paasche TG Talon Quick Start Manual

TG Talon – Airbrush
Double Action - Internal Mix - Gravity Feed - PTFE Packings.
Size #2 Needle,Tip,and Aircap Installed.

TG Specifications:

• Dual Action • Gravity Feed • Internal Mix • Cutaway Handle w/ Pre-set Needle Stop • PTFE Packing
• TT-2, TN-2, and TA-2 Components come installed on Talon.

Options for Talon:

.2mm head (TT-0, TN-0 and TA-1 components)Great for jobs requiring the "extremely
.25mm head (TT-1, TN-1, and TA-1 components)
.66mm head (TT-3, TN-3 and TA-3 components)
.66mm Fan Aircap (TAF-3, TN-3 and TT-3)

Working pressure:

Operating pressures 15-55 PSI; Maximum pressure 85 PSI. Fan aircap needs 20 PSI or more.
20-30 PSI is best for detail spraying w/ properly thinned paint
Use the higher pressures for thicker material where fine detail is not critical
or thin the paint for lower pressures.

Airbrush Operation:

1. Attach air hose to air supply and to airbrush. If using a regulator set pressure between 20-55 psi .
2. Press down on Finger Button to release air and pull back on button to control quantity of color.
3. Speed of movement controls density of color and fading effects at beginning and end of strokes.
4. Practice this movement until you can spray a fine line or a broad pattern without heavy build up at the
beginning or end of your strokes.
5. For detail, hold the airbrush very close to the surface push down for air and pull back very slowly on
the Finger Button to release a small amount of paint.
6. For background work and broad effects, hold the airbrush away from the work surface and pull back
on Finger Button to release required amount of color.
*
* Note: Etched lines on items
2 3, 24. indicate size. All
, and
should match when installed
on airbrush.
NO. PART
XI-41
1.
TAF-3
1a.
2.*TA-1,TA-2,TA-3 Head(.25mm, .38mm, .66mm)
(Size TA-1 Head is used with size 0 and 1 Tip)
3.*TT-0,TT-1,TT-2,TT-3Tip(.2mm,.25mm,.38mm,.66mm)
MIL-12
4.
TG-30
5.
TG-4
6.
TAL-8
7.
TAL-37
8.
9. TAL-14
10. TAL-36
10a. A-53
For Multi-Language Manuals go to: www.paascheairbrush.com
DESCRIPTION
Needle Protection Cap
Fan Aircap for .66mm head -
"O" Ring for TG-30 Shell
Shell Assembly
Cup Cover
Packing Assembly PTFE
Trigger
Valve Casing
Valve Plunger (Includes O-ring)
(Optional) Pack of (6) O-rings
INSTRUCTIONS AND PARTS LIST TG-TALON 9/25/2020
WARNING: Spray materials may be harmful if
inhaled or allowed to come into contact with the
skin or eyes. Consult the product label and material
safety data sheet supplied for the spray material.
Follow all safety precautions. CAUTION:
Ventilated Area Required to remove fumes, dust or
overspray. Maximum Air Pressure 75 P.S.I.
Great for spraying Metallics, Pearlescent and Thicker Paints.
Will give a 2-1/2 to 3 inch flat pattern.
11. TAL-15
11a. TAL-22
12. A-22
17. TAL-18
18. MIL-11
19. TAL-17
20. TAL-19
21. MIL-12
22. TAL-20
23. 3A-4
*24.TN-0,TN-1,TN-2,TN-3 Needle
(.2mm,.25mm, .38mm, .66mm)
25. TAL-35
26. TAL-28
27. TAL-33
fine"detail.
*
Valve Adapter (Includes O-ring)
(Optional) Pack of (6) O-rings
Spring
Rocker Assembly
Needle Spring
Spring Housing
Needle Lock Nut
"O" Ring
Handle
"O" Ring
Allen Wrench
Wrench
Needle Stop
Well
