- Page 1 E07-900M10S CC1101 855-925MHz 10dBm SPI Wireless Module...
-
Page 2: Table Of Contents
6.3 BER(Bit Error Rate) is high ............................. 8 7 Production guidance ................................. 8 8 E07 series ..................................9 9 Antenna Guide .................................. 9 9.1 Antenna recommendation ............................9 Revision history ..................................9 About us ....................................10 Copyright ©2012–2021，Chengdu Ebyte Electronic Technology Co.,Ltd. -
Page 3: Disclaimer
Co., Ltd. Notice : Due to product version upgrades or other reasons, the contents of this manual may be changed. Ebyte Electronic Technology Co., Ltd. reserves the right to modify the contents of this manual without any hint or noticet. This manual is only used as a guide. Chengdu Ebyte Electronic Technology Co., Ltd. -
Page 4: Overview
E07-900M10S User Manual 1 OVERVIEW 1.1 Brief Introduction E07-900M10S is an independently developed 410-450MHz SMD wireless module based on the CC1101 chip produced by Texas Instruments (TI), using industrial-grade high-precision 26MHz crystal oscillator. Due to the adoption of the already mature CC1101 chip as the core of the module, its stability has won unanimous praise from users, and there is no need to worry about compatibility. -
Page 5: Specification And Parameter
Test condition：clear and open area, antenna gain: 5dBi， Reference distance 1.5km antenna height: 2.5m，air data rate: 1.2kbps FIFO 64Byte Maximum length of a single transmission Crystal Oscillator 26MHz 10ppm Modulation GFSK(recommended) Support OOK、ASK、GFSK、2-FSK、4-FSK and MSK Copyright ©2012–2021，Chengdu Ebyte Electronic Technology Co.,Ltd. -
Page 6: Size And Pin Definition
Ground wire, connected to the power reference ground Ground wire, connected to the power reference ground No need to connect No need to connect No need to connect Power supply, 3.0~3.6V (It is also recommended to add external ceramic filter capacitor) Copyright ©2012–2021，Chengdu Ebyte Electronic Technology Co.,Ltd. -
Page 7: Basic Operation
If necessary, appropriate isolation and shielding can be done; Assume that there are traces with large electromagnetic interference (high-frequency digital, high-frequency analog, power traces) around the module that will greatly affect the performance of the module. It is recommended to stay Copyright ©2012–2021，Chengdu Ebyte Electronic Technology Co.,Ltd. -
Page 8: Programming
MCU; After CC1101 restores IDLE mode or configured as sleep mode, it is recommended to reinitialize the power configuration table. 5 Recommended circuit diagram Copyright ©2012–2021，Chengdu Ebyte Electronic Technology Co.,Ltd. -
Page 9: Faq
This product is a SMD module. When soldering the module, the soldering personnel must work in accordance with the anti-static operation specification; This product is an electrostatic sensitive product. If the module is not welded according to the specification, the module may be permanently damaged. Copyright ©2012–2021，Chengdu Ebyte Electronic Technology Co.,Ltd. -
Page 10: E07 Series
915M SMA-J antenna antenna Rubber Fixed bending, omnidirectional TX915-JK-11 915M SMA-J antenna antenna Rubber Ultra-short and straight, TX915-JZ-5 915M SMA-J antenna omnidirectional antenna Revision history Version Date Description Issued by 2021-06-18 Initial version Linson Copyright ©2012–2021，Chengdu Ebyte Electronic Technology Co.,Ltd. -
Page 11: About Us
Chengdu Ebyte Electronic Technology Co.,Ltd E07-900M10S User Manual About us Sales hotline：0086-4000-330-990 Tel：0086-28-61399028 Technical support：support@cdebyte.com Website：www.ebyte.com/en Address ： Building B5, Mould Industrial Park, 199# Xi-Qu Ave, West High-tech Zone, Chengdu, 611731, Sichuan, China Copyright ©2012–2021，Chengdu Ebyte Electronic Technology Co.,Ltd.
