- Page 1 User Manual PTZ Network Camera O2P20X / O2P25X Please read this instruction carefully before operating the unit and keep it for further reference...
- Page 2 1. Electrical safety All installation and operation here should conform to local electrical safety codes. Use a certified/listed 12VDC power supply only. Please note: Do not connect two power supplying sources to the device at the same time; it may result in device damage! The product must be grounded to reduce the risk of electric shock.
- Page 3 Statement This guide is for reference only. Product, manuals, and specifications may be modified without prior notice. Speco Technologies reserves the right to modify these without notice and without incurring any obligation. Speco Technologies is not liable for any loss caused by improper operation.
-
Page 4: Table Of Contents
Table of Contents Introduction ..........................................2 Web Access and Login ......................................3 Live View..........................................4 PTZ Menu Setup ........................................6 System Information................................6 System Setup ..................................6 4.2.1 Auto PT Flip ................................. 6 4.2.2 Language Setup................................7 4.2.3 RS485 Setup ................................7 4.2.4 Date Setup .................................. - Page 5 5.4.1 Motion Detection ..............................23 5.4.2 Other Alarms ................................24 5.4.3 Alarm Server ................................25 5.4.4 Smart Tracking ................................26 Analytics Configuration ..............................27 5.5.1 Abnormality ................................27 5.5.2 Line Crossing ................................28 5.5.3 Intrusion ..................................30 5.5.4 Region Entrance ................................31 5.5.5 Region Exiting ................................32 5.5.6 Target Counting .................................33 5.5.7 Face Comparison ..............................35 Network Configuration ..............................38...
-
Page 6: Introduction
Thank you for purchasing this network camera! Please read this manual carefully before operating the unit and retain it for further reference. Should you require any technical assistance, please contact Speco Technologies Technical Support at 1-800-645-5516. Main Features Built-in PoE (Power over Ethernet) ... -
Page 7: Web Access And Login
2 Web Access and Login The IP camera settings can be accessed via a web browser (Internet Explorer 8 and up) through the LAN. Access through IP Scanner Network connection: ①Make sure the PC and IP-Cam are connected on the same local network. The camera is set to DHCP by default and will be assigned an IP address by the DHCP server. -
Page 8: Live View
3 Live View The window below will be shown after logging in. The following table describes the icons on the live view interface. Icon Description Icon Description Original size Color abnormal indicator Fit correct scale Abnormal clarity indicator Auto (fill the window) Scene change indicator Full screen Line crossing indicator... - Page 9 : Move the cursor to view the live image in all direction after you click this button. Additionally, hold and drag the left mouse button to zoom in the live image. All indicator icons above will flash in live view interface only when the corresponding events are enabled. ...
-
Page 10: Ptz Menu Setup
4 PTZ Menu Setup On the PTZ control panel of IE remote preview interface, call Preset 95 and click . This will take you to see the following main menu setup. The menu setup can be displayed when the resolution of the live is set to 1920×1080. After you go to the main menu interface, you can select the menu by clicking the direction button ( ：To select menu by moving up and down. -
Page 11: Language Setup
4.2.2 Language Setup English or Chinese menu can be selected. 4.2.3 RS485 Setup This function is only available for some models. Go to System SetupRS485 Setup as below: 【Dome ID】: The available range is from 001 to 255. 【Protocol】: PELCO-D or PELCO-P is selectable. 【Baud Rate】: The baud rate is selectable from 1200 to 9600bps. -
Page 12: New Password And Change Password
Choose a location by clicking the direction button. ① Select STORE to save the setting. ② The horizontal angle will treat the north position as a reference; otherwise it will treat the horizontal origin as a reference to ③ display the clockwise rotation angle of camera. The vertical PTZ will treat its highest point as a reference (when the camera is parallel with the horizontal ground) to show the ④... -
Page 13: Camera Control
4.3.1 Camera Control After you select Camera Control, you will see the following menu. 【Brightness】: Set the brightness level of the camera’s image. 【Sharpness】: Set the resolution level of the image plane and the sharpness level of the image edge. 【Contrast】: Set the color difference between the brightest and darkest parts. - Page 14 AE Setup Go to AE Setup menu as shown below: 【AE MODE】: Auto, Bright, Shutter, IRIS and Manual are optional. 【Brightness】 ： Range from 0（darkest）~20（brightness）. It is available only when bright mode is selected. 【Shutter】 ：The lower the value of camera shutter is, the brighter the image is. It is available only when the shutter or manual mode is selected.
