※If you are using a 3.5-inch disk model server:
You can install N8146-36 Dust-proof Bezel with the server equipped with a cylinder lock.
If you do not need a cylinder lock, remove it in the following procedure:
1. Remove the Screw 1.
2. Insert the key into key slot, and rotate it to unlock.
3. Remove the Screw 2, then remove the cylinder lock.
4. Insert your finger into a hole on accent cover, and raise it up toward you to remove the accent
cover. Dispose of the removed accent cover.
5. Put a blindfold label so that its non-adhesive part is placed over the key slot, and stick the label
as shown in the figure below.
6. Set the provided accent cover (without holes) as shown in the figure below.
4
Screw 1
5
Blindfold label
Adhesive portion
Screw 2
Non-adhesive portion
19
This portion is easily disengaged
from the bezel. Pay attention not
to drop it during work.
6
