- Page 1 EP1000 PLC Quick User Manual (Version: V1.00)
- Page 2 Version History Date Version Description 2015-03-20 V1.00 Initial release.
-
Page 3: Table Of Contents
EP1000 PLC Quick User Manual Contents Chapter 1 Product Overview ..................1 1.1 Overview ......................1 1.2 Module Diagram ....................1 1.3 EPX-Programmer .................... 3 Chapter 2 Installation ....................4 2.1 Matters Need Attention ..................4 2.2 Assemblage ..................... 5 2.3 Wiring ....................... -
Page 4: Chapter 1 Product Overview
EP1000 PLC Quick User Manual Chapter 1 Product Overview 1.1 Overview The EP1000 series is a line of networking micro-programmable logic controllers (Networking Micro PLCs) that can control a variety of automation applications. The user program can be composed many instructions, including Bit Logic, Counter, Timer, Math, complicated data processing, and communication, which make the PLC can be monitored the input status and changed the output status for the controlling. - Page 5 EP1000 PLC Quick User Manual INPUT EP1121 INPUT EP1161 RELAY EP1213 MOS EP1231 OUTPUT EP1234 OUTPUT EP1252 OUTPUT EP1222 ANALOG EP1A11...
-
Page 6: Epx-Programmer
EP1000 PLC Quick User Manual 1.3 EPX-Programmer EPX-Programmer Editor makes it easy for you to study and design a micro PLC program, and you can carry out the following task: Set up PLC (CPU) type Create a PLC program ... -
Page 7: Chapter 2 Installation
EP1000 PLC Quick User Manual Chapter 2 Installation 2.1 Matters Need Attention Installation mode You can install the EP1000 PLCs either on a panel or on a standard rail, and you can orient the EP100 PLCs either horizontally or vertically. -
Page 8: Assemblage
EP1000 PLC Quick User Manual Installation space EP1000 PLCs are designed for natural convection cooling. For proper cooling, you must provide a clearance of at least 150 mm above and below the devices. Also, allow at least 150 mm of depth. - Page 9 EP1000 PLC Quick User Manual There is a toggle switch S1 on the left of EP1002 module, which is used for identifying the terminal. When the modules have been assembled, the EP1002 module on the very right must turn the toggle switch to ON, while the other EP1002 modules must turn the toggle switch to OFF.
-
Page 10: Wiring
EP1000 PLC Quick User Manual Choose a proper position for the mounting. Make sure the clasp is jointed the DIN Rail correctly, and the DIN Rail must be grounded. Caution 2.3 Wiring Make sure the power supply is cut off before your wiring. -
Page 11: Wiring Of Communication Module
EP1000 PLC Quick User Manual 2.3.2 Wiring of Communication Module Diagram Sign Description CAN Connection CAN_L 3-core Connect to the Twisted-pair Shell of DB Cable Shielding CAN_H Twisted pair Ground wire of CAN CAN_GND Others Null 485A RS485 Connection Twisted-pair... -
Page 12: Wiring Of Input Module
EP1000 PLC Quick User Manual 2.3.3 Wiring of Input Module EP1161 Diagram Sign Description Common port for the ports of I0 to 24VDC The input signal ports Common port for the prots of I9 to 24VDC The input signal ports... - Page 13 EP1000 PLC Quick User Manual EP1121 Diagram Sign Description Common port for the ports of I0 to 24VDC The input signal ports Common port for the ports of I4 to 24VDC The input signal ports The common port for the input signals is ambipolar.
-
Page 14: Wiring Of Output Module
EP1000 PLC Quick User Manual 2.3.4 Wiring of Output Module EP1222 Diagram Sign Description Common port for the ports of Q0 to The output signal ports Common port for the ports of Q4 to The output signal ports... - Page 15 EP1000 PLC Quick User Manual EP1252 Diagram Sign Description Common port for the ports of Q0 to The output signal ports Common port for the ports of Q4 to The output signal ports Common port for the ports of Q8 to...
- Page 16 EP1000 PLC Quick User Manual EP1234 Diagram Sign Description +24V 24VDC The output signal ports +24V 24VDC The output signal ports...
- Page 17 EP1000 PLC Quick User Manual EP1231 Diagram Sign Description +24V 24VDC The output signal ports +24V 24VDC The output signal ports...
- Page 18 EP1000 PLC Quick User Manual EP1213 Diagram Sign Description +24V The output signal port 24VDC The output signal port +24V 24VDC The output signal port The output signal port...
-
Page 19: Wiring Of Analog Module
EP1000 PLC Quick User Manual 2.3.5 Wiring of Analog Module Diagram Sign Description Short R0 and 0+, then combine with 0-: Channel 0 is used for current sampling; Combine 0+ with 0-: Channel 0 is used for voltage sampling. Reserved... -
Page 20: Wiring Of Power Supply Module
EP1000 PLC Quick User Manual 2.3.6 Wiring of Power Supply Module Diagram Sign +24V... -
Page 21: Chapter 3 Basic Operation
EP1000 PLC Quick User Manual Chapter 3 Basic Operation 3.1 Connect to PC To carry out your programming, you need connect the PLC to a PC. We suggest you using the standard cable of RS232 for the connecting, as shown in Figure 3-1. -
Page 22: Starting Epx-Programmer
EP1000 PLC Quick User Manual 3.2.2 Starting EPX-Programmer Open the EPX-Programmer editor. When success in installing, there is a shortcut icon EPX-Programmer.exe created on your desk. Double-click icon to open a new project, as shown in Figure 3-2. Operation Program Editor (LAD&STL) -
Page 23: Create A Sample Program
EP1000 PLC Quick User Manual 3.3 Create a Sample Program 3.3.1 Description Entering this example of a control program will help you understand how easy it is to use EPX-Programmer. This program uses six instructions in three networks to create a very simple, self-starting timer that resets itself. -
Page 24: Procedure
EP1000 PLC Quick User Manual 3.3.2 Procedure Step 1 Open EPX-Programmer editor. Step 2 Entering Network 1: Starting the Timer. When M0.0 is off (0), this contact turns on and provides power flow to start the timer. To enter the contact for M0.0: Either double-click the Bit Logic icon or click on the plus sign □... -
Page 25: Download The Sample Program
Select the File > Save As menu command from the menu bar. Enter a name for the project in the Save As dialog box. Click OK to save the project. After saving the project, you can download the program to the EP1000 PLC. ----END 3.4 Download the Sample Program Open the sample program. -
Page 26: Run The Program
Select the PLC > RUN menu command from the menu bar. Click OK on the pop-up dialog box. When the EP1000 PLC goes to RUN mode, the output LED for Q0.0 turns on and off as the EP1000 PLC executes the program. - Page 27 EP1000 PLC Quick User Manual Figure 3-4 Force a value The EP1000 PLC only allows you to force any or all of the I/O points (I and Q bits).
-
Page 28: Appendix A Modules Dimension
EP1000 PLC Quick User Manual Appendix A Modules Dimension CPU EP1900 Unit: millimeter 29.9 75.5 COMM EP18x0 Unit: millimeter 79.5 20.9... - Page 29 EP1000 PLC Quick User Manual INPUT EP1161 Unit: millimeter 27.8 20.9 84.5 RELAY EP1252 Unit: millimeter 27.8 20.9 84.5...
- Page 30 EP1000 PLC Quick User Manual MOS EP1213 Unit: millimeter 27.8 84.6 20.9 POWER EP1002 Unit: millimeter 27.8 20.9 84.5...