-
Page 15: Lens Setup
4.3.3 Lens Setup Go to Camera SetupLens Setup menu as shown below: Focus Limit Set the nearest distance of focus. Options: 1m, 1.5m, 2m, 3m, 5m and 10m. Zoom MAG DISP If “ON” is selected, you will see the zoom magnification in the live image ... -
Page 16: Infrared Control
4.3.5 Infrared Control Auto, ON or OFF is optional. 4.3.6 Video Format PAL or NTSC is optional. 4.3.7 Smart IR Setup Smart IR Mode: “Auto”, “Manual” or “OFF”. This function can effectively avoid image overexposure so as to make the image more realistic. -
Page 17: Group Setup
In this interface, by programming presets in cruise list in advance, the system will keep calling those presets at the set time in sequence when executing cruise command so that non-stop monitoring between multiple important positions can be achieved. Setting steps are as follows: ①... -
Page 18: Trace Setup
By dividing 24 hours into several periods and appointing different commands for each period, the camera system will automatically execute the commands according to the set time if there is no operation. Setting Steps: ① Enable the task. ② Set the task. Time Format: Start Time –... -
Page 19: Home Position
Setting Steps: ① Select Alarm In No. ② Go to “EDIT CUR ALARM IN” menu as shown below. 【ALARM IN CON】:Set the alarm enter type to be Normally Opened (N.O.) or Normally Closed (N.C.) according to the sensor type. 【ALARM IN MODE】:ON, OFF and TIME are optional. 【ALARM CALL】: Call the preset/cruise/trace/scan you need. -
Page 20: Display Setup
① Set the speed level and run time. ② Call “START” to enable wiper function. 4.5 Display Setup You can enable title display and time display as needed. 4.6 Load Default There are three menus, including master reset, master clear and system reboot. 【Master Reset】... -
Page 21: Camera Configuration
5 Camera Configuration Press the “Setup” button to go to the configuration interface. Note: Wherever applicable, click the “Save” button to save the settings. 5.1 System Configuration 5.1.1 System Information In the “System Information” interface, the system information of the device is listed. 5.1.2 Date and Time To set the time and date, go to SystemDate and Time. -
Page 22: Storage
5.1.4 Storage Go to SystemStorage to go to the interface as shown below. SD Card Management When the card is used for the first time, click the “Format” button to format the SD card. All data on the card will be cleared by clicking this button. - Page 23 Weekly schedule Set the alarm time from Monday to Sunday for a single week. Each day is divided in one hour increments. Green means scheduled. Blank means unscheduled. “Add”: Add the schedule for a special day. Drag the mouse to set the time on the timeline. “Erase”: Delete the schedule.
-
Page 24: Video Configuration
snapshots is less than the set quantity of snapshots. Timing Snapshot: Enable timing snapshot first and then set the snapshot interval and schedule. The setup steps of schedule are the same as the schedule recording (See Schedule Recording). 5.2 Video Configuration Video Configuration includes Image Settings, Video/Audio Setup, OSD, Privacy Mask and Region of Interest. -
Page 25: Video / Audio Configuration
Drag “ ” icons to set the time of day and night. Blue means day time and blank means night time. If the current mode of camera parameters is set to “Timing”, the image configuration mode will automatically switch between day and night according to the schedule. -
Page 26: Osd Configuration
5.2.3 OSD Configuration Go to VideoOSD interface as shown below. Set time stamp, device name, OSD content and picture overlap here. After enabling the corresponding display and entering the content, drag them to change their position. Then click the “Save” button to save the settings. Show Azimuth: Show the PTZ moving direction on the live view interface. -
Page 27: Ptz Configuration
2. Click direction buttons to change the area you want to mask. 3. Click “Draw Area” and then drag the mouse to draw the video mask area. 4. Click “Add” to add the mask area. 5. Return to the live to verify that the area have been drawn as shown as blocked out in the image. To clear the video mask: Select the mask area in the mask area list and then click the “Delete”... -
Page 28: Other Alarms
1. Check “Enable” check box to activate motion based alarms. If unchecked, the camera will not send out any signals to trigger motion-based recording to the NVR or CMS, even if there is motion in the video. Trigger Snap: If selected, the system will capture images on motion detection and save the images on an SD card. Trigger SD Recording: If selected, video will be recorded on an SD card on motion detection. -
Page 29: Alarm Server
2. Click “Enable” and set the alarm holding time. 3. Set alarm trigger options. The setup steps are the same as motion detection. Please refer to motion detection chapter for details. SD Card Error When there are some errors in writing SD card, the corresponding alarms will be triggered. 1. -
Page 30: Smart Tracking
5.4.4 Smart Tracking The tracking option is available for line crossing detection, region entrance and exiting and intrusion detection. Smart Tracking: When people or vehicle cross the alarm line or intrude or exit the predefined area, the PTZ camera will automatically track them and the target image will be automatically zoomed in and centered on the screen until the target disappears on the screen. -
Page 31: Analytics Configuration
Note: Clicking the “Unlock” button suspends object tracking until you click the “Lock” button. If you want to change the start tracking position, you can click “Unlock” button to enable PTZ control. After that, please remember to lock the PTZ, or object tracking will not take effect. -
Page 32: Line Crossing
1. Enable the applicable detection that’s desired. Scene Change Detection: Alarms will be triggered if the scene of the video has changed. Video Blur Detection: Alarms will be triggered if the video becomes blurry. Enable Video Color Cast Detection: Alarms will be triggered if the video becomes obscured. 2. - Page 33 1. Enable line crossing alarm and select the snapshot type and the detection target. Save Panoramic Picture: If it is enabled, the detected panoramic pictures will be captured and saved to the SD card when there are targets detected. Save Target Cutout: If it is enabled, the detected target cutout pictures will be captured and saved to the SD card when there are targets detected.
