McCall DH-1 Specifications

McCall Refrigeration specification sheets are available
online @ www.mccallrefrigeration.com
Construction - The DH series drop in
heated pans are self-contained units with all metal
construction. All joints and seams between wells
and tops are closed and sealed. Each unit is
designed to be installed in new or existing
countertops. Sealing gasket and drain connection
are provided. Well will accept up to 6" deep pans.
Pans are not provided.
Phone (731) 847-5570 / Fax (731) 847-9012 / 1-888-REACH-IN (1-888-732-2446) / www.mccallrefrigeration.com
ITEM #
MODEL #
PROJECT NAME
D -I
ROP
DH-3
SPECIFICATIONS
The well walls and bottoms are fully insulated with
2" thick superwool insulation. Top and rails are 16-
gauge stainless steel construction for strength and
durability.
Each unit is provided with a 1/2" drain, shut-off
valve and a remote control panel with an infinite
control for each pan. The control box is wired to
McCall Refrigeration / 81 West Holly Street / Parsons, TN 38363
January 2007 / Printed in U.S.A.
H F
N OT OOD
DH Series Offered in Six Sizes
DH-1 DH-3 DH-5
DH-2 DH-4 DH-6
Standard Features
• Self contained units
• All metal construction
• Individually controlled wells
• Wet-dry operation
• Manifolded drain with shut off value
• Control box prewired with 4' long harness
for remote installation
Approval :
the wall by a 4' long flexible metallic
harness.Designed to hold pre cooked products at
serving temperatures between 140˚ to 160˚ F.
Single pan offered with cord and plug. Food pan
and covers purchased separately.
AIA #
SIS #
W
ELLS
