DIGITAL VIDEO
SURVEILLANCE RECORDER
WITH MOTION DETECTION
AND AUDIO RECORDING
Instruction Manual
English Version 1.0
MODELS:
L204 & L208 Series
www.lorexcctv.com
Includes L204 & L208
Copyright © 2007 Lorex Technology Inc.
