Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Light column
LTM440-FT
LTM444
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for WE-EF LTM444
Summary of Contents for WE-EF LTM444
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Light column LTM440-FT LTM444 Surge Protection This product features built-in surge protection circuitry in compliance with applicable standards. For comprehensive protection of a luminaire installation against lightning and electrical surges, it is essential to cover mains supply and data input lines at the distribution board level, by using respective primary (Type 1) and secondary (Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
- Page 2 Light column LTM440-FT LTM444 IP55, IK09, Class I, ta = 40°C...
-
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the outside of the luminaire, no special maintenance is necessary. Warning: Do not open luminaire while mains supply is switched on. -
Page 4: Installation Procedure
Installation Installation Procedure The product must be installed and maintained by a It is recommended to incorporate the optional WE-EF planted root to ensure maximum stability. building/construction and/or electrical regulations and 1) Switch off mains electrical supply. relevant legislation. 2) Check that rating shown on luminaire label conforms with mains electrical supply. - Page 6 Cable connecting box EK70...
- Page 7 WE-EF HELVETICA WE-EF LIGHTING Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9230W0420 © WE-EF 2020 subject to change.
- Page 8 WE-EF LEUCHTEN Installation and Maintenance Instructions Planted Root ESV4 ESV2 ESV6...
- Page 9 6. XRZ324 ESV4 300-0586 ESV4 300-0459 Suitability Suitability 1. XRY334-AP 1. QSI254 2. XRZ334 3. RRY334-AP 4. RRZ334 ESV2 300-9115 ESV6 300-0457 300-0824 Suitability Suitability 1. PSY414/424 1. LTM440 2. LTM444 3. AMW-C 4. AMF-C 5. AMF-S 6. AML-C 7. FLA461...
-
Page 10: Installation Instruction
Installation Instruction 1) Note: It is the responsibility to installer to 2) Please note, ESV4 must be orientated correctly ensure the suitability of the ESV planted root for different products. In both instances conduit for any local or national structural requirements entry can be rotated to match cable routing. - Page 11 5) For ESV6 please orientate planted root as shown (base plate is parallel to the pathway). connections/conduit. For this installation, use 40 mm long M16 bolts supplie. 7) Place the ESV in the form work for concrete 8) Fit the nominated bolts through mounting pad, ensuring orientation, position and levels are correct.
- Page 12 9) Pour concrete to desired level depending on requirement of soil, paver or concrete. Ensure (as per luminaire instructions) onto mounting Concrete Paver Soil...
- Page 13 WE-EF HELVETICA WE-EF LIGHTING Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9257W0420 © WE-EF 2020 subject to change.
