Summary of Contents for Allnet ALL-MC116-VDSL2
- Page 1 ’ ’ ’...
- Page 2 Foreword The ALL-MC116 is a VDSL2 CO/CPE bridge with 2 x 10/100/1000base-T LAN ports solution that's built for data transmission via 10/100/1000BASE-T Ethernet cable (UTP), line port by single twisted pair and 1.25G SFP slot. ALL-MC116 supports CO/CPE mode selectable and bands profile selectable via DIP switch on rear panel of ALL-MC116. ALL-MC116 LAN port support auto-negotiation &...
-
Page 3: Safety Warnings
Safety Warnings For your safety, be sure to read and follow all warning notices and instructions before using the device. DO NOT open the device or unit. Opening or removing covers can expose you to dangerous high voltage points or other risks. -
Page 4: Table Of Contents
Table of Contents Safety Warnings ..............................3 1.1 Check List ....................................6 Chapter 2. Installing the Device ......................... 7 2.1 Hardware Installation ................................. 7 2.2 Pre-installation Requirements ..............................7 2.3 General Rules .................................... 8 2.4 Connecting the Ethernet of RJ-45 Ports ............................ 9 2.5 Connecting the SFP Slot................................ - Page 5 Blinking Slowly ....................................16 OFF ........................................16 Remark: 1. Except for Fiber SFP transceiver, SFP LED indicator will light up right away when the SFP transceiver insert into SFP slot....................................16 CO = Master / CPE =Slave ..............................16 3........................................16 Appendix B: Product Specification ......................... 19 Appendix D: Troubleshooting ..........................
-
Page 6: Check List
Chapter 1. Unpacking Information 1.1 Check List Carefully unpack the package and check its contents against the check list. Package Contents: 1 x ALL-MC116 Accessory: 1 x Ethernet Cable, 4 x Rubber Feet, 1 x DC12V Adapter Notes: 1. Please inform your dealer immediately for any missing or damaged parts. If possible, retain the carton including the original packing materials. -
Page 7: Chapter 2. Installing The Device
Chapter 2. Installing the Device 2.1 Hardware Installation This chapter describes how to install the bridge and establish the network connections. The ALL-MC116 may be installed on any level surface (e.g. a table or shelf or rail). However, please take note of the following minimum site requirements before one begin. -
Page 8: General Rules
2.3 General Rules Before making any connections to the bridge, please note the following rules: SFP Port All Fiber optical network connections to the SFP port must use Fiber 1.25G SFP transceiver. Please note that SFP transceiver that you are using must be compatible to both side’s device. ... -
Page 9: Connecting The Ethernet Of Rj-45 Ports
RJ-11 Pin out Assignments Pin# MNEMONIC FUNCTION Unused Unused Used Used Unused Unused_ External Splitter installing ALL-MC116 need install external splitter depend on PBX systems such as POTS/ISDN, when connecting with pone set and please make sure splitter which is compatible with local PBX system. 2.4 Connecting the Ethernet of RJ-45 Ports ALL-MC116 has two Ethernet ports which support connection to Ethernet operation. -
Page 10: Connecting The Line Of Rj-11 Port
2.6 Connecting the Line of RJ-11 Port The line port has 2 connectors: RJ-45 and terminal block. It is used to connect with ALL-MC116(CO) using a single pair phone cable to ALL-MC116(CPE) bridge side (point to point solution). Take note that ALL-MC116 line port RJ-11 and terminal block cannot be used at the same time. - Page 11 When inserting a RJ-11 plug, make sure the tab on the plug clicks into position to ensure that it is properly seated. Do not plug a RJ-11 phone jack connector into the Ethernet port (RJ-45 port). This may damage the bridge. Instead, use only twisted-pair cables with RJ-45 connectors that conform to Ethernet standard.
-
Page 12: Application Diagram
2.7 Application Diagram Even though Fiber optic is a well developed technology, it still can't reach some places due to cost & physical limit. To extend Fiber optic service to region where Fiber optic infrastructure is not advanced, ALL-MC116 will play an important role in such situation. ransmission at up to 160/160Mbps and 5/1Mbps at 3000 meters, ALL-MC116 is suitable for FTTdp/FTTC network With t scenario, and is a perfect solution to extend LAN to buildings, hotels, hospitals, office, etc. -
Page 13: Chapter 3. Hardware Description
Chapter 3. Hardware Description This section describes the important parts of ALL-MC116. It features the front panel and rear panel. 1. Front Panel: The front panel provides SFP Slot, RJ-45 Connector, RJ-11 connector and LED indicators of ALL-MC116. 1-1. Front panel indicator : There are 7 LEDs indicators on front panel, the following Table shows the description. - Page 14 Tip: With only a glance of the front panel’s LED indicators, the converter status will be fully aware. Table 2-1 Description of the front interface Port Name Connector type Description E1 / E2 RJ-45 For connecting to a Networking device. SFP slot For small form-factor pluggable transceiver.