-
Page 34: Intrusion
Set the alarm line number and direction. Up to 4 lines can be added. Multiple lines cannot be added simultaneously. Direction：A<->B, A->B and A<-B optional. This indicates the direction of the intruder who crosses over the alarm line that would trigger the alarm. -
Page 35: Region Entrance
3. Click the “Save” button to save the settings. 4. Set the alarm area of the intrusion detection. Click the “Area” tab to go to the interface as shown below. Set the alarm area number on the right side. Up to 4 alarm areas can be added. Set the detection area by clicking the buttons of area ①... -
Page 36: Region Exiting
1. Enable region entrance detection, select the snapshot type and the detection target and set the alarm holding time and alarm trigger options. The detection setup steps are the same as line crossing detection. Please refer to the detection configuration of line crossing detection for details. -
Page 37: Target Counting
1. Enable region exiting detection, select the snapshot type and the detection target and set the alarm holding time and alarm trigger options. The detection setup steps are the same as line crossing detection. Please refer to the detection configuration of line crossing detection for details. - Page 38 2. Enable target counting and select the snapshot type and the detection target. Detection Target: Select the target to calculate. Human, motor vehicle and motorcycle/bicycle can be selected. Counting Reset: The current number of the target counting can be reset. You can choose to reset the counting daily, weekly or monthly.
-
Page 39: Face Comparison
5.5.7 Face Comparison 1. Go to Analytics Face Detection as shown below. 2. Enable the face detection function. Save Source Information: if checked, the whole picture will be saved to an SD card when detecting a face. Save Face Information: if checked, the captured face picture will be saved to an SD card when detecting a face. Note: To save images to a local PC, please enable the local smart snapshot storage first (SystemLocal Recording). - Page 40 Use this to draw the approximate size of the face that you want the camera to capture. This is useful when there are multiple faces in the background or foreground that are not needed to be captured. To enable, Click “Draw Area” and drag the border lines of the rectangle to modify its size.
- Page 41 Click “Modify” to change people information and click “Delete” to delete this face picture. Set face comparison trigger options. Click “Comparison and Linkage” to go to the following interface. Deduplication Period: In the set period, delete the repeated comparison results. Similarity threshold: When the similarity of the captured face picture and the face picture added into the face database exceeds the similarity threshold, alarms will be triggered.
