4. Push claws (2 places) on accent cover, and remove the accent cover from front bezel.
Push claws toward the direction
shown by an arrow in the figure
below to remove the accent cover.
5. Connect the sensor cable to the connector on motherboard.
①
①
18
Accent cover
②
Connector for
sensor cable
Connector for
sensor cable
