DRIFT GHOST N2 Quick Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Thank you for purchasing the Drift GHOST N2
CUSTOMER SUPPORT
Download the full manual and check our official website for firmware updates, customer support, and
info on all of our products.
https://driftinnovation.com/
If you have any suggestions, comments or concerns; please contact our customer support team at:
sales@driftinnovation.com
WARRANTY
Warranty does not apply if the product is damaged due to physical abuse, mishandling, accident, fire,
frostbite, water damage, negligence or failure to follow the supplied operating instructions. For more
information on warranty, see:
https://driftinnovation.com/warranty
CONTENTS
1.
2.
3.
Installing the Module
4.
5.
6.
7.
8.
9.
Version 1.0.0.1
GHOST N2 QUICK GUIDE
Date: 2022-01-22

Advertisement

loading
Need help?

Need help?

Do you have a question about the GHOST N2 and is the answer not in the manual?

Questions and answers

Related Manuals for DRIFT GHOST N2

Summary of Contents for DRIFT GHOST N2

  • Page 1: Table Of Contents

    GHOST N2 QUICK GUIDE Thank you for purchasing the Drift GHOST N2 CUSTOMER SUPPORT Download the full manual and check our official website for firmware updates, customer support, and info on all of our products. https://driftinnovation.com/ If you have any suggestions, comments or concerns; please contact our customer support team at: sales@driftinnovation.com...

  • Page 2: Product Specification

    Product Specification: Recording Resolution 4K(4096*2160 17:9) : 24/25FPS 4KUHD(3840*2160, 16:9): 24/25/30FPS 2.7K(2704*1520, 16:9): 25/30/50FPS 1080P(1920*1080,16:9): 24/25/30/50/60/100/120FPS 720P(1280*720, 16:9): 25/30/50/60/200/240FPS WVGA(854*480, 16:9) 25/30FPS Livestream Resolution 1080P(1920*1080,16:9): 30/60FPS 720P(1280*720, 16:9): 30/60FPS WVGA(854*480, 16:9): 30FPS Livestream bitrate：adjustable，8Mbps maximum Livestream protocol： RTSP, RTMP, H.264 Mic：...

  • Page 3: Package Contents

    Package Contents Ghost 4K+ Camera Image Transmission Module Accessories bag Antenna Power/Audio 2-in-1 Cable Mini USB Cable Version 1.0.0.1 Date: 2022-01-22...
  • Page 4 3. Install the Antenna on the module, now your Ghost N2 is ready for use. Reminder: when using the Ghost N2, please supply power on the USB port through the Power/Audio 2-in-1 Cable, since the camera could consume 1.5A current in peak period, camera may not work properly if the 2-in-1 cable (with external power) not applied.

  • Page 5: About Your Camera

    About your camera Power On/Off Connect your Ghost N2 with External Power through the Power/Audio 2-in-1 cable, the camera will be automatically powered on, remove the external power from camera, it will automatically power off. Mode Navigation Press button to toggle between Video mode and Settings mode.

  • Page 6: Features Overview

    (resolution fixed as 480P), you can control the camera to record by the physical Record button on cam, or through Drift Link App remotely, in this settings, camera can record up to 4K resolution.
  • Page 7 stream_gop=30 stream_bitrate=4000000 stream_framerate=30 stream_audio=1 rtmp_url=rtmp://xxxxxxx rtmp_cbr=0 once the script file is saved on the memory card, remove the camera from computer, plug in the external power on the USB port through the 2-in-1 Power/Audio cable, the camera will be powered on, and connect to the router automatically.

  • Page 8: Drift Link App

    From your mobile’s browser, scan below QR code to download and install Drift Link App Once installed, conenct your mobile to the same network as what Ghost N2 connected, turn on the App, you should see the camera appeared on the list, marked with a Red block, you can also see the...
  • Page 9 Drift Link is a tool in order to manipulate the camera remotely, if you need to do livestream, you can use your computer to access the network stream by input the URL as : rtsp://IP address/live, where IP address is your cam’s IP, for example, if your camera is with this address:192.168.5.22, you can access the camera live feed by : rtsp://192.168.5.22/live.

  • Page 10: How To Access Real-Time Video (For Developer)

    How to access real-time video from your camera (for developers) 1. Find the default router gateway of your network: From a computer in the same network, click “Start”, type “cmd” and press “Enter” to open the Command Prompt window. Type “ipconfig” and press “Enter”...

  • Page 11: Remote Control & Setup (For Developer)

    Remote Control & Setup (for developers) With camera’s IP address, you can use HTTP commands to configure or manipulate your camera remotely from either a computer or mobile device. Command list: 1. Zoom in/out http://192.168.4.148/cgi-bin/foream_remote_control?dzoom=1 where the value set to dzoom can be from 1 to 10. 2.
  • Page 12 8. Stop Recording http://192.168.4.148/cgi-bin/foream_remote_control?stop_record 9. Reset Setting http://192.168.4.148/cgi-bin/foream_remote_control?reset_setting 10. Reboot your Camera http://192.168.4.148/cgi-bin/foream_remote_control?reboot 11. Power off your camera http://192.168.4.148/cgi-bin/foream_remote_control?power_off 12. Setup Camera LED Indicator http://192.168.4.148/cgi-bin/foream_remote_control?led=1 where the value: 1 stands for On, 0 stands for Off 13. Setup Camera Exposure Value http://192.168.4.148/cgi-bin/foream_remote_control?exposure=1 where the value: 0 stands for 0, 1 stands for 1, 2 stands for 2, 3 stands for -1, 4 stands for -2.
  • Page 13 where video bitrate value is in Byte, 1000000 means 1Mbyte, 8Mbps. 19. Setup Video Recording Framerate http://192.168.4.148/cgi-bin/foream_remote_control?video_framerate=30 4K（4096 * 2160 17：9）： 24 / 25FPS 4KUHD（3840 * 2160，16：9）： 24 / 25 / 30FPS 2.7K（2704 * 1520，16：9）： 24 / 25 / 30 /50 FPS 1080P（1920 * 1080,16：9）：...
  • Page 14 </video_setting> <stream_setting> <stream_res>2</stream_res> <stream_framerate>30</stream_framerate> <stream_bitrate>2000000</stream_bitrate> </stream_setting> <camera_setting> <dzoom>0</dzoom> <filter>0</filter> <exposure>0</exposure> <mic>3</mic> <led>1</led> <hd_record>0</hd_record> </camera_setting> </Cam_Status> </Response> Where the item : <capture_mode>: 0 stands for video mode , 1 stands for photo mode, 2 stands for timelapse mode, 3 stands for burst mode; N1/N2 only support video and photo mode.

  • Page 15: Auto Detection In A Network (For Developer)

    Auto detection in a network (for developers) Once a Ghost N2 connects into a network, it will broadcast a UDP package to present itself to devices (mobile or PC) in the same network. The package contains the necessary info for the device Version 1.0.0.1...
  • Page 16 Once connected, the device can issue http command to Drift camera for further actions, the following are the details of how the connection can be established. 1. Broadcast package (UDP) format The broadcast package (from camera) is in this format...
