OneAdvisor 1000 High-Speed Network Testing Platform
Q UI CK CA RD

Ethernet Layer 2 Traffic Loopback

This quick card describes how to
device.
•
OneAdvisor 1000 equipped with the following:
100G Transport Module
o
BERT software release V30.1.0 or greater
o
C510GELAN test option for 10 Gigabit Ethernet loopback
o
C525GE test option for 25 Gigabit Ethernet loopback
o
C540GE test option for 40 Gigabit Ethernet loopback
o
C550GE test option for 50 Gigabit Ethernet loopback
o
C5100GE test option for 100 Gigabit Ethernet loopback
o
•
Optical Transceiver supporting the Ethernet data rate
to be tested (SFP or QSFP)
•
Cables to match the optical transceiver and the line under test
•
Fiber optic inspection microscope (P5000i or FiberChek Probe)
•
Fiber optic cleaning supplies
L A U N C H T E S T
Press the Power button
1.
OneAdvisor.
Press the 100G Module Test icon
2.
at the top of the screen.
Tap the Power button
3.
to launch the 100G Module.
Using the Select Test menu, Quick Launch
4.
menu, or Job Manager, launch the Ethernet
Layer 2 Traffic test on Port 1 for the desired
data rate. For example:
Ethernet ►1GigE Optical ►Layer 2 Traffic
►P1 Terminate.
Tap to open the Tools Panel and
5.
select
Press to continue.
6.
OneAdvisor 1000 High-Speed Network Testing Platform
set up the OneAdvisor 1000 100G Module as a Layer 2 Loopback
to turn on the
and click
.
VIAVI//Public
Figure 1: Equipment Requirements
Figure 2: Launch 100G Module
Figure 3: Launch Test
