MICROWAVE/ WALL OVEN COMBINATION
All 27" Models:
A. Place the color matched trim (B) in place as
shown in Figure 8. Line up screw locations and
attach both ends.
B. Place the air diverter (A) in place as shown. Line
up screw locations and attach both ends.
B
B
A
Figure 8
5. Leveling the Wall Oven
1. Install an oven rack in the center of the upper oven
(see Figure 9).
2. Place a level on the rack. Take 2 readings with the
level placed diagonally in one direction and then
the other. Use wood shims under the wall oven to
level if necessary.
3. Repeat in the lower oven if you have a double
cavity wall oven. If the level indicates that the
rack is not level, use wood shims to reach a
compromise for both ovens.
INSTALLATION INSTRUCTIONS
A
IMPORTANT NOTE
A cooling fan inside the upper rear part above
the oven (some models) provides cooling of the
oven electrical and electronic components. If the
oven has been operating at high temperatures,
the fan will continue to run after the oven is
turned off.

6. Checking Operation

Your model is equipped with an Electronic Oven
Control. Each of the functions has been factory
checked before shipping. However, it is suggested
that you verify the operation of the electronic oven
controls once more. Refer to the Use and Care Guide
for operation.
1. Remove all items from the inside of the oven.
2. Turn on the power to the oven (Refer to your Use &
Care Guide.)
3. Verify the operation of the electronic oven controls:
Bake - Verify that this function makes the oven hot.
20 seconds after turning oven on, open the door and
you should feel heat coming from the oven.
Broil - When the oven is set to BROIL, the upper
element in the oven should become red.

Before You Call for Service

Read the Before You Call for Service Checklist and
operating instructions in your Use and Care Guide.
It may save you time and expense. The list includes
common occurrences that are not the result of
defective workmanship or materials in this appliance.
Refer to your Use and Care Guide for service phone
numbers.
6
