-> keys to adjust the upper limit of the CPU temperature. The CPU fan will operate at the maximum duty cycle when the CPU temperature is higher than the limit. CPU Fan Max. Duty Cycle(%) Use the <+>...
  • Page 50 When the temperature source is under the limit, the Chassis Fan will operate at the minimum duty cycle. CPU Intrusion Detection Support This item allows you to enable or disable the chassis intrusion detection function. Configuration options: [On] [Off] H110T-CM-A R2.0 3-18...

  • Page 51: Boot Menu

    Boot menu The Boot menu items allow you to change the system boot options. Fast Boot [Enabled] [Enabled] Select to accelerate the boot speed. [Disabled] Select to go back to normal boot speed. The following item appears only when you set Fast Boot to [Enabled]. Next Boot after AC Power Loss [Normal Boot] Returns to normal boot on the next boot after an AC power loss.
  • Page 52 The following items appear only when you set the Launch CSM to [Enabled]. Boot Device Control This item allows you to select the type of devices that you want to boot. Configuration options: [UEFI and Legacy OPROM] [Legacy OPROM only] [UEFI only] H110T-CM-A R2.0 3-20...
  • Page 53 Boot from Network Devices This item allows you to select the type of network devices that you want to launch. Configuration options: [Ignore] [Legacy only] [UEFI driver first] Boot from Storage Devices This item allows you to select the type of storage devices that you want to launch. Configuration options: [Ignore] [Legacy only] [UEFI driver first] Secure Boot This item allows you to configure the Windows...
  • Page 54 The db file must be formatted as a UEFI variable structure with time-based authenticated variable. DBX Management The Forbidden Signature database (dbx) lists the forbidden images of db items that are no longer trusted and cannot be loaded. H110T-CM-A R2.0 3-22...
  • Page 55 Save To File This item allows you to save the dbx to a USB storage device. Set New Key This item allows you to load the downloaded dbx from a USB storage device. Append Key This item allows you to load the additional dbx from a storage device for an additional db and dbx loaded management.

  • Page 56: Asus Ez Flash 3 Utility

    This item allows you to run ASUS EZ Flash 3. When you press <Enter>, a confirmation message appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to confirm your choice. 3.6.2 ASUS SPD Information This item allows you to view the DRAM SPD information. H110T-CM-A R2.0 3-24...

  • Page 57: Exit Menu

    Exit menu The Exit menu items allow you to save or discard your changes to the BIOS items. Load Optimized Defaults This option allows you to load the default values for each of the parameters on the Setup menus. When you select this option or if you press <F5>, a confirmation window appears.
  • Page 58 H110T-CM-A R2.0 3-26...

  • Page 59: Appendix

    Appendix Notices FCC Compliance Information Responsible Party: Asus Computer International Address: 48720 Kato Rd., Fremont, CA 94538, USA Phone / Fax No: (510)739-3777 / (510)608-4555 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 60 CAN ICES-003(B)/NMB-003(B) VCCI: Japan Compliance Statement Class B ITE KC: Korea Warning Statement HDMI Trademark Notice The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. H110T-CM-A R2.0...
  • Page 61 REACH Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of Chemicals) regulatory framework, we published the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm. DO NOT throw the motherboard in municipal waste. This product has been designed to enable proper reuse of parts and recycling.
  • Page 62 Directives. Full text of EU declaration of conformity is available at: www.asus.com/support www.asus.com/support Srpski ASUSTeK Computer Inc. ovim izjavljuje da je ovaj uređaj u saglasnosti Français AsusTek Computer Inc. déclare par la présente que cet appareil est sa osnovnim zahtevima i drugim relevantnim odredbama povezanih conforme aux critères essentiels et autres clauses pertinentes des directives...

  • Page 63: Service And Support

    Service and Support Visit our multi-language website at https://www.asus.com/support/ Manufacturer ASUSTek COMPUTER INC. Address, City 1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112, Taiwan Authorized ASUS COMPUTER GmbH Representative in Europe Address Harkortstrasse 21-23, 40880 Ratingen Country Germany...
