HERCULES SIMPLIFIED PROGRAMMING GUIDE (2020)

SETTING THE CLOCK AND THE DAY OF THE WEEK

When the bathroom radiator is first connected, the clock and date will not be configured, 4 lines will be
displayed indicating that the clock needs to be set.
Please press the Stand-by
Mode and Fan Mode
To set the clock please press and hold the
top left corner, please press + or – to select the current hour, once selected please press
the minutes. Adjust the minutes with the + or – and press
Monday, 2: Tuesday, ... 7:Sunday). Once finished, press
The time and date will be now shown on the screen.
!
Please note that if the unit is disconnected from the mains, you will need to re-set the clock and date

MODE SELECTION

To change the modes please press the
Comfort temperature: Adjustable temperature from 5ºC to 35ºC.
Economy temperature: Adjustable temperature from 1.5ºC to 31.5ºC.
Anti-frost mode: Pre-set at 7ºC. This temperature cannot be altered.
P1 Programming Mode: Pre-set program 1 which can be modified by the user.
P2 Programming mode: Pre-set program 2 which can be modified by the user.
P3 Programming mode: Pre-set program 3 which can be modified by the user.
Pilot wire mode: Settings are established from the pilot wire controller. On this mode, user can
only change temperature and activate/deactivate the Open Windows Function.
button to turn on the bathroom radiator. The display will light up, Comfort
will be shown.
button for 3 seconds. The hour will start to flash at the
button until the desired mode is selected.
to adjust the day of the week (1:
to confirm.
to change
