Summary of Contents for Insignia NS-RGFCES2
- Page 1 USER GUIDE 4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry NS-RGFCES2 / NS-RGFCES2-C Before using your new product, please read these instructions to prevent any damage.
-
Page 2: Table Of Contents
Contents IMPORTANT SAFETY PRECAUTIONS..............3 Anti-tip device. -
Page 3: Important Safety Precautions
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Selecting the 12-hour or 24-hour display setting ..............30 Using the timer . -
Page 4: Important Safety Instructions
WARNING • Do not step, lean, or sit on the doors of the range. You can cause the range to tip, resulting in burns or serious injuries. • Confirm that the Anti-Tip device is installed properly. Then, to verify that the Anti-Tip device is engaged, grasp the top rear edge of the range and carefully attempt to tilt it forward. - Page 5 4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Additional safety instructions • Do not store items in or on the appliance. Do not store flammable materials in the oven or near the surface elements. Be sure all packing materials are removed from the appliance before operating it. Keep plastics, clothes, and paper away from parts of the appliance that may become hot.
- Page 6 WARNING If the surface is cracked, switch off and unplug the appliance to avoid the possibility of electrical shock. Do not use your cooktop until the glass surface has been replaced. WARNING • Disconnect the range from AC power or turn off its breaker circuit before replacing the lamp to avoid the possibility of electric shock.
- Page 7 4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Glass/ceramic cooking surfaces • DO NOT TOUCH SURFACE ELEMENTS OR AREAS NEAR ELEMENTS. Surface elements may be hot even though they are dark in color. Areas near surface elements may become hot enough to cause burns. During and after use, do not touch, or let clothing or other flammable materials contact the surface elements or areas near the elements until they have had sufficient time to cool.
- Page 8 • If any foreign substance such as water has entered the appliance, contact your nearest service center. • Failing to do so may result in electric shock or fire. • Do not touch the power cord with wet hands. • This may result in electric shock. •...
-
Page 9: Features
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry • Take care that children do not come too close to the appliance. • Failing to do so may result in children burning themselves. • Do not place food or heavy objects over the edge of the oven door. •... -
Page 10: Main Components
Main components Glass surface Surface control knob Oven control panel Oven door switch Shelf position Oven door Oven light Oven fan Gasket Storage drawer www.insigniaproducts.com... -
Page 11: Oven Control Panel
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Oven control panel TOUCHPAD DESCRIPTION Turns on the fan while baking. Provides more consistent heat by circulating the air inside the oven while baking. Cooks large amounts of baked goods on Bake (Convection Bake) multiple shelves at the same time. -
Page 12: Range Dimensions
TOUCHPAD DESCRIPTION 18 Timer On / Off Turns on the kitchen timer for the amount of time you want. Press and hold for three seconds to turn on the clock set feature, then set the (clock set) current time. Press and hold for three seconds to turn off the control panel touch pads to (lock) prevent the oven from accidentally being turned on. -
Page 13: Installing
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Installing 4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Selecting a location ........14 Clearances and dimensions. -
Page 14: Selecting A Location
Selecting a location Clearances and dimensions BEFORE YOU BEGIN to install your range, refer to the following information, dimensions, and clearances. Do not install your range where it may be subject to strong drafts. Provide adequate clearances between your range and adjacent combustible surfaces. -
Page 15: Electrical Requirements
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Minimum dimensions Make sure that the wall covering, countertop, flooring, and cabinets around your range can withstand the heat up to 194° F (90° C) that your range generates. Allow a 30 in. -
Page 16: Installing Your Range
Installing your range WARNING: We recommend that a professional installer install your range. If your range is not installed correctly, incorrect electrical grounding can cause a fire or explosion which can lead to injury or death. Tools you need (not included) 1/4 in. -
Page 17: Connecting The Power Cord
Failure to do any of the above could result in a fire, personal injury, or electrical shock. Note: The power cord connections described below are only applicable to NS-RGFCES2. NS-RGFCES2-C comes with a power cord. Remove the terminal block cover 1 Remove the screw that secures the terminal block cover to the back of your range. - Page 18 3 For the conduit installation, insert the conduit strain relief in the 1 1/8 in. (2.8 cm) conduit hole, then install the conduit through the body of the strain relief and fasten the strain relief with its ring. Power cord hole Ring Conduit hole Body...
