- Page 1 UF7C Universal Hobby Lighting Controller Installation Instructions for FW1.0 Please read instructions completely before attaching LEDs to RC.
-
Page 2: Table Of Contents
Contents LED INSTALLATION ..................3 POWER CONNECTIONS & SETTINGS ............4 BLINK MODES ....................5 MODE 0 ON/OFF ..................5 MODE 1 Watercraft ..................5 MODE 2 Basher/Crawler (for Vehicles with Brakes) ..........5 MODE 3 Crawler (for Vehicles without Brakes) ............6 MODE 4 Car 1 (Turn Signals normally OFF)............7 MODE 5 Car 2... -
Page 3: Led Installation
LED INSTALLATION Insert LEDs into LED Holders. It is Choose where to install, what size, and recommended to apply a pliable glue, such as what color LEDs are to be used. Next, choose Zap Goo or Shoe Goo, liberally making sure the the desired UF7B blink MODE (See Blink Mode glue contacts the body, the LED and LED wires. -
Page 4: Power Connections & Settings
Each time you press the MODE button the power LED will blink the number of times equivalent to the current MODE. For Example, 5 blinks indicates that the current mode is #5. After blinking, the power LED will stay on steady to indicate power. www.MyTrickRC.com... -
Page 5: Blink Modes
BLINK MODES MODE 0 ON/OFF OFF OFF OFF PORT 1 or 2 AUXILIARY POWER OUT OFF OFF OFF OFF OFF OFF Connect to CHNL 1 Vehicle Radio (3rd Channel) function CHNL 2 AUXILIARY chanel Open POWER OUT ON/OFF (Not Connected) control OFF OFF OFF Note: ON/OFF function on 3rd Channel (including Pig Tail) -
Page 6: Mode 3
Note: 1. Hazard Lights (All LEDs turn off except ports B & D that blink as hazard lights after 20 sec). You can turn OFF Hazard Lights by press-and-hold the Mode Button for 3 seconds. Repeat to turn back ON. 2. ON/OFF function on 3rd Channel (including Pig Tail) www.MyTrickRC.com... -
Page 7: Mode 4
MODE 4 Car 1 (Turn Signals normally OFF) Tail/Brake DIM Left Turn OFF Reverse OFF PORT 1 or 2 AUXILIARY POWER OUT Right Turn OFF Center Brake OFF Headlights ON Tail/Brake (brake light also turns on when in reverse) Reverse Connect to Left Turn (turn signals Vehicle Radio... -
Page 8: Mode 6
Note: 1. Hazard Lights (All LEDs turn off except ports B & D that blink as hazard lights after 20 sec). You can turn OFF Hazard Lights by press-and-hold the Mode Button for 3 seconds. Repeat to turn back ON. 2. ON/OFF function on 3rd Channel (including Pig Tail) www.MyTrickRC.com... -
Page 9: Chp/Police/Utility (Headlights Normally Off)
MODE 7 CHP/Police/Utility (Headlights normally OFF) Tail/Brake DIM Slow Strobe ON Wig Wag Strobe ON PORT 1 or 2 AUXILIARY POWER OUT Wig Wag Strobe ON Slow Strobe ON Headlights ON Wig Wag Tail/Brake normally Strobe DIM then Bright normally when braking or OFF, then reverse... -
Page 10: Aircraft 1 (With Landing Lights Normally Off)
Connect to switchable with Land- Landing ing Lights channel on PORT Lights 4th Vehicle Radio Channel (Aux Channel) ON/OFF control Open Nav Lights ON Wing Strobe ON (Not connected) Landing Lights normally OFF but turns ON with 4th channel www.MyTrickRC.com... -
Page 11: Mode 10 Aircraft 2
MODE 10 Aircraft 2 (with Landing Lights normally ON) Fuselage Strobe ON Gun LED OFF Slow Strobe ON PORT 1 or 2 AUXILIARY POWER OUT Wing Strobe ON Navigation Lights ON Landing Lights normally ON Fuselage Strobe ON Slow Strobe ON Connect to Gun LED normally OFF Vehicle Radio... -
Page 12: Mode 12 War Bird (With Slow Wig Wag Landing Lights)
Lights 4th Vehicle Radio Channel (Aux Channel) ON/OFF control Open Navigation Lights ON Slow Strobe (Not connected) Landing Lights normally ON but Slow Strobe Landing Lights turns OFF with normally ON but turns OFF 4th channel with 4th channel www.MyTrickRC.com... -
Page 13: Mode 13 Trailer
Q: My controller is working fine except the switched function (turn signals, brake lights, aircraft landing lights, or police flashers) are not switching on/off. A: Be sure your Y-Cable is plugged into the correct port on your radio. For additional trouble shooting visit www.MyTrickRC.com and select the SUPPORT tab. UF-7C Rev A...
