- Page 1 CEI1100BK Cooker hood Instruction manual CONTENT 1……………………………………….Notice...
- Page 2 2……………………………………….Feature 3………………………………………..Installation 4………………………………………..Notice of installation 5………………………………………..Safety Warning 6…………………………………………Speed adjustment 7…………………………………………Maintenance 8…………………………………………Abnormity and Solution 1.Notice...
- Page 3 This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 4 – there shall be adequate ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the room); – the details concerning the method and frequency of cleaning;...
- Page 5 The installation instructions shall include the substance of the following: – the air must not be discharged into a flue that is used for exhausting fumes from appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the room);...
- Page 6 The installation instructions for range hoods with accessible metallic enclosures of class II construction shall include details that indicate the location and maximum permitted lengths for any fixing or mounting screw or other fixing device that penetrates into the range hood to attach an accessory such as a facia or duct fitting.
- Page 7 Warning: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards Feature 1. The cooker hood uses high quality materials, and is made with a streamlined design. 2. Equipped with a large power low noise electric motor and centrifugal leaf, it produces strong suction, low noise, non stick grease filter and easy to clean.
-
Page 8: Installation
INSTALLATION 1. Before installation, turn the unit off and unplug it from the outlet. 2. The cooker hood should not be placed at a distance of no more than 150cm from the cooking surface for the best performance. Refer to Pic 3. - Page 9 4. According to the size shown on pic 2, drill 14pcs φ8mm holes on the ceiling once the installation height is determined,14pcs explode screws(or 14pcs of ST6*40mm big flat screws+14pcs wall plugs) will be used to fix the two hanging board on the ceiling.( see pic. 3) 5.
- Page 10 the expansion pipe outside.(Note: The expansion pipe must be fixed on the housing firmly.) 8. After installing the housing to the hanging board, use cross screwdriver or straight screwdriver to adjust the screw of the angle iron bracket, direct the housing level position and height till it is suitable. Adjust method: Adjust rang of the angle iron bracket is 0-25mm, clockwise twist the screw of the 4 angle iron bracket, slightly move the housing upwards;...
- Page 11 4.Notice of installation 1. Before installation, please ensure the area is clean to avoid suction of the remaining bits of broken wood and dust. 2. It cannot share the same air ventilation tube with other appliance such as gas tube, warmer tube, and hot wind tube. 3.
- Page 12 • Any installation work must be carried out by a qualified electrician or competent person. • Before cleaning, always ensure that you have switched your cooker hood off. Clean the cooker hood according to the instruction manual and keep • the cooker hood from the danger of burning.
- Page 13 4. When the hood is working, if press the “Timer” button, the hood will go into the status of acquiescent working (acquiescent time is 9mins), and then, the LED display will indicate as “9-8-7…-1-0”, when indicate “0”, the hood will be off automatically and the lamp will extinguish. If keep pressing “Timer”...
-
Page 14: Maintenance
press button once, the light is on, press again, the light is off. The lighting button it is controlled separately and will not affect any other functions. 2. Turning on/ Increasing motor speed key , the motor has low, mid, high totally 3 levels. 2.1 Press one time,the motor will work at low speed (Turning on). - Page 15 2. It is recommended to leave the appliance in operation for 15 minutes after cooking is terminated in order to completely eliminate cooking vapors and odors. 3. The proper function of the cooker hood is conditioned by the regularity of the maintenance operations, in particular, the active carbon filter.
- Page 16 You can clean the filter as below measure: Soak them for about 3 minute in hot water (40-50 degrees) with a grease-loosening detergent then brush it gently with a soft brush. Please do not apply too much pressure, avoid damaging it. Note: Please do not use abrasive detergent for it will damage the hood;...
-
Page 17: Bulb Replacement
NOTE: • Make sure the filter is securely locked. Otherwise, it would loosen and cause dangerous. • When activated carbon filter attached, the suction power will be lowered. BULB REPLACEMENT Important : The Bulb must be replaced by a competent person. -
Page 18: Abnormity And Solution
Abnormity and Solution Cause Solution Fault The leaf blocked Get rid of the blocking The capacitor damaged Replace capacitor Light on, but motor does not work The motor jammed bearing Replace motor damaged The internal with of motor off or Replace motor a bad smell from the motor Beside the above mentioned, check the following:... -
Page 19: Environmental Protection
ENVIRONMENTAL PROTECTION: This product is marked with the symbol on the selective sorting of waste electronic equipment. This means that this product must not be disposed of with household waste but must be supported by a system of selective collection in accordance with Directive 2002/96/EC.