- Page 15 VDSL2 bands profile Config Overview Below table clarify the settings of 9 different VDSL modes. DIP Switch on rear panel Config Mode Description PIN1 PIN2 PIN3 PIN4 Symmetric Auto, Max. Interleave=8, Min.Inp=2, Sy-Auto I_8/2 (SNRM 8/8) SNRM=8 (Default) non symmetric Auto, Max. Interleave=8, Min.Inp=2, NSy-Auto I_8/2 (SNRM 8/8) SNRM=8 Symmetric Auto, Max.
-
Page 16: Led Indicators
3.1 LED Indicators The ALL-MC116 has LED indicators. The following Table shows the description. (Table 2-1) Table 2-1 LED Indicators Description and Operation LEDs Color Status Description Power Good Green Power OFF Ethernet port on Link status ON (Steady) E1/E2 Green Blinking Data transmission... - Page 17 Appendix A: Cable Requirements A.1 Ethernet Cable A CAT 5~7 UTP (unshielded twisted pair) cable is typically used to connect the Ethernet device to the Modem. A: 10/100TX cable often consists of four pairs of wires, two of which are used for transmission. The connector at the end of the 10/100TX cable is referred to as a RJ-45 connector and it consists of eight pins.
- Page 18 Figure A-2 Pin Assignments and Wiring for an RJ-45 Straight-Through Cable Figure A-3 Pin Assignments and Wiring for an RJ-45 Crossover Cable...
-
Page 19: Appendix B: Product Specification
Appendix B: Product Specification Key Features and Benefits: Comply with IEEE802.3/802,3u/802.3ab standards Comply with ITU-T G.993.2 VDSL2 standard Supports 2 x 10/100/1000TX & auto –MDIX for RJ-45 port Supports 1 x 1.25G SFP Slot Cost effective Copper/Fiber to VDSL2 bridge function for FTTDP/FTTC application ... - Page 20 Specifications: Item Description Protocol and Standards : IEEE 802.3u / IEEE802.3ab / IEEE802.3z Ethernet: 1000Base-T Cat.5 or above UTP Cable Fiber Optic: 1000Base-X Flexible (Depending on Fiber Cabling requirements: Transceiver) Modes : VDSL2 CO mode X 8 + CPE mode 2 x RJ-45、1 x RJ-11、1 x SFP slot、1 x DIP switch、1 x DC power Interface : jack...
- Page 21 Appendix C: DIN-Rail mount installation This appendix describes how to install the DIN-Rail to the bridged. The accessory is optional. Please refer to install the DIN-RAIL as following step: 1. Install the DIN-Rail mounting plate to the ALL-MC116. (Figure C-1) 2.
-
Page 22: Appendix D: Troubleshooting
Appendix D: Troubleshooting Diagnosing Bridge’s Indicators The Bridge can be easily monitored through its comprehensive panel indicators. These indicators assist in identifying problems the Media Converter may encounter. This section describes common problems you may encounter and possible solutions: 1. Symptom: POWER indicator does not light up (green) after power on. Cause: Defective External power supply Check the power plug by plugging in another that is functioning properly. - Page 23 System Diagnostics Power and Cooling Problems If the POWER indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply. However, if the unit power is off after running for a while, check for loose power connections, power losses or surges at the power outlet.
- Page 24 System Integrity As a last resort verify the switch integrity with a power-on reset. Turn the power to the switch off and then on several times. If the problem still persists and you have completed all the preceding diagnoses, then contact your dealer.
- Page 26 This recycle logo Indicates that this product is capable of being recycled, not that the product has been recycled or will be accepted in all recycling collection systems. The RoHS directive aims to restrict certain dangerous substances commonly used in electronic and electronic equipment. This RoHS...
- Page 27 compliant symbol indicate the component is tested for the presence of Lead (Pb), Cadmium (Cd), Mercury (Hg), Hexavalent chromium (Hex-Cr), Polybrominated biphenyls (PBB), and Polybrominated diphenyl ethers (PBDE). For Cadmium and Hexavalent chromium, there must be less than 0.01% of the substance by weight at raw homogeneous materials level. For Lead, PBB, and PBDE, there must be no more than 0.1% of the material, when calculated by weight at raw homogeneous materials.
