CRT ALPHA Owner's Manual

Mobile cb transceiver am-fm citizen band european multi-norms 12/24v
Hide thumbs
Table of Contents

Advertisement

Quick Links

1000 000 euros

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALPHA and is the answer not in the manual?

Questions and answers

Related Manuals for CRT ALPHA

Summary of Contents for CRT ALPHA

  • Page 1 1000 000 euros...
  • Page 2 2021...

  • Page 4: Table Of Contents

    Band norme setting/Emergency channel Setting Resume factory default CTCSS/DCS Codes European restrictions 14-15 Specifications Frequencies table Supplied Accessories Mobile installation/Power supply connection Antenna installation/Basic operation/Ajustment of SWR 20-21 Conditions of guarantee/Procedure on returning to the aftersales service CRT Declaration of conformity...

  • Page 5: Symbols Description

    Restrictions - 1 -...

  • Page 6: Warning Before Use - Precautions

    This transceiver corresponds to the requirements of European directive RED 2014/53/EU documents n°62 368 -1, EN 301 489 - 1/ - 13, EN 300 RED 2014/53/EU documents n°62 433, EN 62311. - 2 -...
  • Page 7 - 3 -...

  • Page 8: Know About This Radio - Microphone Connection

    1. KNOW ABOUT THIS RADIO AM/FM MENU SQ/AQ EXT.SP POWER Mode/Keypad lock Squelch control, SQ, ASQ switch key Microphone Jack Channel up selector Channel down selector Emergency channel Power On/Off Volume control External speaker Jack Antenna Jack Down Connector Microphone cable - 4 -...

  • Page 9: Lcd - Functions And Features

    2. LCD RF Gain Automatical Squelch Key lock Noise Blanker Beep sound TALKBACK Emergency channel HI-CUT Roger Beep BAND name Channel AM/FM mode TX/RX S-meter Channel/Frequency /Menu CTCSS FUNCTIONS AND FEATURES AM : MODE AM/FM VOX FUNCTIONS (TRANSMIT WITHOUT PRESS PTT) (in Vox function , the squelch must be always engaged) AQ : SQ,ASQ FUNCTION RFG : RF GAIN FUNCTION –...

  • Page 10: How To Use This Radio

    3. HOW TO USE THIS RADIO 3.1 Power On/Off the Radio ..............Turn VOL switch clockwise to power on the radio, the LCD displays the Norms and then displays channel number. Turn VOL switch anti-clockwise, until hear Ka Ta, the radio is powered off.

  • Page 11: Am-Fm/Emg/Scan Function

    ....................※Mode Control (short press) Short press , key to switch between mode. The LCD displays the selected mode. ※Keypad Lock (long press) Long press key for over 2 seconds to lock the keys, LCD displays Long press key for over 2 seconds again to unlock the keys disappears form LCD.

  • Page 12: Vox Function/Talkback Level/Norms Control

    3.8 VOX function ..................The VOX function allows transmitting by speaking into the original microphone without pressing the PTT switch. Press [PTT] + [EMG] key to activate VOX function, LCD displays microphone icon, and then press [PTT] + [EMG] key to disable VOX function.

  • Page 13: Install External Speaker/Menu Operations

    3.11 Install External Speaker .............. Choose a 8Ω external speaker with 3.5 mm mono connector. 3.12 Menu Operations ................Long press key to enter menu list. Short press microphone [ UP ] or [ DN ] or to choose menu to be.
  • Page 14 NO. LCD display Function detail Setting details 1~9: Total 9 levels VOX Time Default: 4 , 1~9 Talkback level control Default: : turn off ANL/NB function : turn on ANL/NB function Noise blanker Default: Level AU 03,06,09~48 Default: oF RF gain level Note: If the AUTO RFG function is on, control the radio will turn on the automatic...

  • Page 15: Band Norme Setting/Emergency Channel Setting

    3.13 Band Name Setting ..............Choose a band to be modified. Long press key to enter menu list. Short press microphone [ UP ] or [ DN ] or to choose BAND name function memu, LCD displays Short press key, the first digit blinks on LCD. Short press microphone [ UP ] or [ DN ] or to choose the character of the first digit.

  • Page 16: 3.15 Resume Factory Default

    Short press key to validate the channel,and the mode blinks on LCD. Short press microphone [ UP ] or [ DN ] or (10) to choose the mdoe AM or FM. (11) Short press key to validate the mode and exit setting. (12) Long press key or wait 10 seconds to store exit MENU.

  • Page 17: Ctcss/Dcs Codes

    CTCSS/DCS codes - 13 -...

  • Page 18: European Restrictions

    European Restrictions 40 ch 4 W AM-FM - 14 -...
  • Page 19 - 15 -...

  • Page 20: Specifications

    4. SPECIFICATION GENERAL Modulation Mode AM/FM Frequency Range 26.965-27.405MHz Frequency Tolerance ±5.0ppm Input Voltage 12/24V Dimensions 185x124x38mm Weight 620g Operating Temperature Range -20℃ to +50℃ Transmit 3A MAX Current Drain Receive Squelched 0.3A VOL Max 0.7A Antenna Connector UHF, SO-239 TRANSMITTER Power Output 4 Watts FM/AM...

  • Page 21: Frequencies Table

    - 17 -...

  • Page 22: Supplied Accessories

    AM/FM MENU SQ/AQ Manual Fuse Microphone bracket - 18 -...

  • Page 23: Mobile Installation/Power Supply Connection

    - 19 -...

  • Page 24: Antenna Installation/Basic Operation/Ajustment Of Swr

    The voltage has to be 13,8V or 24 V DC with negative grounding. Ensure that the positive (+, red) and negative (-, black) polarity is correct, before you connect the radio. The wiring has to be done by an authorized technician. Connect the power cable directly with the battery.
  • Page 25 - 21 -...

  • Page 26: Conditions Of Guarantee/Procedure On Returning To The Aftersales Service Crt

    - 22 -...

  • Page 27: Declaration Of Conformity

    DECLARATION OF CONFORMITY N° 200240 We hereby declare under our responsability that the product : Brand : CRT Model : ALPHA Description : Mobile transceiver Satisfies all the technical regulations applicable to the product within the scope of directive RED 2014/53/EU european standarts EN 62368-1 :2014+A11 :2017 EN 301 489-1 V2.2.1...
