Unidirectional Control and Communication Connections

G
Rear Panel
C C OM7
S G S G
TX RX G RTS CTS
COM8
TX RX RX G RTS CTS S G S G
Strip wires
3/16"
(5 mm)
max.
To Projector,
Panel Display, or
IR or RS-232
the Wired
Output
IR Remote or
Ground
RS-232 Port of a
Source Device
IR/Serial output ports (see
signals or unidirectional RS-232 serial signals to control various devices (up to 32 total
for IR) via these eight ports. Set output signal type (IR or serial) during configuration. The
figure below shows wiring examples.
Output options:
• IR (with or without carrier signals)
• unidirectional RS-232
1 2 3 4
S G S G
IR/SERIAL
5 6 7 8
S G S G
or
G Ground
S IR Output Signal
Unidirectional
IR
Figure 11. Wiring the IR/Serial Ports
Serial control: Connect one of these ports to the serial control receive (Rx) and ground
pins of the device to be controlled. These ports have the same serial protocol options
as the COM ports (see page 13 for protocol details).
IR control: Connect one of these ports directly to the wired IR port of another device.
Or insert the wires from up to four IR Emitters into an IR port and place the heads of the
emitters over or next to the IR signal pickup windows of the devices. For wiring, see the
following figures or the IR Emitter Installation Guide (available on www.extron.com).
NOTE: Each emitter must be within 100 feet of the IPCP for best IR control results.
Installing One Single Emitter
Ground (−)
IR Signal (+)
One Single IR Emitter
Installing Two Single Emitters
When installing only single emitters, tie them in series as shown below.
Ground (−)
(−)
(+)
IR Signal (+) (−)
(+)
Two Single IR Emitters
figure 7 on page 12) — An IPCP 505 can use infrared
IR/Serial Ports
(-)
IR Receiver
(+)
(-)
of a Projector,
(-)
Display, or
Source Device
(+) (+)
Two Single IR Emitters
Installing One Dual Emitter
Ground (−)
IR Signal (+)
Dual IR Emitter
IPCP 505 • Hardware Features and Installation
Front Panel
RTS
IR/S RELA
CTS
1 2 3 4 1
TX
RX
6 6 6 7 8 5 6 7 8 5
IR/S LEDs
Light when signals are transmitted
on the corresponding IR/serial port
To the
A Y Y Y Y
2 3 3 3
6 7 7 7
