Installation, Operation and Maintenance Manual
Please read and save these instructions for future reference. Read carefully before attempting to assemble, install,
operate or maintain the product described. Protect yourself and others by observing all safety information. Failure
to comply with these instructions will result in voiding of the product warranty and may result in personal injury
and/or property damage.
Table of Contents
General Louver Installation Instructions . . . . . . . . 2
Single Section Wide x Single Section High Installation 3
Single Section Wide x Multi Section High Installation. 4
Multi Section Structural Support Tables . . . . . . . . 5
Multi Wide x Single Section High - Unsupported . . . 6
Multi Wide x Single Section High - Supported . . . . 7
Multi Section Wide x Multi Section High Installation . 8
®
Horizontal Blade, Wind-Driven Rain Louvers
Models EHH-201, EHH-401, EHH-501 and EHH-601
Receiving and Handling
Upon receiving louvers, check for both obvious
and hidden damage. If damage is found, record all
necessary information on the bill of lading and file
a claim with the final carrier. Check to be sure that
all parts of the shipment, including accessories are
accounted for.
Safety Warning
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, injury
or death. Read the installation, operating, and
maintenance instructions thoroughly before installing
or servicing this equipment.
Horizontal Blade, Wind-Driven Rain Louver Models
Document 485605
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Greenheck EHH-201
Summary of Contents for Greenheck EHH-201
- Page 1 Document 485605 Horizontal Blade, Wind-Driven Rain Louvers Models EHH-201, EHH-401, EHH-501 and EHH-601 ® Installation, Operation and Maintenance Manual Please read and save these instructions for future reference. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with these instructions will result in voiding of the product warranty and may result in personal injury and/or property damage.
- Page 2 General Louver Installation Instructions Installation Instructions 1. Locate all crates, boxes, cartons, etc. 2. Use care when handling louver sections to prevent damage. Louvers are to be carefully lifted by the louver frame or supports. Use multiple lifting points when possible to avoid deformation or distortion of louver components.
- Page 3 Single Section Wide x Single Section High Installation 1. Locate the optional extended sill, if provided, and place in the opening. (Extended Sill Details) 2. Locate mounting angles and fasteners required to Figure 1.1 attach the louver to the structure. Clip angles and fasteners are by others unless the optional mounting angles have been ordered from manufacturer with the louvers.
- Page 4 Single Section Wide x Multiple Section High Installation 1. Locate the shipped loose Alignment Plates for the jambs. Following the provided Installation, Operation, and Maintenance Manual instructions Figure 2.1 included with the Alignment Plates, connect the upper and lower louver sections together. 2.
- Page 5 If additional support is not required, reference the Multiple Section Wide and Single Section High-Unsupported installation instructions. If additional support is required, reference the Multiple Section Wide and Single Section High-Supported installation instructions. Table 1.2 Table 1.1 EHH-201 EHH-401 Maximum Unsupported Height Maximum Unsupported Height Section Width (In.) At 25 PSF Wind Load (In).
- Page 6 Multiple Section Wide x Single Section High Installation - Unsupported 1. Locate the optional extended sill, if provided, and Figure 3.1 place in the opening. (Extended Sill Details) 2. Locate mounting angles and fasteners required to attach the louver to the structure. Clip angles and fasteners are by others unless the optional mounting angles have been ordered from manufacturer with the louvers.
- Page 7 Multiple Section Wide x Single Section High Installation - Supported 1. Locate the optional extended sill, if provided, and Figure 4.1 place in the opening. (Extended Sill Details) 2. Locate mounting angles and fasteners required to attach the louver to the structure. Clip angles and fasteners are by others unless the optional mounting angles have been ordered from manufacturer with the louvers.
- Page 8 Multiple Section Wide x Multiple Section High Installation Larger opening sizes require field assembly of multiple louver sections to make up the overall opening size. Individual louver sections are designed to withstand a 25 psf wind load. Structural reinforcing members may be required to adequately support and install multiple louver sections within a large opening.
- Page 9 Multiple Section Wide x Multiple Section High Installation Continued Figure 5.3 Structural Reinforcing (by others) IOM# 468788 Figure 5.4 Horizontal Blade, Wind-Driven Rain Louver Models ®...
- Page 10 As a result of our commitment to continuous improvement, Greenheck reserves the right to change specifications without notice. Product warranties can be found online at Greenheck.com, either on the specific product page or in the literature section of the website at Greenheck.com/Resources/Library/Literature.
