※Maintenance of Exhaust air Filter
If the mesh of exhaust air filter is clogged with dusts, clean it according to the following procedure:
1．Remove the exhaust air filters A and B in reverse procedure of installation.
2．Remove dust from the mesh of exhaust air filter with vacuum cleaner or the like.
●Do not press the mesh strongly. It may cause damage to the filter.
3．Install the exhaust air filters A and B according to Section 3, "Installing/Removing the Bezel to the Server".
11. Make sure that a filter is mounted on the provided dust-proof vent holes cover, insert the four claws
into the grooves on top of the server (when the server is vertically installed), as shown in the figure
below.
Note: To remove the dust-proof vent holes cover from the server chassis, put your finger in the hole at
rear of the dust-proof vent holes cover, and lift it to remove.
Hold for removal
12. Stick the nameplate on the bezel shown by the slant lines in the figure below.
Air-cooling model: G110e-S, Silver
Water-cooling model: G110e-S, Navy blue
24
Claws (4 places)
