3．Installing/Removing the Product to the Server
Take the steps below to install the product to the server.
● Read the sections "Safety Precautions" and "Handling precautions" in the User's Guide of the
target server to install or remove the product safely and properly.
Note: The outer dimension of T110d or T120d is as follows after the product is installed.
200.0 mm (width) X 613.5 mm (depth) X 438.0 mm (height) (projection excluded)
1. Open the front bezel, and remove it by sliding it upward.
2. Open the device door, and remove it by sliding it upward.
3. Install the dust proof door in reverse order of removal
procedure of device door (Step 2).
Device door
Dust proof door
17
Front bezel
②
①
②
①
①
②
