Summary of Contents for ZEP Dyna-Clean
- Page 1 ZEP DYNA PARTS WASHERS — SOLVENT Model Dyna-Clean Operations and Maintenance Instructions (Drum not included) Zep Inc. 3330 Cumberland Blvd. Atlanta, GA 30339 www.zepequipment.com 786-93885 1 of 14 6/6/22...
- Page 2 Contact the seller for further instructions. INTRODUCTION The Zep Dyna-Clean is a heavy-duty, industrial, and stable parts washers for cleaning with solvent- based cleaners. An ideal choice for fast, efficient and economical cleaning of dirty or greasy parts. The Zep Dyna-Clean meets or exceeds the OTC Freeboard Specifications.
-
Page 3: Safety Warnings/Cautions
SAFETY WARNINGS/CAUTIONS Read all of the SAFETY INSTRUCTIONS on the machine and those in the manual BEFORE installing or using this equipment. Keep this manual handy for reference/training. You will find various types of safety information on the following pages and on the labels attached to Zeps equipment. - Page 4 Do not operate below minimum liquid level marking. Low liquid level may result in motor failure, creating a potential fire hazard. Fill tank to recommended operating capacity range before plugging in power cord. Do not operate with drum empty. Operator shall wear appropriate PPE (personal protective equipment). Refer to cleaning fluid SDS (safety data sheet) for details.
-
Page 5: Specifications And Dimensions
The Zep Dyna-Clean is designed to be used with combustible (flash point over 104°F) petroleum-based cleaning fluids such as Zep Dyna 143, Dyna 170, Dyna Zone Defense, Dyna 680-T2, or Dyna 5202. H min H max 38.2"... - Page 6 Unit is now ready for use. Automatic Safety Cover Open the lid on your Dyna-Clean and you will notice that it lifts simply and easily with one hand. There is nothing to connect or disconnect to open or close the cover.
-
Page 7: Item Description
FIGURE 2 ITEM DESCRIPTION ITEM DESCRIPTION Gas Spring Stud Tube, 1/2" ID Cotter Pin Pump Flat Washer Drain Filter Sock Fusible Link Drain Hole Cover Push Cap Shut Off Valve Bolt 1/4-20 Magnetic Sink Stopper Sleeve Trap Cover Gas Spring Flexible Plastic Hose Flexible Plastic Hose –... -
Page 8: Canister Filter
Removes large particles of dirt and grime to extend fluid life. It is recommended to remove and clean nylon filter sock daily for optimum filtration of contaminants. CANISTER FILTER Replace the Zep canister filter every two months or when there is a reduction in flow rate from the spout. DYNA-TRAP FILTER BAG Attach the Dyna-Trap by pushing the connector hose onto the hose-barb at the rear of the tank and turn the “ON/OFF”... -
Page 9: Maintenance
MAINTENANCE Cleaning Inspect pump, fusible link, and all electrical cords and plugs each time unit is cleaned. Do NOT use if any wear or damage is noticed until impaired components are repaired or replaced. Fill drum to recommended operating capacity range before plugging in power cord. (See INSTALLATION AND OPERATION section. -
Page 10: Troubleshooting Guide
TROUBLESHOOTING GUIDE CONDITION POSSIBLE CAUSE CORRECTION Machine is unplugged Plug machine into outlet Pump is not plugged into Plug pump into electrical box electrical box Pump does not run Check breaker and correct. If Circuit breaker is tripped problems persist, contact Graymills. Pump motor is burned out Replace pump Faulty switch... -
Page 11: Replacement Parts
REPLACEMENT PARTS PART DESCRIPTION DRAWING REF. NUMBER Fuse Link PWP0091 Figure 2 (D) Gas Spring PWP0087 Figure 2 (H) Canister Filter – Fine PWF0102 Figure 2 (J) Canister Filter – Medium * PWF0202 (* included with Canister Filter – Coarse machine) PWF0302 Rocker Switch... -
Page 12: Limited Equipment Warranty
LIMITED EQUIPMENT WARRANTY Zep Inc warrants to the original purchaser that all equipment furnished by Zep will be free from defects in material and workmanship under normal proper maintenance. Zep’s obligation under this Warranty is limited to: A. One year from date of purchase for parts and/or labor to repair or replace defective equipment. - Page 13 DRUM MOUNTED PARTS WASHERS — SOLVENT Model Dyna-Clean Operations and Maintenance Instructions *** PLACEHOLDER FOR *** *** SPANISH TRANSLATED VERSION *** Zep Inc. 3330 Cumberland Blvd. Atlanta, GA 30339 www.zepequipment.com 786-93885 13 of 14 6/6/22...
- Page 14 DRUM MOUNTED PARTS WASHERS — SOLVENT Model Dyna-Clean Operations and Maintenance Instructions *** PLACEHOLDER FOR *** *** FRENCH TRANSLATED VERSION *** Zep Inc. 3330 Cumberland Blvd. Atlanta, GA 30339 www.zepequipment.com 786-93885 14 of 14 6/6/22...
