M OTO R I Z E D S W I TC H - D I S C O N N E C TO R S , OT M 3 2 0 0 E4 M 2 3 0 C - G E
—

6. Technical data

—

6.1 Motor operation

Motor operator, control circuit
Rated operational voltage U [V]
Operating voltage range
Operating angle
Operating time
Protection degree
Rated impulse withstand voltage U
Voltage supply
F2
Cable of the push-buttons (no SELV)
Maximum cable length
State information of locking (no SELV)
Handle attached or motor operator
locked
Locking motor operator
Operating temperature
Transportation and storage temperature
Altitude
Table 6.1 General technical data of motor operators
Type Voltage
OTM3200...4000_ 220-240Vac
Table 6.2 Specified technical data of motor operators
a)
Under nominal conditions
—

6.2 State information

Measurement
Handle attached or motor operator locked
Locking motor operator
SCPD
Table 6.3 State information
Value
220-240 Vac, 50-60Hz
0,85... 1,1 x U
90° 0-I, I-0
See Table 7-2
IP 20, front panel
4 kV
imp
PE N L
Max. MCB 16A
C I 0
100 m
11-12-14 (C/O)
23-24 (NO)
-25... +55 °C
-40... +70 °C
Max. 2000 m
Nominal
U current
a)
e
I
[V]
n
[A]
1,4
Value
11-12-14 (C/O): 5A, AC-1 / 250V
23-24 (NO): 5A, AC-1 / 250V
Max. MCB C2A
Cabling
1,5 -2,5mm
1,5 -2,5mm
1,5 -2,5mm
1,5 -2,5mm
Current Operating
inrush time
a) a)
I-0, 0-I,
[A] [s]
10 1,0 - 2,0
19
2
2
2
2
Fuse
5 x 200 m
250 U
T 2 Ah
