Ref.No. Part No.
1 RGV0230-K KNOB,PLAY/SEL/STOP
2 RGV0231-K KNOB,HOLD
3 RHQ0051-K SCREW
4 RGL0420-Q PANEL,LIGHT
5 RGU1673-K BUTTON,10 SEC REVIEW
6 RGV0232-K KNOB,SPEED CONTROL
7 RKK0115-S BATT.COVER
8 RKS0290B-1S REAR CABINET
9 RFKDRDR60P-S JOG SW ASS~Y,PLAY/STOP
10 RJM0016 MICROPHONE
11 RMG0496-H ZEBRA GUM
13 RSL5213-T LCD(LCD101)
14 RAS3P13-U SPEAKER
16 RGU1669-1S BUTTON,MODE
17 RGU1670-R BUTTON,REC START/STOP
18 RGU1671-K BUTTON,ERASE
19 RJC40015 BATT.TERMINAL(+)
20 RJC80017 BATT.TERMINAL(-)
21 RJC94013-2 BATT.TERMINAL
22 RMZ0466 SHEET
23 RYK0859-S FRONT CABINET ASS~Y
24 XQN2+CQ3 SCREW
25 XTNR2+5CFN SCREW
A1 RQT4801-G INSTRUCTION MANUAL
A2 RQCB0169>

SERVICE CENTER LIST

C1 ECUV1C154KBN 16V 0.15U
C2 ECST0GY226RR 4V 22U
C4 ECUZNC104ZFV 16V 0.1U
C5 ECUVNA105ZFV 10V 1U
C6 ECUVNA105KBN 10V 1U
C7,C8 ECUZNC104ZFV 16V 0.1U
C9 RCST0GA106RE 4V 10
C10 ECUV1H151KBV 50V 150P
C13 ECST1CY105RR 16V 1U
C14 ECUZNC104ZFV 16V 0.1U
C16 ECUV1H100DCV 50V 10P
C17 ECST0GX476R 4V 47U
C19 ECUV1H332KBV 50V 3300P
C20 ECST0GY226RR 4V 22U
C21 ECUZNC104ZFV 16V 0.1U
C22 ECST0GY106RR 4V 10U
C23 ECUVNC473KBV 16V 0.047U
C24 RCSX0GC157RE 4V 150U
C25 ECUZNC104ZFV 16V 0.1U
C27 ECUZNC104ZFV 16V 0.1U
C28 ECUV1C105ZFN 16V 1U
C29 ECUZNC104ZFV 16V 0.1U
C30,31 ECUV1H102KBV 50V 1000P
C32 ECUZNC104ZFV 16V 0.1U
C37 ECUV1E103KBV 25V 0.01U
C38 ECUV1H220KCV 50V 22P
C39 ECUV1H120KCV 50V 12P
Part Name & Description Pcs Remarks
1
1
3
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1 <IA>
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
4