- Page 19 4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry 7 CAUTION: Check the voltage after connecting the power cord. Live 1 - Neutral 120V Live 2 - Neutral 120V Live 1 - Live 2 208V / 240V 8 Go to Replace the terminal block cover on page 20.
-
Page 20: Installing The Anti-Tip Device
Replace the terminal block cover Terminal block cover 1 Make sure that the cable is tightened in place using the strain relief. See step 2 in Remove the terminal block cover on page 17. 2 Align the terminal block cover with the screw holes on the back of your range. 3 Insert the screw you removed earlier through the holes in the cover and into the holes on the back of your range. -
Page 21: Leveling Your Range
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Leveling your range Your range should be level. If your range is not level, the door may not close or seal correctly which can cause uneven heating and electric wastage problems. Note: •... -
Page 22: Installing The Plastic Pads
3 Place the door handle against the oven door and fit it on the connection part. 4 Use the Allen wrench to tighten both sides of the door handle. Installing the plastic pads To prevent your range from getting too close to the wall behind the range, install the included plastic pads. 1 Locate the plastic pad kit. -
Page 23: Operating Instructions
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Operating instructions 4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Before you begin using your range......24 Tips for saving energy . -
Page 24: Before You Begin Using Your Range
Before you begin using your range WARNING: All electrical equipment with moving parts can be dangerous. Make sure that you read and understand all safety information. See IMPORTANT SAFETY PRECAUTIONS on page 3. Before turning on the burners or oven: •... -
Page 25: Identifying The Burners
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry The cooktop burners are radiant surface elements. When you turn on an element, the temperature rises gradually and evenly. As the temperature rises, the radiant element glows red. To maintain the selected setting, the element cycles on and off. -
Page 26: Using A Surface Element Control Knob
Using a surface element control knob SETTING TYPE OF COOKING HIGH Starting most foods, bringing water to a boil, or pan broiling MEDIUM HIGH Continuing a rapid boil, frying, deep fat frying, or steaming vegetables MEDIUM Maintaining a slow boil or thickening sauces and gravies, MEDIUM LOW Keeping foods cooking, poaching, or stewing Keeping food warming or melting... -
Page 27: Protecting The Ceramic Cooktop
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Types of cookware What your cookware is made of determines how evenly and quickly heat is transferred from the surface element to the pan bottom. MATERIAL DESCRIPTION Aluminum Excellent heat conductor. -
Page 28: Using The Oven
Using the oven Minimum and maximum settings WARNING: Stand away from the oven when opening the oven door. Escaping hot air or steam can burn your hands, face, or eyes. Let hot air or steam escape before removing or replacing food. FUNCTION MINIMUM SETTING MAXIMUM SETTINGS... -
Page 29: Using The Oven Vent
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry • Centering the baking pans in the oven produces better cooking results. • When baking multiple items, make sure that you leave a 1 to 1.5 in. (2.5 to 3.8 cm) space around each item. •... -
Page 30: Using The Oven Light
Using the oven light The oven has a light that is located on the rear oven wall in the upper left rear corner. Oven light • Touch the Oven Light pad to turn the light on or off. The oven light lets you check the cooking progress without opening the oven door. -
Page 31: Baking
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Baking The Bake function lets you program the oven to bake to any temperature between 150° F (66° C) and 550° F (288° C). 1 Position the oven rack where you want it. 2 Press the Bake pad. -
Page 32: Air Frying
Air Frying The Air Fry feature uses hot air for crispier and healthier frozen or fresh foods without any (or less than normal) oil compared to convection modes. The Air Fry feature works best for single rack baking with packaged and convenience foods. Make sure that you remove the packaging from food before cooking it. -
Page 33: Programming A Delayed Start Time
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry 7 To change the programmed baking temperature, press the Bake pad, enter the new baking temperature, then press the Start pad. The oven completes cooking at the new temperature. 8 To change the cooking time, press the Cook Time pad, enter the new cooking time, then press the Start pad. -
Page 34: Keeping Food Warm
Broiling guide This guide is for reference only. • The size, weight, thickness, starting temperature, and your doneness preference affect broiling times. • If you covered the meat with aluminum foil and you let it stand covered for 10 minutes after cooking is complete, the internal temperature increases by 5-10°... -
Page 35: Maintenance
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Maintenance 4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Cleaning and maintenance....... . . 36 Cleaning the control panel . -
Page 36: Cleaning And Maintenance
Cleaning and maintenance WARNING: • Always make sure that the controls are off and all surfaces are cool before removing or cleaning any of the range parts. This will prevent you from getting burned. • If your range is pulled out from the wall for any reason, make sure that the anti-tip device is reengaged after your range has been pushed back into place. -
Page 37: Cleaning The Oven Door
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Cleaning the oven door CAUTION: • DO NOT clean the oven door gasket. The oven door gasket is made of a woven material which is essential for a good seal. Care should be taken not to rub, damage, or remove this gasket. - Page 38 Normal daily use cleaning Note: Daily use of a ceramic cooktop cleaner helps keep the cooktop looking new. Use only a ceramic cooktop cleaner. Other cleaners may not be as effective. By following these steps, you can maintain and protect the surface of the glass cooktop. Before using the cooktop for the first time, clean it with a ceramic cooktop cleaner.
