Summary of Contents for Westinghouse WMF3122WA
- Page 1 USER MANUAL 31 & 40 LITRE FREESTANDING MICROWAVES WMF3122WA, WMF3122SA, WMF4102SA, WMF4102WA, WMF4102BA...
-
Page 2: Table Of Contents
Products must be used, installed and operated in accordance with this manual. You may not be able to claim on the Westinghouse manufacturer’s warranty in the event that your product fault is due to failure to adhere this manual. -
Page 3: General Warnings
GENERAL WARNINGS Please read the user manual carefully and store in a handy • Do not heat liquids and other foods in sealed place for later reference. Pass the user manual on to containers. They are liable to explode. possible new owners of the appliance. •... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Installation Care and cleaning WARNING WARNING Only a qualified person must install this appliance. Risk of injury, fire or damage to the appliance. • Remove all the packaging. • Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket. •... - Page 5 CAUTION Steam will escape, when opening lids or wrapping foil. Specifications Model: WMF4102WA / WMF4102SA / WMF4102BA WMF3122WA / WMF3122SA Rated Voltage: 230-240V~ 50Hz 230-240V~ 50Hz Rated Input Power (Microwave): 1450-1550W 1450-1550W Rated Output Power (Microwave): 1050-1100W 1000W Oven Capacity:...
-
Page 6: Before First Use
BEFORE FIRST USE Make sure that all the packing materials are removed NOTE: from the inside of the door. • If you have any questions about the grounding or electrical instructions, consult a qualified electrician or service person. WARNING • Neither the manufacturer nor the dealer can accept Check the microwave for any damage, such as any liability for damage to the microwave or personal... -
Page 7: Setting The Time
• Round/oval dishes rather than square/oblong ones are recommend, as food in corners tends to overcook. • Narrow strips of aluminum foil may be used to prevent overcooking of exposed areas. But be careful don’t use too much and keep a distance of 1 inch (2.54cm) between foil and cavity. -
Page 8: Product Description
PRODUCT DESCRIPTION CONTROL PANEL Models WMF4102SA, WMF4012WA, WMF4102BA, WMF3122SA, WMF3122WA Control panel Turntable shaft Turntable ring Glass tray Observation window Oven door Safety interlock system Accessories Quick Touch Presets - Sensor Menu (Sensor Reheat, Frozen Pizza, Frozen Meal, Potato, Rice, Veggie ) -
Page 9: Daily Use
DAILY USE Defrosting butter or similar WARNING • Do not fully defrost the food in the appliance, but Refer to the safety chapters. let it defrost at room temperature. This gives a more even result. Fully remove all metal or aluminium packaging before defrosting. - Page 10 DAILY USE (CONTINUED) Suitable cookware and materials MICROWAVE COOKWARE / MATERIAL DEFROSTING HEATING COOKING Ovenproof glass and porcelain (with no metal components, e.g. Pyrex, heat- proof glass) Non-ovenproof glass and porcelain Glass and glass ceramic made of ovenproof / frost-proof material (e.g.
- Page 11 Power setting table LEVEL Power 100% Display PL10 One Touch Start Custom Defrost Function Instant cooking at 100% power level and 1 to 6 Press , “dEF1” and “DEF.” will appear in the minutes cooking time can be started by pressing display.
- Page 12 DAILY USE (CONTINUED) Auto menu table During cooking: • The food can be covered, but the cover or lid must be MENU FOOD DISPLAY WEIGHT/ vented with a hole to allow steam to escape. BUTTON PORTION • Wait until the cooking time is displayed and starts Custom Bacon CC-1...
- Page 13 Multi-stage cooking Popcorn At most 2 stages can be set for cooking. If one stage is Press repeatedly until the number you wish Defrost, it will automatically set to be the first stage. appears in the display, “50”, “85”, “100” g will display in order.
-
Page 14: Using The Accessories
USING THE ACCESSORIES ADDITIONAL FUNCTIONS Timer WARNING Press , “00:00” and “Timer” will appear in the Refer to the safety chapters. display. Press the number pads to enter the time amount. The maximum amount of time that can be entered is 99 CAUTION minutes, 99 seconds. -
Page 15: Helpful Hints And Tips
HELPFUL HINTS AND TIPS Power setting table PROBLEM REMEDY You cannot find details for the amount of food prepared. Look for a similar food. Increase or shorten the length of the cooking times according to the following rule: Double the amount = almost double the time Half the amount = half the time The food got too dry. -
Page 16: Troubleshooting
TROUBLESHOOTING WARNING Refer to the safety chapters. PROBLEM POSSIBLE CAUSE REMEDY Electrical cord for oven is not Plug into the outlet. Oven will not start plugged in. Door is open. Close the door and try again. Wrong operation is set. Check instructions. -
Page 17: Installation
INSTALLATION 7.5cm CAUTION 30cm Do not block the air vents. If you do that, the appliance can overheat. CAUTION Do not connect the appliance to adapters or extension 7.5cm leads. This can cause overloading and risk of fire. • Put the appliance far away from steam, hot air and water splashes. - Page 18 INSTALLATION (CONTINUED) Electrical installation WARNING Only a qualified person must do the electrical installation. IMPORTANT The manufacturer is not responsible if you do not follow the safety precautions from the chapter “Safety Instructions”. This appliance is supplied with a main cable and main plug.
-
Page 19: Warranty
(c) ‘ASC’ means Electrolux’s authorised serviced centres; (a) the Appliance has been, or Electrolux reasonably believes that the (d) ‘Westinghouse ’ is the brand controlled by Electrolux Home Products Appliance has been, used for purposes other than those for which Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004... - Page 20 The Electrolux Group to consumers including delivery, home service and spare parts. and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation. Used under license by Electrolux Home Products Pty Ltd. All Rights Reserved. © 2018 Electrolux Home Products Pty Ltd.