-
Page 42: Network Configuration
Area ①: captured face pictures; area ②: face comparison area View the comparison details In area ②, click the compared face picture to bring up the following window. In this interface, you can view the detailed comparison information. Add captured face pictures to the face database ... -
Page 43: Port
Use IP address (take IPv4 for example)-obtain a local IP address automatically through DHCP. A typical router has a DHCP server built in, and therefore is able to assign an IP address to the camera. Use PPPoE-Click the “PPPoEConfig” tab to go to the interface as shown below. Enable PPPoE and then enter the user name and password from your ISP. -
Page 44: Server Configuration
HTTP Port: The default HTTP port is 80. It can be changed to any port which is not occupied. HTTPS Port: The default HTTPs port is 443. It can be changed to any port which is not occupied. Data Port: The default data port is 9008. Please change it as necessary. RTSP Port: The default port is 554. -
Page 45: Snmp
5.6.5 SNMP To get camera status, parameters and alarm information and remotely manage the camera, the SNMP function can be used. Before using SNMP, please install an SNMP management tool and set the parameters of the SNMP, such as SNMP port, trap address. 1. -
Page 46: 802.1X
5.6.6 802.1x If it is enabled, the camera’s data can be protected. When the camera is connected to the network protected by the IEE802.1x, user authentication is needed. To use this function, the camera shall be connected to a switch supporting 802.1x protocol. The switch can be reckoned as an authentication system to identify the device in a local network. -
Page 47: Upnp
5.6.8 UPNP If this function is enabled, the camera can be quickly accessed through the LAN. Go to Network SetupUPnP. Enable UPNP and then enter UPnP name. 5.6.9 Email If you need to trigger Email when an alarm happens or IP address is changed, please set the Email here first. Go to Network Setup... -
Page 48: Https
Server Name: The name of the FTP server. Server Address: The IP address or domain name of the FTP. Upload Path: The directory where files will be uploaded to. Port: The port of the FTP server. Use Name and Password: The username and password that are used to login to the FTP server. 5.6.11 HTTPS HTTPs provides authentication of the web site and protects user privacy. -
Page 49: Qos
Click the “Create” button to create a private certificate. Enter the country (only two letters available), domain (camera’s IP address/domain), validity date, password, province/state, region and so on. Then click “OK” to save the settings. * Click “Create a certificate request” to enter the following interface. Click “Create”... - Page 50 Add user: 1. Click “Add” to pop up the following textbox. 2. Enter user name in “User Name” textbox. 3. Enter letters or numbers in “Password” and “Confirm Password” textbox. Please set the password according to the requirement of the password security level (Go to SetupSecuritySecurity ManagementPassword Security interface to set the security level). 4.
-
Page 51: Online User
3. Enter the old password of the user in the “Old Password” text box. 4. Enter the new password in the “New password” and “Confirm Password” text box. 5. Enter computer’s MAC address as necessary. 6. Click the “OK” button to save the settings. Note: To change the access level of a user, the user must be deleted and added again with the new access level. -
Page 52: Maintenance Configuration
enabled, login failure after trying six times will make the login interface locked. The camera can be logged in again after a half hour or after the camera reboots. Password Security Please set the password level and expiration time as needed. Password Level: Weak, Medium or Strong. -
Page 53: Reboot
5.8.2 Reboot Go to MaintenanceReboot. Click the “Reboot” button to reboot the device. Timed Reboot Setting: If necessary, the camera can be set up to reboot on a time interval. Enable “Time Settings”, set the date and time and then click the “Save”... -
Page 54: Search
6 Search 6.1 Image Search In the Setup interface, click Search to go to the interface as shown below. Images that are saved on the PC or SD card can be found here. Local Image Search 1. Choose “Picture”—“Local”. 2. - Page 55 Click to return to the previous interface. SD Card Image Search 1. Choose “Picture”—“SD Card”. 2. Set time: Select date and choose the start and end time. 3. Choose the alarm events at the bottom of the interface. 4. Click to search the images.
-
Page 56: Video Search
Icon Description Icon Description Close: Select an image and click Close all: Click this button to close all this button to close the image. images. Save: Click this button to select the Save all: Click this button to select the path for saving the image on the path for saving all pictures on the PC. -
Page 57: Sd Card Video Search
Icon Description Icon Description Play button. After pausing the video, Pause button click this button to continue playing. Stop button Speed down Speed up Watermark display Enable / disable audio; drag the slider to adjust the volume after enabling audio. 6.2.2 SD Card Video Search Click Search to go to the interface as shown below. - Page 58 4. Select the alarm events at the bottom of the interface. 5. Select mix stream (video and audio stream) or video stream as needed. 6. Double click on a file name in the list to start playback. The time table can be shown in 24H/12H/2H/1H format by clicking the corresponding buttons. Video clip and downloading 1.
- Page 59 Click “Set up” to set the storage directory of the video files. Click “Open” to play the video. Click “Clear List” to clear the downloading list. Click “Close” to close the downloading window.
-
Page 60: Appendix
Appendix Appendix 1 Troubleshooting IP Scanner does not show any device. Make sure that the PC that’s running IP Scanner is on the same local network as the devices. Internet Explorer cannot download ActiveX control. IE browser may be set up to block ActiveX. Follow the steps below. 1. - Page 61 Models: O2P25X/O2P20X Federal Communications Commission (FCC) Statements This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