-
Page 39: Removing And Replacing The Oven Door
WARNING: • We recommend that you do not remove the door unless directed to do so by Insignia Customer Service. • The oven door is heavy. Do not lift the door by its handle. Be careful not to drop the door during removal. Incorrect handling could result in personal injury. - Page 40 3 Hold the door firmly on both sides. www.insigniaproducts.com...
- Page 41 4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry 4 Disengage the hinges and remove the door gently with a 30° angle between the door and the oven. Place the door on a protected surface. www.insigniaproducts.com...
- Page 42 Replacing the door 1 Hold the door firmly in almost half open position. Notch 2 Insert the hinge tongues into the slots making sure that the notches on both sides drop into place. 3 Open the door fully. www.insigniaproducts.com...
-
Page 43: Removing And Replacing The Storage Drawer
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry 4 Fully close the levers on the left and right hinges, then close the door. Removing and replacing the storage drawer The storage drawer is a good place to store cookware and bakeware. Don’t store plastics or flammable material in the drawer. -
Page 44: Self-Cleaning The Oven
Self-cleaning the oven CAUTIONS: • Do not leave small children unattended near your range during the self-cleaning cycle. The outside surfaces of the range can get extremely hot. • Some birds are extremely sensitive to fumes from a self-cleaning oven. Relocate birds to a well-ventilated room away from your range. -
Page 45: Troubleshooting
8 After cleaning, leave the oven door ajar at a 15° angle to let the interior enamel surface dry thoroughly. Troubleshooting If the solutions in this section do not solve a problem, contact a qualified service technician or Insignia customer service. PROBLEM... -
Page 46: Cooktop
Insignia customer normal voltage. care for support. The surface burners do not A fuse in your home may be Replace the fuse or reset the circuit breaker. -
Page 47: Oven
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Oven PROBLEM POSSIBLE CAUSE SOLUTION The oven does not turn on. A fuse in your home may be Replace the fuse or reset the circuit breaker. blown or the circuit breaker tripped. -
Page 48: Drawer
PROBLEM POSSIBLE CAUSE SOLUTION Steam is coming out of the When using the convection This is normal operation, and not a system failure. Use the vent. feature, it is normal to see oven as usual. steam coming out of the oven vent. -
Page 49: Error Codes
4.8 Cu. Ft. Electric Convection Range with Self Clean and Air Fry Error codes ERROR CODE POSSIBLE CAUSE SOLUTION Oven temperature detection circuit Press Off/Clear, then restart the oven. If failure. the problem persists, disconnect all power to your range for at least 30 seconds, then After the oven starts to heat up, the reconnect the power. -
Page 50: Specifications
Specifications Dimensions (H × W × D) 36.5 to 37.5 × 29.9 × 27.1 in. (92.7 to 95.2 × 75.9 × 69 cm) NS-RGFCES2 Gross Weight: 212.7 lb (96.5 kg) Net Weight: 183 lb (83 kg) Weight NS-RGFCES2-C Gross Weight: 213.8 lb (97 kg) Net Weight: 184 lb (83.5 kg) -
Page 51: One-Year Limited Warranty
During the Warranty Period, if the original manufacture of the material or workmanship of the Product is determined to be defective by an authorized Insignia repair center or store personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. - Page 52 For product inquiries, please contact us with the information below: 1-877-467-4289 www.insigniaproducts.com INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A. ©2022 Best Buy. All rights reserved.
